Application Scenarios

In a continuous chemical batch process, a reactor’s control system manages complex sequences involving temperature ramps, pressure holds, and precise ingredient additions over a 12-hour cycle. The control program and the thousands of associated parameters (PID tuning, timers, setpoints) reside in the controller’s volatile RAM. If a brief but total power outage occurs, losing this data would mean the batch is ruined, requiring a tedious manual restart from scratch with significant product loss. The ABB SB808F Memory Board​ is installed in the controller rack precisely to prevent this scenario. It continuously shadows the active controller’s memory. Upon a proper shutdown or the detection of imminent power loss, the controller automatically writes the entire current state—including the exact step in the batch sequence and all live parameters—to the non-volatile storage on the SB808F. When power is restored, the controller reads this data back, allowing the process to resume automatically from the exact point of interruption within seconds. This module addresses the critical pain points of data integrity, process continuity, and reduction of waste in industries where controlled processes cannot tolerate amnesia.

Parameter
