Product Overview

The Emerson UT63 7004-1102 3130-0872 is an industrial electronic circuit board identified by a triple-numbering scheme: model UT63, primary part number 7004-1102, and secondary identification number 3130-0872. This board functions as an internal electronic component within compatible Emerson control equipment, supporting signal processing and control functions for the host system. Unlike catalog-listed I/O modules or processors with published datasheets, the Emerson UT63 7004-1102 3130-0872 is a board-level spare part that exists only as an internal assembly within a larger machine—it is not a user-selectable component with configurable options .

The Emerson UT63 7004-1102 3130-0872 is most commonly associated with Control Techniques drive products under the Emerson umbrella, particularly the Unidrive SP series. Third-party parts suppliers have listed this board as a “UT63 control board” for Emerson CT inverter repair, suggesting its role in the control circuitry of variable frequency drives . The board’s compact dimensions of approximately 140 × 25 × 100 mm and weight of 0.35 kg indicate a small-form-factor PCB designed for integration into a drive chassis or control cabinet, not for standalone mounting . The presence of two identification numbers—7004-1102 and 3130-0872—reflects common industrial PCB practice where the primary part number identifies the assembly and the secondary number denotes a revision, variant, or manufacturing batch. Both numbers must match the original board for reliable replacement.

It is critical to understand what the Emerson UT63 7004-1102 3130-0872 is not. It is not a field-installable option module, it does not have published electrical specifications, and it cannot be selected by performance criteria. Its sole function is to restore operation when the original board in a compatible Emerson drive fails. Purchasing decisions should be based on exact part-number matching and visual verification of the physical board against the unit being replaced, not on assumed specifications or cross-references from other Emerson products .



Technical Specifications

Parameter Name	Parameter Value
Product Model	UT63
Manufacturer	Emerson / Control Techniques
Primary Part Number	7004-1102
Secondary Identification	3130-0872
Product Type	Industrial Electronic Circuit Board (PCB)
Application	Internal component for compatible Emerson control equipment
Typical Use	Board-level replacement, maintenance, and repair
Dimensions	Approx. 140 × 25 × 100 mm
Weight	Approx. 0.35 kg
Origin (per distributor)	USA
Electrical Specifications	Not publicly available
Interface Definition	Not publicly available
Operating Temperature	Not publicly available
Lifecycle Status	Discontinued / spare parts channel only

Note: The absence of electrical and environmental parameters is not an oversight. The manufacturer does not publish a standalone datasheet for this board-level component. Any specification not listed above should be treated as unknown until verified against the physical unit or original equipment documentation.



Main Features and Advantages

Board-level replacement for legacy drive maintenance: The primary value of the Emerson UT63 7004-1102 3130-0872 lies in its role as a drop-in replacement for a failed control board in compatible Emerson/Control Techniques drive systems. When a drive exhibits control faults traced to the UT63 board, replacing the board restores functionality without requiring a complete drive replacement—a significant cost saving for facilities maintaining legacy Unidrive SP or related equipment.

Dual-number identification for accurate matching: The 7004-1102 and 3130-0872 numbering scheme allows maintenance personnel to cross-check against the original board’s silkscreen markings before installation. Industrial PCBs can share similar physical dimensions while differing in component population, connector orientation, or firmware configuration. Matching both numbers reduces the risk of installing an incompatible variant that could fail immediately or cause further damage .
