DescriptionThe 6ES5441-7LA13​ is a SIMATIC S5 Series 441 Digital Output (DO) module manufactured by Siemens, delivering 32 non-isolated (non-floating) 24 V DC output channels at 0.5 A per point in a single compact “L”-format slot. Designed primarily for the S5-90U, S5-95U, and S5-100U small-frame central racks—and equally at home on ET100U / ET200U distributed nodes—the 6ES5441-7LA13​ is the high-density workhorse DO when your field devices (pilot lamps, solenoid valves, small relay coils, indicator towers) all share a common 24 V return and you’d rather spend one rack slot than two. As the later-production sibling of the 6ES5441-7LA12, the 7LA13 carries identical electricals with more stable component batching—making it the preferred drop-in spare for 1990s–2000s S5 machines that still earn their keep.h2 Application ScenariosAn automotive seat-track assembly cell in Southern Germany runs on an S5-100U (CPU 92-3UA21) rack mounted behind the guard door, sequencing six pneumatic clamp cylinders, four pilot-light towers, and twelve intermediate relay coils that drive the 230 V AC weld-timer contactors. The original DO population used two 16-channel 24 V DC modules (different brand third-party clone that the OEM no longer supports), leaving only one free slot for a future analog expansion that the process engineer had been asking for since 2018. When one of the clone DOs started dropping Channel 14 under load—a 0.55 A solenoid valve that technically exceeded the 0.5 A rating but had run fine for 19 years until the clone’s output driver aged—the plant replaced both 16-ch clones with a single 6ES5441-7LA13. Thirty-two outputs, one slot, common 24 V return already shared across the cell’s 0 V bus, and the freed slot finally got the 2-channel AO the weld-timer PID had been waiting for. The pain point the 6ES5441-7LA13​ solved wasn’t fancy features—it was slot economy plus “don’t make me rewire the 0 V trunk” on a machine-center panel where every device already lands on the same M-bus. Three years later, the cell still hasn’t dropped a clamp-cycle.h2

Parameter
