Technical Specifications

Parameter Name	Value
Product Model	ABB 3HNA012323-001/02
Manufacturer	ABB
Product Type	Frequency Converter / Variable Frequency Drive (VFD)
Operating Voltage	380 – 400 V AC (3-phase typical)
Rated Power	1.5 kW (typical low-power variant)
Output Frequency Range	0 – 400 Hz (or up to 50 kHz for variants)
Control Method	PWM (Pulse Width Modulation), Vector Control
Communication Protocols	Modbus RTU, Ethernet/IP
Inverter Efficiency	Up to 97%
Input Current	2.5 A (typical)
Output Current	2.0 A (typical)
Cooling Method	Air Cooling (forced convection)
Protection Class	IP20
Dimensions	Approx. 152 x 150 x 160 mm
Weight	Approx. 4.5 kg
Operating Temperature	-10°C to +50°C
Certifications	CE, UL, CSA, IEC





Main Features and Advantages

Advanced PWM Control with High Efficiency: The ABB 3HNA012323-001/02 utilizes PWM control technology to deliver a smooth, sinusoidal current waveform to the motor, minimizing harmonic distortion and reducing motor heating . This technology contributes to the device’s remarkable efficiency rating of up to 97%, significantly reducing energy losses and operational costs in continuous duty applications .

Flexible Control Modes for Diverse Loads: Supporting both V/F (Voltage/Frequency) and sophisticated Vector Control modes, the ABB 3HNA012323-001/02 adapts to a wide variety of load characteristics . Vector Control provides excellent torque response at low speeds, making the ABB 3HNA012323-001/02 ideal for demanding applications like hoists, extruders, and conveyors, while V/F control is perfectly suited for variable torque loads such as fans and pumps .

Seamless System Integration: The ABB 3HNA012323-001/02 features built-in support for Modbus RTU and Ethernet/IP communication protocols, allowing for easy integration with PLCs, SCADA systems, and factory automation networks . This connectivity enables remote monitoring, centralized control, and real-time data acquisition, which are essential for modern, data-driven industrial environments.

Robust and Reliable Construction: Built to withstand harsh industrial conditions, the ABB 3HNA012323-001/02 features an IP20 protection class, offering protection against solid objects larger than 12mm . Its air-cooled design is engineered for reliability, and the inclusion of robust overload protection mechanisms ensures the ABB 3HNA012323-001/02 and the connected motor are safeguarded against overcurrent and overheating conditions . Its certified compliance with global standards (CE, UL, CSA, IEC) confirms its adherence to strict safety and quality benchmarks .

Compact Footprint and Easy Installation: The ABB 3HNA012323-001/02 boasts a compact form factor (approx. 152 x 150 x 160 mm) and lightweight design (~4.5 kg), enabling easy installation in space-constrained control cabinets . Standardized connectors and clear labeling further simplify the wiring and commissioning process.



Application Fields

The ABB 3HNA012323-001/02 is a versatile and high-performance motor controller deployed across a wide spectrum of industries where precise speed control and energy efficiency are paramount.

In the water and wastewater treatment industry, the ABB 3HNA012323-001/02 is widely used to regulate the speed of pumps and blowers, enabling precise flow control and significant energy savings compared to constant-speed operation. The drive’s soft-start capability reduces water hammer and mechanical stress on pump systems, extending equipment life. Similarly, in building automation and HVAC, the ABB 3HNA012323-001/02 controls fans, pumps, and compressors, optimizing climate control and reducing power consumption in large commercial and industrial facilities.

In manufacturing and material handling, the ABB 3HNA012323-001/02 provides the reliable speed and torque control needed for conveyor belts, packaging machinery, mixers, and extruders. Its support for advanced control algorithms ensures stable operation even with variable loads, enhancing product quality and production efficiency. The ABB 3HNA012323-001/02 is also well-suited for textile and printing machinery, where precise speed and tension control are critical for maintaining process consistency.

In the oil, gas, and petrochemical sector, the ABB 3HNA012323-001/02 is deployed for process pumps, compressors, and fan applications, where robust construction and reliable operation are non-negotiable. Its ability to withstand harsh environmental conditions and its compliance with international safety standards make it a trusted component in these critical applications. For system integrators and maintenance engineers, the ABB 3HNA012323-001/02 offers a reliable solution for improving the efficiency and performance of existing motor-driven machinery.
