Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | 3BHE028767R0101 |
| Manufacturer | ABB |
| Product Type | Inverter Driver Board / IGBT Gate Driver Board |
| Compatible Platforms | ABB ACS 2000, ACS 5000, ACS 6000, AC 800PEC |
| Core Function | Converts Fiber Optic PWM Signals to IGBT/IGCT Gate Drive |
| Input Signal | Fiber Optic PWM (from PCD/PEC master controller) |
| Output Drive Level | ±15 V or +15 V / -5 V (depending on power module) |
| Auxiliary Power Supply | 24 V DC (isolated) |
| Protection Functions | DESAT Detection, Active Clamping, UVLO, VCE Monitoring |
| Isolation Rating | ≥2500 V DC (reinforced insulation) |
| Status Feedback | Fiber Optic Fault Signal (VCE/Power Monitoring) |
| Operating Temperature | -25°C to +70°C (industrial wide temperature) |
| Storage Temperature | -40°C to +85°C |
| Certifications | CE, IEC 61800-5-1 |
Main Features and Advantages
Precision Gate Drive for High-Power Semiconductors: The ABB 3BHE028767R0101 is purpose-built to interface with IGBT and IGCT power modules, converting low-power fiber optic PWM signals into the high-current gate pulses required to switch large power semiconductors. The ABB 3BHE028767R0101 delivers typical output levels of ±15 V or +15 V / -5 V, providing the positive voltage needed for device turn-on and negative voltage for reliable turn-off and noise immunity . This precision gate drive ensures that power modules switch efficiently, minimizing switching losses and extending the operational life of the entire drive system.
Integrated Short-Circuit Protection: The ABB 3BHE028767R0101 features DESAT (de-saturation) detection circuitry that continuously monitors the IGBT’s VCE saturation voltage during the on-state. When a short-circuit or overcurrent condition is detected, the ABB 3BHE028767R0101 initiates a “soft turn-off” sequence, blocking the gate drive signal within microseconds to prevent the power module from destructively failing . This rapid response capability protects the facility’s most expensive drive components—the power semiconductor modules—from catastrophic damage, representing substantial cost savings in repair and replacement.
Fiber Optic Isolation and Noise Immunity: The ABB 3BHE028767R0101 communicates with the master controller entirely through fiber optic links, eliminating the risk of electromagnetic interference (EMI) corrupting the PWM command signals or fault feedback . The reinforced insulation rating of ≥2500 V DC ensures that control electronics are safely isolated from the high-voltage power section, protecting the drive’s sensitive control board from potential ground faults. The ABB 3BHE028767R0101‘s fiber optic interface makes it particularly suitable for installation in high-EMI environments such as steel mills and mining operations where copper signal cables would be susceptible to noise.
Comprehensive Diagnostics and Status Monitoring: The ABB 3BHE028767R0101 includes onboard status LEDs (RUN/FAULT/PWR) and test points that enable rapid field diagnostics without specialized test equipment . When a fault condition occurs, the ABB 3BHE028767R0101 reports the failure back to the master controller via a separate fiber optic feedback channel, allowing the control system to log the event and initiate an appropriate response, such as tripping the drive or switching to a redundant power unit.
