Product Overview

The 3BSE050091R65, officially designated as the ABB PFEA112-65, is a high-performance tension electronic device engineered for precision measurement and control of web tension in industrial processing applications. This advanced tension controller belongs to ABB’s PFEA series of tension electronics and serves as a critical component in automated tension control systems, enabling real-time monitoring and regulation of material tension during winding, unwinding, and processing operations. The PFEA112-65 receives signals from up to two tension sensors (load cells), processes these inputs through sophisticated control algorithms, and provides accurate tension feedback for closed-loop control. With its compact design, flexible mounting options, and robust IP65 protection, the PFEA112-65 is ideally suited for demanding industrial environments across paper, film, metal foil, textile, and printing applications. The 3BSE050091R65 features a 2×16 character multilingual interactive display for real-time tension monitoring and configuration, with the added capability of PROFIBUS-DP communication for seamless integration with higher-level control systems.



Technical Specifications

Parameter Name	Parameter Value
Product Model	PFEA112-65
Ordering Code	3BSE050091R65
Manufacturer	ABB
Product Type	Tension Electronics / Tension Controller
Series	PFEA
Number of Load Cells	2
Load Cell Excitation	0.5 A rms, 330 Hz
Max. Load Capacity	2 load cells plus 5 Ω cable resistance
Power Supply (IP20)	24V DC (18-36V)
Power Supply (IP65)	100-240V AC, 45-65 Hz
Power Consumption	7.5W
Analog Outputs	1x -5 to +11V, 1x 0-21mA
Analog Output Scaling	Yes
Selectable Filter	15, 30, 75, 250, 750, 1500 ms
Communication	PROFIBUS DP (GSD file: ABB_0716.GSD)
Display	2×16 Character Multi-Language Interactive
Tension Units	N, kN, kg, lbs, N/m, kN/m, kg/m, pli
Max Load Memory	Yes
Zero Offset Memory	Yes
Self-Diagnostics	LED (Green/Red)
Protection Class	IP20 (DIN Rail) / IP65 (Wall Mount)
Operating Temperature	+5°C to +55°C
Product Net Weight	1 kg
Country of Origin	Sweden
Replaced Product ID	3BSE030369R65



Main Features and Advantages

Precision tension measurement and control: The PFEA112-65 delivers accurate and reliable tension measurement by processing signals from two load cells, providing SUM, individual A&B, and differential signal displays. The 3BSE050091R65 incorporates advanced signal processing with adjustable filtering options (15, 30, 75, 250, 750, 1500 ms) to optimize signal response speed and stability according to specific application requirements. This flexibility ensures that the PFEA112-65 can accommodate a wide range of process dynamics, from slow-responding web processes to high-speed applications.

Comprehensive connectivity and communication: The PFEA112-65 provides flexible analog output options including voltage (-5 to +11V) and current (0-21mA) with scaling capability, facilitating seamless integration with various actuators such as drives, brakes, and clutches. The integrated PROFIBUS-DP interface (with associated GSD file ABB_0716.GSD) enables the 3BSE050091R65 to exchange data and parameters with upper-level control systems, supporting centralized monitoring and control. This communication capability makes the PFEA112-65 an ideal solution for modern, connected industrial environments.

User-friendly operation and diagnostics: The PFEA112-65 features a multi-language interactive 2×16 character display that provides real-time visibility of tension values, sensor signals, and system status. Configuration keys allow operators to set various parameters and check the tension system’s health without specialized tools. The 3BSE050091R65 includes self-diagnostic functions with a green/red LED indicating status, plus maximum load memory and zero offset memory functions that enhance usability and control accuracy. This intuitive interface significantly simplifies setup, operation, and troubleshooting, reducing downtime and training requirements.

Robust design for harsh environments: The PFEA112-65 is available in two mounting versions: an IP20 DIN-rail version for standard electrical cabinets and an IP65 wall-mount version for installation in harsh, dusty, or washdown environments. This flexibility ensures that the 3BSE050091R65 can be deployed in a wide variety of industrial settings without compromising performance or reliability. The rugged construction and proven durability of the PFEA112-65 make it a trusted choice for continuous operation in demanding applications.
