Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | 2MBI600VX-120-50 |
| Manufacturer | ABB (based on Fuji Electric V-Series platform) |
| Product Type | Dual IGBT Power Module (2-in-one package) |
| Series | VX Series (6th Generation) |
| Collector-Emitter Voltage (VCES) | 1200 V |
| Continuous Collector Current (Ic) | 600 A (Tc=80°C) |
| Peak Collector Current (1ms) | 1200 A |
| Gate-Emitter Voltage (VGES) | ±20 V |
| Collector-Emitter Saturation Voltage (Vce(sat)) | Typ. 1.80 V (Ic=600A, Tj=125°C) |
| Operating Junction Temperature (Tvj op) | -40°C to +150°C (max 175°C) |
| Storage Temperature (Tstg) | -40°C to +125°C |
| Isolation Voltage (Viso) | ≥ 2500 V AC (1 min, terminal to base) |
| Package Type | M282 Dual XT |
| Dimensions | 62mm (W) x 150mm (L) |
| Weight | Approx. 350 g |
Main Features and Advantages
High power density and current capability: The ABB 2MBI600VX-120-50 delivers exceptional power handling with 1200V blocking voltage and 600A continuous current capacity. This robust rating enables the ABB 2MBI600VX-120-50 to drive large AC motors in the 250-400kW range, making it a preferred choice for heavy industrial variable frequency drives. The pulse current capability of 1200A provides adequate headroom for transient overload conditions common in crane hoists, extruders, and rolling mill applications.
Advanced Trench-FS technology for low losses: Built on the 6th generation V-series platform, the ABB 2MBI600VX-120-50 features trench-gate field-stop IGBT structure that achieves an optimal balance between conduction and switching losses. The typical saturation voltage of 1.80V at rated current ensures reduced power dissipation in the on-state, while optimized switching characteristics minimize turn-off losses (Eoff), enabling efficient operation at switching frequencies up to 20kHz. This translates to smaller cooling requirements and higher overall system efficiency.
Low-inductance package design for reliable switching: The ABB 2MBI600VX-120-50 incorporates a low-inductance module structure that significantly reduces parasitic inductance within the power loop. This design minimizes voltage overshoot during turn-off transients, allowing the ABB 2MBI600VX-120-50 to operate safely at high DC link voltages without requiring additional snubber circuits. The reduced EMI emissions also simplify compliance with electromagnetic compatibility standards in sensitive industrial environments.
