Product Overview

The Allen‑Bradley 1336F‑BRF200‑AA‑EN​ is a member of Rockwell Automation’s 1336 PLUS II (1336F Series) family of Adjustable Frequency AC Drives (Variable Frequency Drives / VFDs), rated for 200 HP (150 kW) output at 480 V AC three‑phase input. Designed to control the speed, torque, and direction of standard squirrel‑cage induction motors, the Allen‑Bradley 1336F‑BRF200‑AA‑EN​ provides flexible control strategies including Volts‑per‑Hertz (V/Hz), Sensorless Vector (SV), and—when used with an encoder feedback card—closed‑loop flux vector control. The drive accepts a 380–480 V AC ±10 %, 50/60 Hz three‑phase supply and delivers a PWM‑synthesized output of 0–input voltage at frequencies from 0.5 Hz up to 650 Hz (depending on carrier‑frequency settings), making it suitable for both constant‑torque and variable‑torque (fan/pump) applications.The Allen‑Bradley 1336F‑BRF200‑AA‑EN​ features a built‑in DSI (Drive Serial Interface / RS‑485) port for peer‑to‑peer or SCADA connectivity, programmable digital and analog I/O, and an English‑language alphanumeric keypad/display (designated by the “‑EN” suffix) showing parameter names, fault codes, and process values in plain text rather than numeric codes alone. The drive includes electronic motor overload protection (per NEC/UL 508C Class I/II), DC injection braking, programmable acceleration/deceleration ramps (S‑curve or linear), and provisions for an external dynamic‑braking resistor or regenerative unit. It is housed in a NEMA 1 / IP20 enclosed book‑size frame intended for through‑panel or back‑of‑cabinet mounting with adequate ventilation or forced‑air cooling.Positioned as a mid‑to‑high horsepower general‑purpose drive within the Allen‑Bradley portfolio (between the smaller 1336 PLUS II frames and the later PowerFlex 700 series), the Allen‑Bradley 1336F‑BRF200‑AA‑EN​ remains widely specified for legacy system spares, retrofit projects, and plants standardizing on 1336F architecture. Its combination of sensorless vector performance, comprehensive onboard I/O, and straightforward HMI makes it a cost‑effective choice for process and discrete manufacturing lines where a PowerFlex 700/755 retrofit is not yet justified. The drive draws on decades of Rockwell drive engineering and is fully configurable via the local keypad or Rockwell Software DriveExplorer / DriveExecutive tools.

Technical Specifications

Product Model | 1336F‑BRF200‑AA‑ENManufacturer | Rockwell Automation / Allen‑BradleyProduct Type | Adjustable Frequency AC Drive (VFD / Inverter), 1336 PLUS II SeriesNominal Output Power | 200 HP (150 kW) @ 460–480 V AC, 3‑PhaseRated Output Current | approx. 260 A (460 V, normal duty) / 240 A (heavy duty depending on frame & overload class)Input Voltage | 380–480 V AC ±10 %, 3‑Phase, 50/60 HzOutput Voltage | 0–Input Voltage (PWM)Output Frequency Range | 0.5–650 Hz (programmable)Control Modes | V/Hz (linear / squared‑V/Hz for fans/pumps), Sensorless Vector (SLV), Optional Closed‑Loop Flux Vector with encoder cardOverload Capability | 150 % for 60 s, 200 % for 3 s (Normal Duty / Variable Torque rating)Enclosure Rating | NEMA Type 1 / IP20 (open‑type with cover)Cooling Method | Forced‑air fan cooling (frame‑size dependent, typically integral blower)Communication Ports | Built‑in DSI (RS‑485, half‑duplex, Allen‑Bradley proprietary SCANport/DSI protocol); optional DeviceNet, ControlNet, Profibus DP, Ethernet/IP via add‑on communication cardDigital I/O | 6 programmable discrete inputs (sink/source selectable), 2 programmable relay outputs (Form‑C), 1 opto‑isolated open‑collector outputAnalog I/O | 2 analog inputs (0–10 V / 4–20 mA, jumper selectable), 1 analog output (configurable 0–10 V or 4–20 mA for frequency/current/DC bus feedback)Operator Interface | Integral alphanumeric keypad & 2‑line × 16‑character LCD (English — “‑EN” option)Dimensions (H×W×D) | Approx. 762 × 305 × 330 mm (30.0″ × 12.0″ × 13.0″) — frame B book‑size; verify exact per revisionWeight | Approx. 68–75 kg (150–165 lb)Certifications | UL 508C, CSA C22.2 No. 14, CE, IEC 61800‑5‑1 / ‑3‑2 (with line reactor)Ambient Operating Temp. | 0 °C to +40 °C (+32 °F to +104 °F), derated above 40 °CHumidity | 5–95 % RH non‑condensing
