Application Scenarios
This module is the core output component in large‑scale process control systems (chemical, pharmaceutical, power generation). It is typically installed in the central S7‑400 rack to provide setpoints for closed‑loop PID control (e.g., valve opening), speed reference for drives, or pressure/flow control signals. Its high resolution and diagnostics make it suitable for applications requiring precise analog command output and fault monitoring.
Parameter
| Main Parameters | Value/Description |
|---|---|
| Catalog Number | 405‑4DAC‑2 (6ES7 405‑4DA02‑0AA0) |
| Manufacturer | Siemens AG |
| Series | SIMATIC S7‑400 |
| Module Type | Analog Output (AO) |
| Number of Channels | 4 (independently configurable) |
| Output Signals | Voltage: 0‑10 V, ±10 V; Current: 0‑20 mA, 4‑20 mA |
| Resolution | 15 bits + sign (high precision) |
| Accuracy | Typically < ±0.5% of full scale (at 25 °C) |
| Load Impedance | Current: ≤ 500 Ω; Voltage: ≥ 1 kΩ |
| Diagnostics | Wire break (4‑20 mA), Short‑circuit, Overflow/Underflow |
| Isolation | Channels isolated from backplane and from each other |
| Connection | 40‑pin front connector (e.g., 6ES7 492‑1… ) |
| Operating Temperature | 0 °C to +60 °C |
Technical Principles and Innovative Values
- Innovation Point 1: High‑Density Precision: Unlike older modules with fixed ranges, the 405‑4DAC‑2 offers 4 fully independent and isolated channels in a single‑width module. Each channel can be individually configured for voltage or current output via software (STEP 7), providing extreme flexibility in cabinet design.
- Innovation Point 2: Advanced Diagnostic Safety: The module features comprehensive diagnostics, including wire‑break detection (for 4‑20 mA loops) and short‑circuit monitoring. It can trigger diagnostic interrupts to the CPU, allowing the control system to take immediate safety actions (e.g., switch to manual mode) if an output channel fails.
- Innovation Point 3: Deterministic Performance: With a 15‑bit resolution and fast conversion time, the module ensures that precise analog setpoints are delivered to the field with minimal jitter. This is critical for stable closed‑loop control in processes where even minor signal fluctuations can cause product quality issues.
