Application Scenarios
This CPU is the core of medium-sized industrial control systems (e.g., packaging machinery, material handling, process control). It is typically installed in Slot 2 of a standard S7‑300 rack (with a power supply in Slot 1). Its primary value proposition is cost-effective migration or replacement for existing Siemens S7‑300 systems, allowing engineers to reuse existing racks, I/O modules, and STEP 7 programs with minimal modification.
Parameter
| Main Parameters | Value/Description |
|---|---|
| Catalog Number | 315‑2AG10 (VIPA) |
| Manufacturer | VIPA GmbH (Germany) |
| Compatible Series | Siemens SIMATIC S7‑300 (Hardware & Software) |
| Work Memory | 128 KB / 256 KB (depending on version) |
| Integrated Interface | 1 × MPI/PROFIBUS DP (configurable as Master/Slave) |
| Bit Instruction Time | ~0.1 µs (faster than many original S7‑300 CPUs) |
| Max. I/O Addressing | 1024 bytes Digital In/Out; 256 bytes Analog In/Out |
| Programming Software | Siemens STEP 7 Classic (V5.x) / TIA Portal (via GSD/HSP) |
| Power Supply | 24 V DC (via S7‑300 backplane bus) |
| Operating Temperature | 0 °C to +60 °C |
Technical Principles and Innovative Values
- Innovation Point 1: SPEED7 Technology: Unlike standard S7‑300 CPUs, VIPA utilizes its proprietary SPEED7 microprocessor architecture, which executes binary instructions significantly faster (typically < 0.1 µs), providing better real-time performance for logic-heavy applications.
- Innovation Point 2: Seamless Compatibility: The module is mechanically and electrically identical to a Siemens CPU 315‑2 DP. It uses the same 40‑pin front connector, DIN rail mounting, and backplane bus protocol, allowing it to be dropped into an existing S7‑300 rack without wiring changes.
- Innovation Point 3: Software Transparency: In Siemens STEP 7 or TIA Portal, the module is configured and addressed as a standard CPU 315‑2 DP (6ES7 315‑2AG10‑0AB0). This means existing Siemens projects can often be downloaded directly with no code changes, drastically reducing migration effort.
