Application Scenarios
A packaging machine OEM needed a compact controller to handle logic sequencing, conveyor coordination, and communication with multiple ABB ACS drives for speed control. The ABB PM5032-T-ETH was selected as the main PLC. Its onboard digital inputs monitored sensors and safety interlocks, while the transistor outputs controlled solenoids and relays. The integrated Ethernet port allowed the PM5032-T-ETH to act as a Modbus TCP master, reading speed feedback from the drives and sending setpoints. This setup eliminated the need for a separate communication module, reducing cabinet space and cost while maintaining precise synchronization between the drives and the packaging process.
Parameter
| Parameter | Value / Specification |
|---|---|
| Product Model | PM5032-T-ETH |
| Manufacturer | ABB |
| Ordering Code | 1SAP123400R0072 (or R0172 for newer version) |
| Product Type | PLC Processor Module (AC500-eCo V3 Series) |
| CPU & Memory | 32-bit Processor, 2 MB User Memory |
| Integrated I/O | 12x DI (24V DC), 8x DO (Transistor, 24V DC / 0.5A), 2x DC (Configurable DI/DO) |
| Communication | 1x Ethernet (10/100 Mbit/s), 2x Option Slots (for serial modules like CM572-RS232/RS485) |
| Programming | Supports IEC 61131-3 (LD, FBD, ST, SFC) via ABB Automation Builder |
| Power Supply | 24 V DC (20.4 – 28.8 V DC) |
| Operating Temp. | 0 °C to +60 °C (horizontal mounting) |
| Mounting | DIN Rail (35mm) |
| Protection | IP20 |
