Application Scenarios
In a Taiyuan municipal water pumping station, the PM5032-T-ETH serves as the local controller for a pump cluster. The onboard digital inputs monitor pump status and flow switches, while the transistor outputs control pump contactors. The integrated Ethernet port communicates pump runtime data and alarms to the central SCADA system via Modbus TCP, and the optional serial board (e.g., TA51xx series) connects to a local HMI for operator interface.
Parameter
| Main Parameters | Value/Description |
|---|---|
| Product Model | PM5032-T-ETH |
| Order Code | 1SAP123400R0072 |
| Product Family | ABB AC500-eCo V3 (Economy PLC) |
| Processor | TI ARM Cortex-A9 32-bit RISC, 300 MHz |
| User Memory | 2 MB (Application code/data) |
| Onboard I/O | 12x DI (24V DC, sink/source) + 8x DO (24V DC, transistor, 0.5A) |
| Configurable I/O | 2x additional configurable digital channels (DC) |
| Communication Ports | 1x Ethernet (10/100 Mbps, RJ45), 1x USB (programming) |
| Option Slots | 2 slots for TA51xx boards (serial RS-232/485, analog I/O, etc.) |
| Programming | IEC 61131-3 (LD, FBD, IL, ST, SFC, CFC) via Control Builder+ |
| Supply Voltage | 24 V DC (19.2 – 30 V DC) |
| Power Consumption | ~8.1 W (max) |
| Operating Temperature | 0 °C to +60 °C (industrial) |
| Dimensions (WxHxD) | 74 mm x 135 mm x 82 mm |
| Weight | ~0.253 kg |
| Mounting | DIN Rail (35 mm) |
| Protection Rating | IP20 |
