Description

Main Features and Advantages

High Torque Handling:With a rated power of 1.5kW and maximum overload current of 18.0A,the YASKAWA ELECTRIC CACR-SR15BB1AF efficiently drives high-torque servo motors,making it suitable for applications requiring heavy lifting or high force,such as robotic material handling and large-part assembly.

Precision Control Algorithms:Equipped with vector control,advanced PID,and feedforward compensation,this servo drive minimizes position and speed errors even under dynamic load changes.This ensures consistent accuracy in tasks like CNC machining and precision welding,where tight tolerances are critical.

Flexible Feedback Options:Supporting both incremental and optional absolute encoders,the YASKAWA ELECTRIC CACR-SR15BB1AF adapts to diverse application needs.Absolute encoders eliminate the need for homing sequences after power loss,enhancing system reliability in automated lines.

Robust Industrial Design:Built to withstand harsh factory environments,the servo drive operates reliably in temperatures up to 55°C and resists humidity,vibration,and electromagnetic interference.Its durable construction ensures long-term performance in demanding settings like metalworking and automotive plants.

Comprehensive Protection:Featuring multiple protection mechanisms—including overcurrent,overvoltage,and motor overload safeguards—the YASKAWA ELECTRIC CACR-SR15BB1AF prevents damage to itself and connected motors,reducing downtime and maintenance costs.

Application Field

In automotive manufacturing,the YASKAWA ELECTRIC CACR-SR15BB1AF controls robotic arms used in welding,riveting,and heavy component assembly.Its high torque handling and precision enable these robots to manipulate large car parts(e.g.,chassis,engine blocks)with accuracy,ensuring consistent build quality.

In logistics automation,this servo drive powers heavy-duty conveyor systems and AGVs(Automated Guided Vehicles)that transport pallets,crates,and large packages in warehouses and distribution centers.Its robust performance ensures smooth,reliable movement even under varying load weights,optimizing material flow.

In metal fabrication,the YASKAWA ELECTRIC CACR-SR15BB1AF regulates the motion of CNC plasma cutters,bending machines,and heavy-duty lathes.Its precise speed control ensures clean cuts and accurate bends in thick metal sheets,meeting the strict tolerances required for structural and aerospace components.

In packaging for bulk goods(e.g.,chemicals,construction materials),the servo drive controls large filling and sealing machines.It maintains precise speed and torque to handle heavy packaging materials,ensuring consistent sealing and filling accuracy while minimizing waste.

Related Products

YASKAWA ELECTRIC CACR-SR20BB1AF:A higher-power variant with 2.0kW rated power,suitable for more demanding heavy-duty applications.

YASKAWA SGMGV-13ADC61:A 1.5kW high-torque servo motor perfectly paired with the CACR-SR15BB1AF for seamless system integration.

YASKAWA JUSP-NS300:A configuration tool for programming and tuning the CACR-SR15BB1AF,enabling advanced parameter adjustment and diagnostics.

YASKAWA CACR-SR10BB1AF:A lower-power 1.0kW model,ideal for applications requiring moderate torque and precision.

YASKAWA SGDM-15ADA:A motion controller that synchronizes multiple CACR-SR15BB1AF drives in multi-axis systems(e.g.,robotic arms with coordinated joints).

YASKAWA CIMR-VB4A0007BAA:A variable frequency drive(VFD)that complements the servo drive in systems requiring both servo and general-purpose motor control.

Installation and Maintenance

Pre-installation preparation:Ensure the mounting surface(panel or DIN rail with adapter)is clean,flat,and properly grounded.Verify the three-phase power supply matches 200-240V AC±10%and that wiring is sized for 6.0A continuous current.Confirm compatibility with the selected servo motor(SGMGV/SGMSV Series)and use shielded cables for control signals to prevent EMI(Electromagnetic Interference).

Maintenance recommendations:Periodically inspect connections for tightness,especially power terminals,to avoid overheating.Clean cooling vents and heat sinks monthly to maintain thermal efficiency.Use YASKAWA’s servo tuning software quarterly to verify parameters and calibration.Monitor fault codes via the drive’s LED indicators and refer to the manual for troubleshooting.Avoid exposure to excessive moisture,dust,or vibration to extend service life.

Product Guarantee

The YASKAWA ELECTRIC CACR-SR15BB1AF is backed by YASKAWA’s industry-leading warranty and quality assurance.Each unit undergoes rigorous testing,including thermal cycling,load testing,and EMC(Electromagnetic Compatibility)checks,to meet international standards.It comes with a 12-month warranty covering defects in materials and workmanship.YASKAWA’s global technical support provides expert assistance for installation,tuning,and troubleshooting,ensuring optimal performance.Additionally,training programs and documentation are available to help users maximize the drive’s capabilities,ensuring long-term reliability in industrial motion control systems.
