Description

CACR-SR15SB1AF Technical Specifications

Product Model:CACR-SR15SB1AF(usually with version number such as#111#)

Manufacturer:YASKAWA(Yaskawa Electric)

Product Type:AC Servo Drive/Servo Amplifier(Servopack)

Series:Yaskawa CACR-SR Series

Input Power:Three-phase AC 200-230V,50/60Hz

Rated Output Power:1.5 kW(KW)

Rated Output Current:11.4 A(Ampere)

Compatible Motors:Yaskawa USAMED-15M or VS-800 Series compatible servo motors

Control Mode:Supports speed control,position control and torque control

Feedback Type:Usually supports incremental encoder feedback

Control Interface:Analog Command Input,Pulse Train Command Input,etc.

Built-in protection functions:overcurrent,overvoltage,undervoltage,overload,encoder failure,overspeed,regenerative resistor abnormality and other protections

Installation method:base installation

Working environment temperature:0°C to+40°C

Protection level:usually IP20

Cooling method:natural cooling or fan-assisted cooling

Dimensions:Please refer to the product manual for specific dimensions,usually industrial standard module dimensions

Life:Key electronic components(such as electrolytic capacitors and relays)have an expected lifespan

CACR-SR15SB1AF Product Overview

Boss,today we are talking about the YASKAWA CACR-SR15SB1AF Servopack,which is a well-known name in the Yaskawa servo product line.It is a medium-to-high power servo drive in the classic CACR series of Yaskawa,designed for industrial applications that require precise control,fast response and high power output.You can think of it as a”powerful engine”and”precise commander”that drives the servo motor to”charge into battle”.It is responsible for converting the instructions issued by the upper controller(such as PLC,motion controller or CNC system)into precise current and voltage to control the position,speed and torque of the servo motor,so that the mechanical equipment can achieve”silky smooth”movement.

The rated power of this YASKAWA CACR-SR15SB1AF reaches 1.5kW,which means that it can drive servo motors with larger loads and is suitable for a wider range of application scenarios.It is usually used with Yaskawa’s own USAMED series or VS-800 series servo motors to form a”golden partner”motion control system.Whether it is automation equipment that requires fast positioning,CNC machine tools that require high-precision trajectory control,or multi-axis coordinated robot systems,CACR-SR15SB1AF can provide stable and reliable performance output to ensure that your production process is efficient and smooth,with accurate accuracy.

Main features and advantages

The reason why YASKAWA CACR-SR15SB1AF can”stand firm”in the market is that it relies on its”real skills”:

First,it has moderate power and excellent performance.The rated output power of 1.5kW is a very common configuration in small and medium-sized industrial equipment,which can meet the motion control needs of most medium-loads.With Yaskawa’s advanced control algorithm,CACR-SR15SB1AF can achieve extremely high position accuracy(Position Accuracy)and repeatability(Repeatability),which is simply the”lifeline”for the precision manufacturing industry.It can make your equipment move”steady,accurate and ruthless”without”deviation”or”shaking”.

Secondly,the dynamic response speed is fast.The response speed of this driver to the command is so”rapid”,which can make the servo motor reach the target speed or position in the shortest time.In situations where frequent acceleration and deceleration and fast switching of actions are required,such as high-speed pick-and-place robots or automatic feeding systems,the fast response characteristics of YASKAWA CACR-SR15SB1AF can significantly improve the operating cycle time of the equipment and directly improve your production efficiency.It is not a”slow”player,it is definitely a”fast shooter”!

In addition,it is highly reliable and durable.As a world-renowned servo system supplier,Yaskawa’s product quality has always been”well-known”.CACR-SR15SB1AF inherits Yaskawa’s consistent”sturdy and durable”gene,with strict internal component selection and complete protection functions,such as overload protection,overvoltage protection,short circuit protection,etc.,which greatly enhance the stability and life of the drive in harsh industrial environments.Even in an environment with large temperature fluctuations and strong electromagnetic interference(EMI),it can be”as stable as a mountain”.

Another point is compatibility and ease of maintenance.As a classic product,YASKAWA CACR-SR15SB1AF has a large market share,and the corresponding compatible motors,connecting cables and technical information are relatively complete.For old equipment that is still running the CACR series servo system,if a fault occurs,it can find original spare parts or high-quality substitutes for replacement,avoiding the huge cost and downtime of the entire system upgrade.For many companies,this is simply a”life-saving straw”and greatly reduces maintenance costs.

The YASKAWA CACR-SR15SB1AF Servopack excels in delivering precise and powerful motion control for a diverse range of industrial applications.Its 1.5kW output capacity makes it highly versatile for medium-load requirements,while Yaskawa’s advanced control algorithms ensure exceptional position and speed accuracy,crucial for high-precision manufacturing processes.This drive enables machinery to execute intricate movements with remarkable stability and repeatability,directly impacting product quality.

A key advantage is its rapid dynamic response.The CACR-SR15SB1AF can quickly accelerate,decelerate,and settle to target positions,significantly boosting cycle times in applications demanding frequent changes in motion,such as automated material handling and packaging lines.This agility translates directly into enhanced productivity and operational efficiency.Furthermore,Yaskawa’s reputation for robust engineering is evident in the CACR-SR15SB1AF.It incorporates comprehensive protection features—including overload,overvoltage,and short circuit protection—which collectively ensure extended operational longevity and reliable performance even in harsh industrial environments.Its enduring design reduces the risk of unexpected downtime and contributes to a lower total cost of ownership.For existing systems utilizing the CACR series,the availability of replacement CACR-SR15SB1AF units provides a cost-effective solution for maintenance and longevity,avoiding the need for extensive system overhauls.

Application Areas

This YASKAWA CACR-SR15SB1AF servo drive,with its”big heart”and”embroidery needle”precision,is”blooming everywhere”in the field of industrial automation,and its application scenarios are very wide.

First of all,**CNC Machine Tools**is its”home base”.Whether it is a lathe,milling machine,grinder,or machining center,it is indispensable for those who need to accurately control the tool trajectory and workpiece feed.CACR-SR15SB1AF can drive the spindle and each axis motor to ensure that the machining accuracy meets the requirements and make your product”accurate”.

Secondly,in the field of industrial robots,although many robots now use newer servos,you can still see YASKAWA CACR-SR15SB1AF on many old robot joints and motion axes.It provides stable power and precise control for robots,enabling complex path planning and high-precision grasping and placement tasks.

Furthermore,**Packaging Machinery**and Printing Machinery**are also its”forte”.High-speed packaging lines and precise printing registration require servo drives to control the synchronization and positioning of components such as conveyor belts,rollers,and cutters.CACR-SR15SB1AF can ensure smooth and efficient production processes,exquisite product packaging,and accurate printing color registration.

In addition,in semiconductor manufacturing equipment,electronic assembly equipment,textile machinery,and material handling and positioning systems on some automated production lines,as long as there are high requirements for motion speed,position accuracy,and dynamic performance,this YASKAWA CACR-SR15SB1AF can find its place and become an indispensable”power source”on your production line.

Selection Guide/Purchase Recommendations

For all the bosses who want to buy YASKAWA CACR-SR15SB1AF,I,an”old man”,have a few”heartfelt words”,you have to listen carefully.

After all,this CACR-SR15SB1AF is a classic model of Yaskawa,and it is relatively old.Now the new original stock on the market is”rare”,almost extinct.If you look for a brand new one,it is basically”looking for a needle in a haystack”.Therefore,in most cases,what you can buy are professionally refurbished spare parts(Refurbished Parts)or used disassembled parts(Used Parts)in good condition.At this time,choosing a reliable supplier becomes the”top priority”.You have to find a manufacturer or trader like us,Shenzhen Changxin,who has a professional testing platform,maintenance experience,and dares to give a warranty,so that you can ensure that the YASKAWA CACR-SR15SB1AF you buy is fully functional and up to standard,so that you can use it with confidence and avoid detours.

Secondly,when confirming the model,in addition to the main model CACR-SR15SB1AF,if there are additional suffixes on the module,such as the”#111#”or”YXXX”you mentioned,it is best to provide us with this information.Although they are usually internal codes,they may sometimes involve minor functional differences or firmware versions.The more detailed the information provided,the greater the chance that we can help you find a fully matched CACR-SR15SB1AF.Finally,don’t forget to confirm your existing servo motor model and encoder type to ensure that the newly purchased drive can”seamlessly connect”with them and can be used directly after installation,saving worry and effort!

FAQ

Q:What does”Servopack”of YASKAWA CACR-SR15SB1AF mean?

A:”Servopack”is a unique name given by Yaskawa Electric to its own servo drive(or servo amplifier).It emphasizes the concept of the drive and servo motor as a whole system,not just a simple
