Description

Main Features and Advantages

The Yaskawa CACR-SR12TB6CSE ServoPack is designed for precision and durability in industrial automation.Its analog input supports seamless integration with CNC controllers and PLCs,providing precise speed and torque control for applications like robotic arms and machining centers.The through-hole mounted(TB)design optimizes cabinet space and simplifies installation,reducing setup time by 20%.Its high-efficiency power delivery likely reduces energy consumption by 10%compared to similar servo drives.

High performance and reliability:The servo drive employs advanced control algorithms for smooth operation,achieving positioning accuracy within 0.01 degrees(based on CACR-SR series standards).Its robust construction withstands vibrations up to 4.9 m/s²(0.5G)and ensures a 10-year service life,minimizing maintenance costs by 15%.Built-in diagnostics detect issues like overcurrent,overheating,or encoder errors,reducing fault-related downtime by 18%.

Service and support:As a discontinued product,repair services from providers like Redrive Inc.,Radwell,and MRO Electric offer free evaluations,full refurbishing,and testing with suitable servomotors,with a 2-year warranty on refurbished units.Repair costs start at approximately$700,and same-day exchange options ensure operational continuity,reducing turnaround time by 25%.

Application Field

The Yaskawa CACR-SR12TB6CSE is ideal for applications requiring precise motion control.In CNC machining,it drives spindle and axis motors,improving cutting accuracy by 15%in automotive part production.In robotics,it powers articulated arms for high-speed assembly,achieving 20%improved cycle times,as seen in Asian automotive plants.Its reliability supports aerospace applications,controlling actuators in testing equipment with 18%enhanced system uptime.

The module’s compatibility with legacy systems facilitates upgrades in manufacturing plants,cutting retrofit costs by 25%.In semiconductor production,it ensures precise wafer handling,reducing defects by 2%.From packaging lines to textile machinery,the Yaskawa CACR-SR12TB6CSE delivers consistent performance in high-precision automation tasks across various industries.

Related Products

Yaskawa CACR-SR10SZ1SF:Servo Drive,1.0 kW,200 VAC,VS-800 Series,Analog Input.

Yaskawa CACR-SR15BE12G-E:Servo Drive,1.5 kW,200–230 VAC,Analog Input.

Yaskawa CACR-SR20SB1BF-Y100:Servo Drive,2.0 kW,200–230 VAC,HR Series.

Yaskawa CACR-SR03BE12M:Servo Drive,0.3 kW,200 VAC,Analog Input.

Bently Nevada 3500/22M 288055-01:Transient Data Interface,for machinery monitoring.

Triconex 4351B:Communication Module,for safety-critical systems.

Honeywell 51305072-300 CLCN-B:I/O Card,for TDC 3000 DCS connectivity.

ABB KUC711AE 3BHB004661R0001:Power Supply Module,for excitation control.

Installation and Maintenance

Pre-installation preparation:Installing the Yaskawa CACR-SR12TB6CSE requires a stable 200–230 VAC,3-phase power source.Ensure the control cabinet meets IP20 standards with 50 mm ventilation clearance.Mount the module securely with a torque of 0.4–0.6 Nm and verify grounding resistance below 5Ω.Use shielded cables for analog inputs and motor connections to minimize interference.Configure settings using Yaskawa’s programming tools,ensuring compatibility with the CNC or robotic controller.Employ ESD precautions,such as wrist straps,to protect electronics.

Maintenance recommendations:Inspect connections semi-annually for wear or corrosion.Clean the control cabinet with compressed air to maintain IP20 protection.Use diagnostic tools to monitor performance and detect faults like overcurrent or encoder errors(e.g.,A02 error for missing parameters).Follow repair service checklists(e.g.,Redrive’s HOW_TO_CHECK_SERVO_PACK.pdf)to verify functionality before sending for repair,potentially saving 30%in troubleshooting time.Store spare units in a dry environment(-20°C to+85°C)to prevent moisture damage.Regular maintenance ensures a 10-year lifespan,reducing downtime by 15%.Common issues include overcurrent errors(Code 1)due to damaged output transistors or capacitors,requiring professional repair.

Product Guarantee

The Yaskawa CACR-SR12TB6CSE reflects Yaskawa Electric’s commitment to quality in industrial automation.Each unit is tested to meet CE,UL,and RoHS standards,ensuring reliable performance in demanding applications.As a discontinued product,it is supported by repair services from providers like Redrive Inc.,Radwell,and MRO Electric,offering a 2-year warranty on refurbished units,covering defects with prompt repair or replacement.Our 24/7 global technical support team provides expert guidance on installation,configuration,and troubleshooting.With fast delivery within 1–3 days from robust inventories,choose the Yaskawa CACR-SR12TB6CSE for trusted quality and unwavering support in precision motion control.
