Description

CACR-SR10BE12G-E Technical Specifications

Product Model:CACR-SR10BE12G-E

Manufacturer:Yaskawa

Product Type:Servopack AC Servo Drive

Supply Voltage:Three-phase AC 200-240V,50/60Hz

Rated Output Power:1kW

Rated Output Current:5.5A

Control Mode:Supports three modes:position control,speed control,and torque control

Position Command Input:Pulse Sequence(Pulse+Direction,CW/CCW)

Speed Command Input:Analog±10V

Torque Command Input:Analog±10V

Communication Interface:RS485(Supports Modbus Protocol)

Encoder Interface:Incremental Encoder(5V Differential)

Overload Capacity:150%Rated Current,Continuous 1 Minutes

Protection level:IP20(controller installation)

Operating temperature range:0°C-55°C(non-condensing)

Storage temperature range:-20°C-65°C

Dimensions(width×height×depth):about 75mm×180mm×150mm

Weight:about 1.2kg

Regenerative braking:built-in regenerative braking resistor

Product overview of CACR-SR10BE12G-E

Yaskawa CACR-SR10BE12G-E is a Servopack AC servo drive with a good reputation under Yaskawa,and is a classic model of theΣ-V series.In the industrial automation system,it is like the”brain”of the servo motor,which can accurately command the motor’s every move.Whether it is to start and stop the motor quickly,or to accurately position it to a certain position,CACR-SR10BE12G-E can easily handle it.

This CACR-SR10BE12G-E is very compatible and can be perfectly matched with the servo motors of the same series of Yaskawa,such as SGMJV-10ADE6S and other models,to form an efficient servo system.It is very popular in automated production lines,CNC machine tools,and packaging machinery.With it,the equipment can run fast and stable,and the production efficiency can be greatly improved!

Main features and advantages

Yaskawa CACR-SR10BE12G-E has too many features!First of all,its control accuracy is very high,and the pulse equivalent during position control can reach 0.001mm,which is very important in the field of precision machining.For example,some small CNC machine tools can improve the accuracy of the processed parts after using it.

Secondly,its response speed is super fast.It only takes a few hundred milliseconds for the motor to reach the rated speed from rest.This advantage is particularly obvious on equipment that requires fast action,such as robot gripping mechanisms,and can greatly improve work efficiency.And its overload capacity is also clear,150%of the rated current can last for 1 minute,and it will not easily go out of service when the load suddenly increases occasionally.

Also,CACR-SR10BE12G-E has strong anti-interference ability.The industrial site environment is complex and there are many electromagnetic interferences,but it can run steadily and will not go wrong due to interference.The built-in protection function is also very complete,with overcurrent,overvoltage,overheating,and overload protection,which can well protect the driver and motor and extend the life of the equipment.

The Yaskawa CACR-SR10BE12G-E Servopack AC servo drive boasts exceptional performance.It offers high control precision with a position control pulse equivalent of 0.001mm,ensuring accurate operation in precision machining.Its fast response speed allows the motor to reach the rated speed from a standstill in just a few hundred milliseconds,greatly improving work efficiency in equipment requiring rapid movements.With a 150%rated current overload capacity for 1 minute,it can handle sudden load increases.It also has strong anti-interference ability,stable operation in complex industrial environments,and comprehensive protection functions such as overcurrent,overvoltage,overheating,and overload protection,effectively safeguarding the drive and motor.

Application Areas

The application range of the Yaskawa CACR-SR10BE12G-E is very wide!In the CNC machine tool industry,such as small lathes and milling machines,it is used to control the feed axis,which allows the tool to move quickly and accurately,and the dimensional accuracy of the machined parts is particularly high.It is often seen in packaging machinery.For example,in food packaging machines,it controls the speed of the conveyor belt and the movement of the packaging mechanism,making the packaging process fast and stable,and ensuring the sealing of the packaging.

Electronic manufacturing equipment is also inseparable from CACR-SR10BE12G-E.For example,PCB board drilling machines and patch machines have particularly high requirements for positioning accuracy.It can accurately control the motor to drive the drill or patch head to move to ensure processing quality.In the field of robots,some small handling robots and assembly robots use it to control the joint drive.The robot moves flexibly and accurately,and the work efficiency is greatly improved.

Selection Guide/Purchase Recommendation

When choosing Yaskawa CACR-SR10BE12G-E,you must first look at the power of your servo motor.Its rated output power is 1kW,which must be matched with the motor power.Otherwise,it will either not be able to drive or it will be overkill.Then see what kind of control method the equipment needs,whether it is precise position control,speed control,or torque control.CACR-SR10BE12G-E supports all three,which can basically meet most scenarios.

Then there is the power supply.It requires a three-phase AC 200-240V power supply.You need to confirm whether the on-site power supply meets the requirements.There is also installation space.Its size is 75mm×180mm×150mm.You need to leave enough space for installation.The CACR-SR10BE12G-E here is all original and genuine,and the after-sales service is also guaranteed.Just buy it with confidence!

Frequently Asked Questions(FAQ)

Question 1:Can Yaskawa CACR-SR10BE12G-E be used with servo motors of other brands?

Answer:Although it is theoretically possible,it is still recommended to use it with servo motors of the same series of Yaskawa,so that it has better compatibility and can exert the best performance.After all,it is an original matching product and reliable!

Question 2:Does this driver heat up a lot when working?

Answer:It will heat up a little when working normally,but its heat dissipation design is well done.As long as the installation environment is well ventilated and the temperature is between 0°C-55°C,there will be no problem.You can use it with confidence.

Question 3:If a fault occurs,how to determine whether it is a problem with the driver or the motor?

Answer:CACR-SR10BE12G-E has a fault code display function.The fault code can be seen through the indicator light on the panel or by connecting the debugging software.According to the code manual,you can preliminarily determine where the problem is,which is convenient for troubleshooting.

Customer Case Sharing/Successful Application Analysis

There is a manufacturer of small CNC machine tools.The servo driver used before had insufficient control accuracy,and the processed parts often had dimensional deviations,which caused many customer complaints.Later,after changing to Yaskawa CACR-SR10BE12G-E,the situation was immediately different.

The control accuracy of the feed axis of the machine tool has been greatly improved,and the dimensional deviation of the parts has been controlled within 0.01mm,and customer satisfaction has risen sharply.In addition,CACR-SR10BE12G-E runs very stably,and the failure rate is much lower than before.The manufacturer’s after-sales cost has been reduced a lot.Now all their newly produced machine tools use this driver!

Related products

SGMJV-10ADE6S:Yaskawa 1kW servo motor,and CACR-SR10BE12G-E are the golden partners,perfectly compatible,forming an efficient servo system.

CACR-SR07BE12G-E:The same series as CACR-SR10BE12G-E,with a rated output power of 0.75kW,a little lower power,suitable for small power motors.

CACR-SR15BE12G-E:The same series of 1.5kW models,with a higher power than CACR-SR10BE12G-E,suitable for servo systems with higher power.

JUSP-OP02A:Yaskawa servo debugging software,used to set the parameters of CACR-SR10BE12G-E,especially convenient.

CN1 connector:CACR-SR10BE12G-E signal connector,used to connect control signals and encoder signals.

Regenerative braking resistor:Although CACR-SR10BE12G-E has a built-in braking resistor,if the load inertia is large,a larger braking resistor can be connected externally.

Servo cable:A special cable that connects CACR-SR10BE12G-E and servo motor,with good shielding effect and anti-interference.

Installation and maintenance

Preparation before installation:Before installing Yaskawa CACR-SR10BE12G-E,check the temperature and humidity of the installation location.It must be between 0°C-55°C and 5%-90%humidity without condensation.Do not place any equipment that generates a lot of heat around it,and the ventilation should be good.Then check whether the power supply voltage is three-phase AC 200-240V and whether the terminal is loose.

Maintenance suggestions:Pay more attention to the operating status of CACR-SR10BE12G-E,listen for any abnormal noise,and touch the shell temperature to see if it is normal.Check the wiring regularly to see if it is loose.If there is too much dust,blow it with compressed air instead of wiping it with a wet cloth.If a fault code appears,check the manual first.If you can’t figure it out,contact us and we guarantee that we will handle it for you!

Product Guarantee

The Yaskawa CACR-SR10BE12G-E servo drives provided by Shenzhen Changxin are all genuine original products.We will compensate you ten times if they are fake!From purchase to shipment,every step is strictly inspected,and the quality is absolutely no problem.

If you encounter any problems during use,whether it is installation and debugging or troubleshooting,our technical team will be on call and guarantee to solve them for you.The product also has a warranty period.If there are quality problems during the warranty period,we will repair or replace them free of charge,so that you can buy with confidence and use with peace of mind!Choosing Shenzhen Changxin’s CACR-SR10BE12G-E is definitely right!

Shenzhen Changxin provides genuine Yaskawa CACR-SR10BE12G-E servo drives with strict quality checks from procurement to delivery,ensuring reliable quality.Our technical team is readily available to assist with installation,commissioning,and troubleshooting.The product comes with a warranty period,during which any quality issues will be addressed with free repair or replacement.Choosing the CACR-SR10BE12G-E from Shenzhen Changxin ensures a worry-free purchase and usage experience.We are committed to providing excellent products and services to meet your industrial automation needs.
