SIEMENS 6ES5457-7LA11 SIMATIC S5 Digital Output Module 32 Channels

Product Overview

The SIEMENS 6ES5457-7LA11 is a high-density floating digital output module from the SIMATIC S5 programmable logic controller series, specifically engineered to provide 32 independent output channels for legacy industrial automation systems. This module, also referenced as 6ES5 457-7LA11, is part of the 457 sub-series and is primarily designed for integration with the S5-115U PLC platform, compatible with both central and expansion racks. The SIEMENS 6ES5457-7LA11 converts CPU logic commands into field-ready 5V or 24V DC signals, making it ideal for driving low-power loads such as LED indicators, optocoupler inputs, and solid-state relay control circuits.

A defining characteristic of the SIEMENS 6ES5457-7LA11 is its floating output architecture, which provides galvanic isolation between the control logic and field circuits. Each group of eight output channels is isolated from the S5 backplane bus via high-quality optocouplers, protecting the CPU from electrical disturbances originating in the field and allowing the SIEMENS 6ES5457-7LA11 to operate reliably in environments where power supplies may have different reference potentials. The module’s dual voltage compatibility—supporting both 5V DC (TTL-compatible) and 24V DC industrial standards without configuration changes—makes the SIEMENS 6ES5457-7LA11 exceptionally versatile, eliminating the need for separate modules for different logic families. With 32 outputs packed into a standard S5 form factor and a weight of approximately 0.89 kg, the SIEMENS 6ES5457-7LA11 delivers an optimal balance of density, reliability,

Category: FUJI

Contact Us WhatsApp / Wechat：+8618150087953
Phone：+86 18150087953
Email：sales@cxplcmro.com

Description

Technical Specifications

Parameter Name	Parameter Value
Product Model	6ES5457-7LA11 (also 6ES5 457-7LA11)
Manufacturer	Siemens
Product Type	Digital Output Module (Floating / Transistor)
Series	SIMATIC S5 (457 Sub-series)
Compatible Systems	S5-115U (Central and Expansion Racks)
Number of Outputs	32 Channels
Output Voltage	5V DC / 24V DC (Floating, user-supplied)
Output Current per Channel	0.1 A (100 mA)
Output Type	Floating (Optocoupler Isolated)
Isolation	Photocoupler, groups of 8 channels
“0” Signal Residual Current	≤ 0.5 mA
Switching Frequency (Resistive Load)	≤ 100 Hz
Power Loss (Typical)	Approx. 18 W (full load)
Current Consumption (CPU)	Approx. 6 mA
Operating Temperature	0°C to +60°C
Protection Rating	IP20
Module Weight	Approx. 0.89 kg
Commodity Code	85389091

Main Features and Advantages

The SIEMENS 6ES5457-7LA11 delivers exceptional value through its unique combination of high-density 32-channel output architecture and floating isolation, making it a reliable choice for legacy S5-115U systems. One of the standout features of the SIEMENS 6ES5457-7LA11 is its dual-voltage compatibility—supporting both 5V DC and 24V DC output levels. This dual-voltage capability is not merely about voltage tolerance; the SIEMENS 6ES5457-7LA11 achieves this through a floating output structure where each channel’s output level is determined by the external load power supply. This design enables the SIEMENS 6ES5457-7LA11 to simultaneously drive 5V TTL logic circuits and 24V industrial relays from a single module, eliminating the need for level converters and simplifying cabinet wiring.

The floating isolation architecture of the SIEMENS 6ES5457-7LA11 significantly enhances system robustness. Each group of eight output channels is galvanically isolated from the S5 backplane via optocouplers, with the field-side power supplied from an external source independent of the CPU power. This isolation is essential in environments with multiple power supplies or where ground potential differences exist—common challenges in large distributed control systems. The SIEMENS 6ES5457-7LA11 prevents these ground potential differences from damaging the CPU or causing erratic signal behavior, improving long-term reliability.

Furthermore, the SIEMENS 6ES5457-7LA11 provides visual status feedback through integrated LEDs, simplifying commissioning and troubleshooting. With switching frequencies up to 100 Hz for resistive loads, the SIEMENS 6ES5457-7LA11 is well-suited for high-frequency signaling applications, including fast sequencing, PWM-style signaling, and rapid indicator control. Despite its 32-channel density, the SIEMENS 6ES5457-7LA11 maintains a compact footprint, allowing efficient use of rack space. For facilities still operating S5-115U systems, the availability of the SIEMENS 6ES5457-7LA11 through the aftermarket provides a critical pathway to extend equipment life without the costly and complex migration to newer PLC platforms.
