Siemens 6ES5456-7LA11 SIMATIC S5 Digital Output Module — 16-Channel 115/230V AC, 1A, Floating, for S5-115U

Product Overview

The 6ES5456-7LA11 is a floating (galvanically isolated) 16-channel digital output module within Siemens’ SIMATIC S5 family, purpose-built for the S5-115U central rack and also deployable in S5-115F (fail-safe) configurations. Where the compact S5-90U/100U machines rely on low-voltage DC I/O, the 6ES5456-7LA11 serves the heavier-duty tier of the S5 ecosystem: directly switching 115 V AC or 230 V AC field loads at up to 1 A per channel, without interposing relays, by way of internal triac/thyristor AC semiconductor switches with optocoupler isolation. This positions the 6ES5456-7LA11 as the workhorse AC output card for process-line S5-115U racks that drive motor contactor coils, solenoid valves, indicator beacons, tower lights, heater bands, and other mains-referenced actuators common in 1990s-vintage process and batch installations.Electrically, the 6ES5456-7LA11 arranges its sixteen outputs into four groups of four, each group galvanically isolated from the backplane via optocouplers and protected by a 10 A fast-acting (FF) fuse. A red group LED flags a blown fuse, giving maintenance staff immediate visual fault localisation — a design choice that reflects the module’s target environment: process skids and machine centres where a single shorted contactor coil can take down an entire output group if undetected. The module draws approximately 70 mA from the S5 rack’s 5 V backplane and dissipates around 16 W (loss across the triacs and series protection), with a tested isolation rating of 1500 V AC and a VDE 0160 continuous rating of 250 V AC. Permissible load voltage spans 89–264 V AC (47–63 Hz), covering both 115 V and 230 V global mains standards on the same card — a flexibility that made the 6ES5456-7LA11 popular in multinational plants running mixed-voltage panel designs.Like most of the S5-456 AC output range, the 6ES5456-7LA11 has been placed on Siemens’ product lifecycle as discontinued (PM410 class, spare-part only, no direct successor), yet remains in steady demand because S5-115U central racks still govern countless extrusion lines, batch reactors, water-treatment stages, and legacy material-handling cells that owners elect to keep running. For those plants, the 6ES5456-7LA11 represents a form-fit-function spare whose electrical behaviour — 1 A continuous, ~10 Hz max switching, 3–5 mA “0” leakage, 1000 m shielded / 300 m unshielded cable reach — is fully characterised in Siemens S5 hardware manuals and unchanged across decades of production.

Category: FUJI

Contact Us WhatsApp / Wechat：+8618150087953
Phone：+86 18150087953
Email：sales@cxplcmro.com

Description

Technical Specifications

Parameter	Value
Product Model	6ES5456-7LA11
Manufacturer	Siemens (SIEMENS AG)
Product Type	Digital Output Module (AC, Floating / Optocoupler Isolated)
Series / Platform	SIMATIC S5 — S5-115U / S5-115F central rack (S5-456 family)
Output Channels	16 (arranged as 4 groups × 4 channels)
Load Voltage	115 / 230 V AC, 47–63 Hz; permissible range 89–264 V AC
Rated Output Current	1 A per channel (25 W lamp load @ 115 V; 50 W @ 230 V)
Output Element	Triac / thyristor AC semiconductor switch
“0” State Leakage Current	3–5 mA
Group Isolation	Optocoupler, 1500 V AC tested; VDE 0160 rated 250 V AC
Short-Circuit Protection	10 A FF fuse per group (e.g. Wickmann 19231 type)
Fault Indication	Red LED per group (blown-fuse flag)
Max Switching Frequency	~10 Hz
Cable Length (Shielded / Unshielded)	1000 m / 300 m
Backplane Current (5 V)	~70 mA
Power Loss	~16 W
Weight	~1.1 kg (≈1.278 kg per Siemens commodity listing)
Commodity Code	85389091
PLC Lifecycle Status	PM410 — Product cancelled, spare-part only, no official replacement
Front Connector	20-pole (e.g. 6ES5752-0AA22)

Main Features and Advantages

AC semiconductor switching eliminates contact wear.Unlike relay-output modules that suffer contact pitting and eventual welding under inductive AC loads, the 6ES5456-7LA11 uses triac/thyristor output stages to switch 115/230 V AC mains directly. This gives the module a silent, bounce-free switching characteristic with a typical ON/OFF response under 1 ms (practically limited to the next AC zero-cross by the triac turn-off behaviour). For plants driving solenoid valves, contactor coils, and heater bands in continuous 24/7 duty, the absence of mechanical contacts translates into significantly longer field life compared to electromechanical alternatives — one reason S5-115U racks with 6ES5456-7LA11 cards routinely run 20+ years before a spare swap is needed.Grouped optocoupler isolation with per-group fuse protection.Sixteen outputs sound like a lot to lose at once, so Siemens partitioned the 6ES5456-7LA11 into four independently fused groups of four. Each group is optocoupled from the S5 backplane (tested to 1500 V AC), and a 10 A FF fuse sits ahead of the group’s four triacs. A red LED on the module front flags a blown fuse on that group without requiring a rack diagnostics dive. On a live S5-115U, an electrician can see at a glance which group tripped, pull the 20-pole front connector, swap the fuse, and restore — no software intervention required. This group-level granularity is a genuine maintenance advantage over modules that fuse only at the card level.Dual-voltage flexibility on a single card.The 6ES5456-7LA11 accepts 115 V AC and 230 V AC loads on the same module (89–264 V AC permissible window, 47–63 Hz), selected simply by how the field wiring is referenced. For multinational OEMs and plants with mixed panel standards — e.g. 115 V contactor coils on US-spec lines and 230 V beacons on EU-spec ancillaries — one spare SKU covers both, reducing storeroom complexity. The 1 A per-channel rating handles typical control-coil and indicator loads comfortably; lamp loads are explicitly rated at 25 W (115 V) / 50 W (230 V) per channel.Long cable reach and noise immunity for distributed panels.Shielded cable runs up to 1000 m and unshielded up to 300 m are supported, unusual for an AC output card and a direct consequence of the triac’s robust drive capability and the optocoupler’s noise rejection. In large process bays where the S5-115U central rack sits in a MCC room while valves and motor starters are hundreds of metres away, the 6ES5456-7LA11 can drive those loads without intermediate repeaters — provided the 10 A group fuse and cable cross-section are correctly specified.
