Description
Application Scenarios
In a recent automotive assembly line upgrade, control engineers faced persistent voltage sag issues that caused PLC resets and production stoppages when high-power motors started across the facility. By deploying the Siemens 6EP1334-2BA01, the plant achieved stable 24 V DC power delivery with the module’s 15 A peak current capability instantly absorbing inrush loads without triggering protective shutdowns. The wide-range AC input (85-264 V) proved invaluable on the 208 V industrial supply, while the built-in PFC ensured compliance with harmonic limits and reduced upstream circuit breaker nuisance tripping.
The Siemens 6EP1334-2BA01 directly addresses the critical industrial pain point of electrical noise and supply fluctuations causing system instability. Its output voltage can be trimmed from 22.8 V to 28 V via an onboard potentiometer, allowing compensation for voltage drops over long cable runs to distributed field devices. The module’s constant-current short-circuit characteristic limits fault current to approximately 16 A, protecting downstream loads while automatically recovering when the fault clears.
Parameters
| Main Parameters | Value/Description |
|---|---|
| Product Model | 6EP1334-2BA01 |
| Manufacturer | Siemens |
| Product Category | AC-DC DIN Rail Power Supply |
| Input Voltage | 85-132 VAC / 170-264 VAC (wide range) |
| Input Frequency | 47-63 Hz |
| Output Voltage | 24 V DC (adjustable 22.8-28 V) |
| Output Current | 10 A continuous / 15 A peak |
| Output Power | 240 W |
| Efficiency | ~91% (typ.) |
| Ripple & Noise | < 150 mV (residual ripple) |
| Overvoltage Protection | < 33 V |
| Short-Circuit Protection | Constant current characteristic (~16 A) |
| Dimensions (W×H×D) | 70 mm × 125 mm × 125 mm |
| Weight | ~0.8 kg |
| Mounting | DIN rail EN 60715 (35×7.5/15) |
| Operating Temperature | 0°C to +60°C (derating above +45°C) |
| Certifications | CE, cULus Listed (UL 508), CB, EAC |
Technical Principles and Innovative Values
- Innovation Point 1: Power Factor Correction (PFC) for Energy Efficiency. The Siemens 6EP1334-2BA01 integrates active PFC technology that shapes the input current waveform to follow the voltage waveform, achieving a near-unity power factor and minimizing reactive power draw. This innovation reduces harmonic distortion on the facility’s mains network, prevents nuisance tripping of upstream breakers, and enables the module to achieve 91% typical efficiency—significantly outperforming legacy linear supplies that waste up to 30% of input energy as heat.
- Innovation Point 2: Wide-Range Universal Input. Unlike competing power supplies that require manual voltage selector switches or separate models for 120 V and 230 V regions, the Siemens 6EP1334-2BA01 automatically accepts any voltage from 85 VAC to 264 VAC. This feature eliminates configuration errors during installation and makes it the ideal choice for OEM equipment destined for global markets, reducing inventory complexity and logistics costs.
- Innovation Point 3: High Peak Current Capability. The Siemens 6EP1334-2BA01 delivers 15 A peak current for brief periods, providing the extra surge capacity needed to start inductive loads like contactors, solenoids, and DC motors without requiring a higher-rated power supply. This overload reserve ensures system stability during transient events while maintaining the compact 70 mm footprint, offering a 50% higher power density than comparable solutions in its class.
