CACR-SR10SZ1SS Technical Specifications

Product Model:CACR-SR10SZ1SS

Manufacturer:YASKAWA(Yaskawa Electric)

Product Type:AC Servo Drive/Servo Amplifier(SERVOPACK)

Series:Yaskawa CACR-SR Series(usually used with USAMED/USAREM Series servo motors)

Input Power:Single-phase or three-phase AC 200-230V,50/60Hz

Rated Output Power:1.0 kW

Rated Output Current:Usually around 6A(specific current value depends on load and motor matching)

Compatible Motors:Yaskawa USAMED-10M and other M series or compatible servo motors

Control Mode:Supports speed control,position control and torque control

Feedback Type:Supports incremental encoder feedback

Control Interface:Analog Command(such as±10V),Pulse Train Command,etc.

Built-in Protection Functions:Overcurrent,overvoltage,undervoltage,overload,encoder failure,overspeed,etc.

Mounting Method:Base Mounting

Working Ambient Temperature:0°C to+40°C

Protection level:usually IP20

Cooling method:natural cooling or fan cooling(according to power level)

CACR-SR10SZ1SS Product Overview

My friends,the YASKAWA CACR-SR10SZ1SS we are talking about today is not an ordinary product.It is a”time-honored”product of Japan’s YASKAWA Electric Corporation in the field of servo control,and belongs to the classic CACR-SR series servo drive of Yaskawa.To put it bluntly,it is the”brain”and”power center”of the servo system,which is specially used to accurately control the position,speed and torque of the servo motor to ensure that your mechanical equipment can”point and hit”according to the instructions,move fast and stable,and the accuracy is high enough to”embroider”.

This YASKA1WA CACR-SR10SZ1SS servo drive mainly receives the command signal from the upper controller(such as PLC,motion controller or CNC system),and then accurately controls the speed and position of the motor after”some calculation”inside it.It is usually used with Yaskawa’s USAMED series or other compatible servo motors to form a complete servo motion control system.In those occasions where motion accuracy and dynamic response are particularly high,such as precision machine tools,robots,packaging machinery,printing equipment,etc.,this CACR-SR10SZ1SS is a”hot commodity”.Although it is an old model,it still performs well with Yaskawa’s”hard power”,and can make your equipment”move”brilliantly and”move”accurately!

Main features and advantages

Speaking of the YASKAWA CACR-SR10SZ1SS servo drive,it has been able to”make its way around the world”for so many years,relying on a few”brushes”:

First of all,its high-precision control capability is beyond doubt.Yaskawa’s technical accumulation in the servo field is not exaggerated.This CACR-SR10SZ1SS can enable the motor to achieve micron-level precision positioning and millisecond-level speed response.Whether it needs to start and stop quickly or reach a certain position accurately,it can complete the task steadily,which is a great help for CNC machine tools and automated assembly lines that require high-precision processing.It can control the error to the level of”hair”,making your product quality more guaranteed.

Secondly,it has fast dynamic response,just like a”flash”.This thing can quickly respond to changes in control instructions,such as from static to high-speed operation,and then from high-speed operation to instant stop.The whole process is called”clean and neat”,without any drag.This can greatly improve the production rhythm and increase production capacity in packaging machinery and printing machinery,which require frequent start and stop and rapid positioning.It is simply an accelerator for”money printing machines”!

In addition,high reliability is also a major advantage.Yaskawa’s products are famous for their”durable”quality,and the CACR-SR10SZ1SS is the same.It has built-in multiple perfect protection functions,such as overcurrent protection,overvoltage protection,overload protection,etc.,which can effectively prevent the module and motor from being damaged due to abnormal conditions,just like giving your equipment multiple”insurances”,making you feel more assured.Even in some harsh industrial environments,its performance is still stable and reliable.

In addition,it has good compatibility.Although CACR-SR10SZ1SS is an old model,it can perfectly match Yaskawa’s early USAMED series servo motors,which is a blessing for those factories that are still using old equipment.If your motor or drive is broken,you don’t have to replace the entire system.Just find a CACR-SR10SZ1SS of the same model to replace it,and it can be”resurrected”,which greatly saves your maintenance costs and time.

The YASKAWA CACR-SR10SZ1SS servo drive stands out for its exceptional precision control capabilities,a hallmark of Yaskawa’s long-standing expertise in servo technology.It enables accurate positioning down to micron levels and rapid speed response in milliseconds,essential for applications demanding high accuracy,such as CNC machine tools and automated assembly lines.This drive ensures that mechanical movements are not only precise but also consistently repeatable,significantly enhancing product quality.

Furthermore,its high dynamic response is a critical advantage.The CACR-SR10SZ1SS can quickly accelerate,decelerate,and change direction,providing the agility required for applications like packaging and printing machinery where frequent starts,stops,and precise positioning directly impact throughput.Its robust design incorporates comprehensive protective functions,including overcurrent,overvoltage,and overload protection,safeguarding both the drive and the connected servo motor from potential damage and ensuring reliable operation even in demanding industrial environments.This inherent durability translates to reduced downtime and lower maintenance efforts.Moreover,its compatibility with earlier Yaskawa Servo motors(e.g.,USAMED series)offer a cost-effective solution for maintaining and extending the lifespan of existing machinery,providing a reliable spare part option without requiring a full system overhaul.

Application areas

This YASKAWA CACR-SR10SZ1SS servo drive,with its”stable,accurate and ruthless”characteristics,is a”hot commodity”in the field of industrial automation,and has a wide range of applications.

First of all,CNC machine tools(CNC Machine Tools)are its”main business”.Regardless of whether it is a milling machine,lathe or grinder,it is needed to drive the spindle and feed axis to achieve precise positioning and high-speed cutting of the tool.Without a high-precision servo like CACR-SR10SZ1SS,your precision parts can be”out of the question”.

Secondly,in packaging machinery(Packaging Machinery)and printing machinery(Printing Machinery),this YASKAWA CACR-SR10SZ1SS is also a”main force”.Think about it,high-speed filling,sealing,labeling,and multi-color printing registration,which one does not need a servo drive to control rollers,conveyor belts,and nozzles?It can make the production line run very fast,while ensuring the consistency and quality of the product,greatly improving production efficiency.

In addition,industrial robots are also its”place of use”.The joint movement of the robot,the precise grasping and placement of the end effector,are inseparable from the support of the servo system.Although most new robots now use more advanced servos,you can still see the CACR-SR10SZ1SS on some old robot arms,which drives the robot arm to complete various complex and repetitive tasks.

In addition,in the fields of semiconductor equipment,electronic assembly equipment,textile machinery,etc.,as long as there are strict requirements on speed,position,and torque,this YASKAWA CACR-SR10SZ1SS can play its”residual heat”to escort your production and solve various”difficult and complicated problems”of motion control.

Selection Guide/Purchase Suggestions

For all the bosses who want to buy YASKAWA CACR-SR10SZ1SS,I,as an old hand,have a few suggestions.You must listen carefully.

After all,this CACR-SR10SZ1SS is a classic model of Yaskawa.There are not many new machines on the market now.Most of them are disassembled parts or professionally repaired spare parts.Therefore,when you buy,you must open your eyes and find a reputable and powerful supplier like us Shenzhen Changxin.The CACR-SR10SZ1SS we provide has been strictly tested to ensure that the functions are intact and the performance meets the standards.We can usually give you a good warranty period so that you can buy with confidence.

In addition,when selecting,you have to confirm its compatibility with your existing system.For example,is your servo motor model the USAMED series or other compatible with CACR-SR10SZ1SS?Does the input power supply voltage meet 200-230V AC?These are”hard indicators”and any difference will not work.If you are really unsure,take a picture of the nameplate information of your device,or tell me the model of the original faulty module.My engineering team here can give you free diagnosis and give the most professional selection suggestions to ensure that the YASKAWA CACR-SR10SZ1SS you buy can perfectly”take over”and make your production line”alive”immediately!

FAQ

Q:What does the string of characters”SZ1SS”in YASKAWA CACR-SR10SZ1SS mean?

A:Yaskawa’s model coding is usually more complicated.This”SZ1SS”in CACR-SR10SZ1SS represents the functional characteristics of the drive.Among them,”SZ”usually refers to the standard type,and the following”1SS”may involve specific configurations such as the number of power phases,control interface type(such as analog input)and encoder feedback type(such as incremental encoder).The detailed coding rules need to be consulted in the official product manual of Yaskawa for accurate interpretation.

Q:My YASKAWA CACR-SR10SZ1SS servo drive alarmed.Are there any common fault codes and solutions?

A:The fault code of CACR-SR10SZ1SS is usually displayed on the LED indicator or seven-segment digital tube on the drive panel.Common alarms include”overcurrent”,”overvoltage”,”encoder fault”,”overspeed”,”abnormal regenerative resistor”,etc.Each alarm has a corresponding fault code and recommended troubleshooting steps.For example,if it is overcurrent,you may need to check whether the motor or load is short-circuited;if it is an encoder fault,you may need to check the encoder wiring or the encoder itself.For specific troubleshooting,it is recommended that you refer to the troubleshooting section in the manual of Yaskawa’s CACR-SR series servo drive.If you can’t figure it out yourself,feel free to contact us in Shenzhen Changxin,we have a professional maintenance team to provide support.

Q:Can you still buy a brand new YASKAWA CACR-SR10SZ1SS now?

A:To be honest,YASKAWA CACR-SR10SZ1S
