Description
Description
The Schneider TSX Quantum 140 CPS 224 00 is a redundant DC power supply module designed for the Schneider Quantum automation system.Operating at 24V DC with an 8A output capacity,it ensures stable and reliable power for PLC racks and critical control modules.
Built for demanding automation environments,the Schneider 140 CPS 224 00 provides redundancy to minimize downtime and guarantee system availability in industrial operations.
Application Scenarios
In an oil refinery control room,uninterrupted power is essential for process controllers and I/O modules.The Schneider 140 CPS 224 00 ensures redundancy,so if one power source fails,the backup maintains seamless system operation.
In a water treatment facility,the Schneider 140 CPS 224 00 powers PLC racks that control pumps and valves.Its redundancy design significantly reduces the risk of outages,ensuring continuous operation and compliance with safety standards.
Parameter
Main Parameters Value/Description
Product Model 140 CPS 224 00
Manufacturer Schneider Electric
Product Category PLC Power Supply Module
Input Voltage 24V DC
Output Current 8A
Redundancy Yes,supports redundant power supply configuration
Compatibility Schneider Quantum PLC racks and modules
Mounting Rack-mounted,easy installation
Protection Overload and short-circuit protection
Operating Temperature-25°C to+60°C
Application Industrial automation,process control,energy,water treatment
Technical Principles and Innovative Values
Innovation Point 1:Redundant design ensures zero downtime in case of primary power supply failure.
Innovation Point 2:High 8A current capacity supports multiple PLC modules without voltage drops.
Innovation Point 3:Built-in electronic protection enhances equipment safety and reliability.
Innovation Point 4:Designed for seamless integration into Schneider Quantum PLC racks.
Application Cases and Industry Value
In a petrochemical plant,the Schneider 140 CPS 224 00 was deployed in redundant pairs to support Quantum PLC racks.Operators reported that the system maintained continuous control even during maintenance,avoiding production losses.
In a mining operation,the Schneider 140 CPS 224 00 provided stable power for distributed PLC nodes.The redundancy feature minimized downtime,ensuring maximum production efficiency under harsh working conditions.
Related Product Combination Solutions
The Schneider 140 CPS 224 00 works effectively with:
140 CPU 67160–Quantum CPU module for advanced control.
140 ACI 040 00–Analog input module for precision measurement.
140 ACO 020 00–Analog output module for process control.
140 DDI 353 00–Digital input module for field device signals.
140 DDO 353 00–Digital output module for actuator control.
140 CRP 931 00–Remote I/O head for distributed systems.
140 NOE 771 01–Ethernet network module for communication.
Together,these components form a complete and reliable Schneider Quantum automation solution.
Installation,Maintenance,and Full-Cycle Support
The Schneider 140 CPS 224 00 installs easily in the Quantum PLC rack,with simple wiring and redundancy setup.Its modular design allows fast replacement without interrupting operations.
Routine maintenance is minimal due to its robust construction and built-in protective circuits.In case of failure,redundant operation ensures continuity while engineers replace the faulty unit.
With Schneider’s global technical support and spare part availability,the Schneider 140 CPS 224 00 offers long-term reliability across industries requiring high-availability automation.
