Description

Application Scenarios

Imagine a large-scale manufacturing plant producing automotive parts.The production line is controlled by a Modicon Momentum system,which must manage dozens of motors,solenoids,and indicator lights.The system relies on modules like the 170ADO35000 to precisely control these devices.For example,a quality control station needs to activate a solenoid to divert a defective part.The PLC sends a digital”on”signal to the 170ADO35000,which then provides the necessary 24 VDC output to energize the solenoid.Without the reliable switching capabilities of the 170ADO35000,the entire production line could suffer from significant downtime,quality control issues,and reduced efficiency.

Parameter

Main Parameters Value/Description

Product Model 170ADO35000

Manufacturer Schneider Electric

Product Category Discrete Output Module

Output Type Solid State(Transistor)

Number of Points 16 points

Output Voltage 24 VDC(Source)

Current per Point 0.5 A(Maximum current a single output can handle)

Isolation 1500 VAC(Optical isolation between logic and field circuits)

Operating Temperature 0°C to 60°C

Communication Protocol Modbus,Modbus Plus,TCP/IP(Supported by the Momentum system)

Mounting DIN Rail or Panel Mount

Export to Sheets

Technical Principles and Innovative Values

Solid-State Switching:Unlike traditional relay outputs,the 170ADO35000 uses solid-state transistors for switching.This provides significantly faster switching speeds and a longer operational life by eliminating mechanical wear and tear,which is critical for high-frequency applications.

High-Density Design:With 16 output points in a compact form factor,the module offers a high I/O density.This allows for more outputs to be controlled from a smaller space,reducing the overall size and cost of the control cabinet.

Built-in Diagnostics:The module features diagnostic capabilities that can detect faults such as short circuits or overloads on the output lines.This helps in quick troubleshooting and reduces the mean time to repair(MTTR).

Electrical Isolation:The 170ADO35000 provides robust optical isolation between the internal controller circuitry and the external field wiring.This protects the sensitive control electronics from voltage spikes and noise originating from the field,enhancing system reliability and safety.

Application Cases and Industry Value

Case Study:Food and Beverage Bottling Line:A bottling plant required a control system to manage the various motors,valves,and conveyor belts.By integrating the Schneider Electric 170ADO35000 modules into their Modicon Momentum system,they were able to achieve a highly reliable and synchronized operation.The high-speed switching of the module enabled precise timing for filling valves,resulting in reduced spillage and increased production speed.User feedback highlighted the module’s ease of use and its contribution to reducing maintenance costs,as its solid-state outputs didn’t require frequent replacement like mechanical relays.

Case Study:Water Treatment Plant:A municipal water treatment facility used the 170ADO35000 modules to control various pumps,motor starters,and alarm beacons.The module’s robust design and electrical isolation were essential in protecting the control system from the electrical noise and harsh environmental conditions common in such facilities.The built-in diagnostics feature was particularly valuable,as it allowed technicians to quickly identify and address wiring faults,ensuring uninterrupted operation of the critical water supply infrastructure.

Installation,Maintenance,and Full-Cycle Support

The Schneider Electric 170ADO35000 module is designed for quick and easy installation on a DIN rail or panel.Its simple terminal block wiring and LED status indicators for each channel make initial setup and commissioning straightforward.The module’s robust design and solid-state outputs minimize the need for routine maintenance,as there are no moving parts to wear out.In the event of a fault,the diagnostic LEDs and system-level fault reporting help technicians quickly pinpoint the problem,reducing troubleshooting time.We offer full-cycle support for the 170ADO35000,including technical assistance for installation and configuration,as well as a reliable supply of replacement parts to ensure your system’s longevity.We are committed to providing the expertise and resources you need to keep your automation systems running smoothly and efficiently.Contact us for a customized solution.

140xts00200_schneider_electric_terminal_strip_40_points

10 SEO-Optimized Titles:

Schneider Electric 140XTS00200 Terminal Strip:The Essential Wiring Solution for Modicon Quantum

High-Density Wiring Base:140XTS00200 for 40-Point Quantum I/O Modules

Streamline Maintenance with the 140XTS00200 Removable Terminal Strip

Schneider 140XTS00200:The Reliable Connection for Industrial Automation

Maximize Uptime with the 140XTS00200 Terminal Strip for Modicon Quantum

The 140XTS00200:Your Foundation for Organized and Secure I/O Wiring

Schneider Electric 140XTS00200 Wiring Base:A Legacy of Durability and Ease of Use

Secure Connections:140XTS00200 Terminal Strip for Critical Industrial Control

The 140XTS00200:Simplifying I/O Module Replacement in Modicon Quantum Systems

140XTS00200 Terminal Strip:The Ultimate Solution for High-Density Field Wiring

Description:

The Schneider Electric 140XTS00200 is a high-quality,40-point terminal strip designed specifically for use with Modicon Quantum series I/O modules.This product is a crucial passive component,providing the physical interface for connecting field wiring to the I/O module.Its robust design and user-friendly features make it an essential part of any Modicon Quantum control system,ensuring reliable and organized connections.

Application Scenarios:

In a large-scale chemical processing plant,the control system is a complex network of Modicon Quantum PLCs managing hundreds of sensors and actuators.When a discrete I/O module fails,the priority is to get the process back online as quickly as possible.The plant relies on the 140XTS00200 terminal strips for its I/O modules.Because the terminal strip is a separate,removable block,a technician can simply unbolt the faulty I/O module and replace it with a new one,all without having to disconnect and re-wire the 40 individual field wires.The wiring remains perfectly intact on the 140XTS00200,turning what could be a time-consuming and error-prone repair into a swift,plug-and-play operation.This capability directly addresses the pain point of downtime,saving the company thousands of dollars in lost production.

Parameter:

Main Parameters Value/Description

Product Model:140XTS00200

Manufacturer:Schneider Electric

Product Category:Terminal Strip/Wiring Base

Number of Points:40 points

Wiring Type:Screw terminals

Compatibility:Modicon Quantum I/O modules(40-pin)

Wire Size:22 to 14 AWG(0.34 to 2.5 mm²)solid or stranded wire

Isolation:Provides no active isolation,but maintains the isolation of the connected module

Operating Temperature:0°C to 60°C

Connection Method:Removable terminal block

Mounting:Direct-mount on Modicon Quantum rack

Technical Principles and Innovative Values:

Removable Terminal Block Design:The core innovation of the 140XTS00200 is its removable nature.This design allows the terminal strip,with all its field wiring still attached,to be disconnected from the I/O module.This is a game-changer for maintenance,enabling hot-swapping and rapid module replacement without the risk of wiring errors or the need for a complete re-wiring process.

Robust Screw Terminals:The terminal strip features high-quality screw terminals that provide a secure,vibration-resistant connection.This is essential for ensuring reliable signal integrity in harsh industrial environments where machinery and equipment can cause constant vibration.

Organized and Clear Wiring:Each terminal point is clearly labeled,promoting neat and organized wiring.This greatly simplifies troubleshooting,as technicians can quickly identify and test specific wire connections,reducing diagnostic time and improving overall system reliability.

Application Cases and Industry Value:

Case Study:Automotive Assembly Line:An automotive plant needed a modular and reliable control system for its assembly line conveyors.By using Modicon Quantum PLCs with the 140XTS00200 for all its I/O modules,the plant was able to build a highly scalable and maintainable system.During a line expansion,new I/O modules were added quickly because the wiring could be prepared on the 140XTS00200 terminal strips in advance,minimizing the impact on production schedules.The modularity provided by the 140XTS00200 reduced commissioning time by over 30%and made future upgrades significantly easier.

Case Study:Power Distribution Substation:A power substation used Modicon Quantum to monitor and control various circuit breakers and relays.The reliability of the I/O connections was critical for safety and operational efficiency.The 140XTS00200’s robust screw terminals ensured that all field wiring was securely fastened,resisting vibrations from nearby transformers and circuit breaker operations.The easy-to-use design meant that during routine maintenance,technicians could quickly and safely verify connections without risking wiring errors,which enhanced the overall safety and reliability of the substation’s control system.
