Description

Application Scenarios

In a large-scale power generation facility,the GE DS200CTBG1ADD serves as a critical interface for analog signals,enabling precise monitoring of turbine parameters such as temperature and pressure.By ensuring accurate signal termination,it addresses common issues like signal degradation and data loss,making it essential for industries like power generation,petrochemical processing,and heavy manufacturing,where system reliability directly impacts operational efficiency.

Parameters

Main Parameters

Value/Description

Product Model

GE DS200CTBG1ADD

Manufacturer

General Electric

Product Category

Analog Termination Board(Mark V Series)

Signal Type

Analog Inputs/Outputs(Supports mA and voltage signals for versatile applications)

Number of Channels

32(High-density termination for multiple signals)

Connector Type

Terminal Blocks(TBQC)(Quick-connect for secure and efficient wiring)

Signal Conditioning

Built-in scaling and filtering(Ensures clean signal transmission)

Operating Temperature

-30°C to+65°C(Rugged design for extreme industrial conditions)

Dimensions

3.0 in x 11.0 in x 12.0 in(Compact for rack integration)

Communication Protocol

IONET(Seamless integration with Mark V control systems)

Weight

Approx.2.5 lbs(Lightweight for easy installation)

Mounting

Rack-mounted(Standard Mark V rack compatibility)

Technical Principles and Innovative Values

The GE DS200CTBG1ADD employs advanced signal termination technology to ensure robust performance in industrial control systems.Its key innovations include:

Innovation Point 1:High-Density Signal Termination–The GE DS200CTBG1ADD supports up to 32 channels,allowing simultaneous processing of multiple analog signals,reducing hardware footprint by 20%compared to similar boards.

Innovation Point 2:Advanced Signal Conditioning–Built-in scaling and filtering reduce signal noise by up to 30%,ensuring precise data for critical control applications.

Innovation Point 3:Quick-Connect TBQC Design–The terminal block quick-connect(TBQC)system simplifies wiring,cutting installation time by 15%compared to traditional termination boards.

Innovation Point 4:Environmental Resilience–Engineered for operation in temperatures from-30°C to+65°C,the GE DS200CTBG1ADD maintains performance in harsh environments,unlike standard modules that may fail under similar conditions.

Application Cases and Industry Value

In a petrochemical refinery,the GE DS200CTBG1ADD was integrated into a Mark V system to manage analog signals from pressure and flow sensors.Its high-density termination enabled precise monitoring of process parameters,reducing system errors by 20%and improving production uptime.Operators reported enhanced system stability and faster response times.In another case,a combined-cycle power plant utilized the GE DS200CTBG1ADD to interface with turbine control sensors,achieving a 12%improvement in fuel efficiency by ensuring accurate data for real-time adjustments.The module’s robust design was praised for maintaining performance during high-vibration operations.

Installation,Maintenance,and Full-Cycle Support

The GE DS200CTBG1ADD is designed for straightforward installation,featuring quick-connect TBQC terminal blocks that reduce wiring complexity and setup time by 15%.It mounts seamlessly into Mark V racks,requiring only standard power and signal connections.Its compact design(3.0 in x 11.0 in x 12.0 in)ensures compatibility with space-constrained environments,while its robust construction supports operation in temperatures from-30°C to+65°C.

Maintenance is simplified with diagnostic features like LED indicators for signal status,enabling rapid identification of issues.The GE DS200CTBG1ADD supports hot-swapping,allowing replacement without system downtime,and its firmware is configurable via Mark V software for easy updates.Our global support team offers 24/7 technical assistance,backed by a one-year warranty and access to an extensive spare parts inventory.Regular inspection of terminal connections and periodic calibration are recommended to maintain optimal performance.

Choose Shenzhen Changxin for worry-free after-sales service and high-quality products. We only cooperate with first-tier brand manufacturers in the industry. Our products are imported and comprehensive. We provide thoughtful pre-sales service, communicating multiple times with customers about product models, quality, prices, and delivery schedules to jointly confirm the solutions and address users’ concerns in advance. Business execution is in place, ensuring on-time delivery of ordered products and formulating a comprehensive delivery plan to guarantee the project schedule. We also assist users in handling acceptance procedures. Our after-sales service is impeccable. For any problems during the warranty period, we only replace, not repair. We never shirk responsibilities or pass the buck when encountering problems. Our service hotline is available 24/7: 18150087953
