Description
Application Scenarios
In the control cabinet for an automated assembly line, multiple sensor clusters, indicator lights, and small relay coils are scattered across several DIN rail-mounted terminal block rows. Supplying 24VDC power to each device individually with wire jumpers creates a messy, unreliable “rat’s nest” of wiring that is prone to errors, difficult to troubleshoot, and a maintenance nightmare. The ABB SAFT166APC power connection board solves this elegantly. Mounted centrally on the DIN rail, it acts as a power distribution backbone. Its integrated bus bars allow a single, thick cable from the main 24VDC power supply to be connected once. Then, via pluggable connectors or bus bridging components, clean and organized power is distributed horizontally to each row of SAFT 166 terminal blocks. This architecture, centered on the SAFT166APC, eliminates dozens of point-to-point wires, reduces wiring time by over 30%, minimizes connection errors, and provides a clear, maintainable power distribution structure that enhances overall cabinet reliability and safety.
Parameter
| Main Parameters | Value/Description |
|---|---|
| Product Model | SAFT166APC |
| Manufacturer | ABB |
| Product Category | Power Connection & Distribution Board / Interface |
| Compatible Series | ABB SAFT 166 Terminal Block System |
| Rated Voltage | Up to 300V AC/DC |
| Rated Current | High current capacity (e.g., 41A or 57A) for main power bus (Defines total power capacity for the section) |
| Number of Connection Points | Multiple positions for plug-in power feeders and jumpers |
| Connection Technology | Screw clamp or spring-cage connection for main power input; plug-in bus connection for distribution |
| Bus Material | High-conductivity copper alloy, tin-plated for reliability |
| Mounting | DIN Rail mounting (35mm, TS35) |
| Cross-Section (Input) | Accepts large gauge wires (e.g., up to 10mm² / 8 AWG) for main power feed |
| Safety Standards | Compliant with IEC/UL standards for terminal blocks and electrical components |
| Color Coding | Typically black or dark gray, distinct from standard terminal blocks |
