NI SCXI-1300

Description

NI SCXI-1300 is a high-performance,multi-function signal conditioning module from National Instruments(NI).The following is a detailed introduction to it:

I.Product Overview

The NI SCXI-1300 module belongs to the SCXI(Signal Conditioning for XI)series and is a signal conditioning and switching platform designed for measurement and automation systems.The module provides a variety of signal conditioning functions,including voltage measurement,signal isolation,analog output,and digital I/O,and is suitable for various test,measurement,and control applications.

II.Main Features

Versatility:

SCXI-1300 integrates multiple functions such as analog input,signal isolation,analog output,and digital I/O to meet a variety of signal conditioning needs.

Users can select the corresponding functions according to application requirements to achieve flexible configuration and expansion.

High-precision measurement:

The module uses high resolution and advanced signal processing technology to ensure the accuracy of measurement results.

The resolution of the analog input can reach 16 bits,the input range is±10V,and it supports a sampling rate of up to 500kS/s,which is suitable for the acquisition of high-speed dynamic signals.

NI SCXI-1300

Signal Isolation:

The SCXI-1300 provides up to 2.5kV AC/DC isolation,effectively preventing electrical noise and interference.

This helps ensure signal integrity and stability,and improves system reliability.

Digital I/O Function:

The module provides 8 configurable digital I/O channels for easy control and monitoring of digital signals.

Users can configure these channels as input or output mode as needed to achieve flexible digital signal control.

Terminal Blocks and Connections:

The SCXI-1300 is equipped with a 96-pin DIN output connector for connecting SCXI modules.

It also has 32 pairs of screw terminals for interconnecting the signals of the 32-channel SCXI modules.

In addition,there are two screw terminals for connecting to the functional chassis ground pins of the module,and a solder tab for chassis ground.

Physical and Electrical Characteristics:

The SCXI-1300 is a small device with physical dimensions of 49.3×4.3×18.8cm.

It is designed to operate over a wide temperature range,with a recommended operating temperature of 0 to 50°C and a storage temperature of-20 to 70°C.

The module complies with electrical safety standards such as IEC 61010-1,EN 61010-1,UL 61010-1,and CAN/CSA-C22.2 No.61010-1.

NI SCXI-1300

III.Application Fields

The NI SCXI-1300 module is suitable for industrial automation,test and measurement,scientific research experiments,energy management and other fields.In particular,the module performs well in applications that require multifunctional signal conditioning and isolation,such as sensor signal processing,data acquisition systems,control systems,etc.
