Industrial Automation Powerhouse: Schneider 170ADO35000 16-Point Output Module

Description

Application Scenarios

Imagine a large-scale manufacturing plant producing automotive parts.The production line is controlled by a Modicon Momentum system,which must manage dozens of motors,solenoids,and indicator lights.The system relies on modules like the 170ADO35000 to precisely control these devices.For example,a quality control station needs to activate a solenoid to divert a defective part.The PLC sends a digital”on”signal to the 170ADO35000,which then provides the necessary 24 VDC output to energize the solenoid.Without the reliable switching capabilities of the 170ADO35000,the entire production line could suffer from significant downtime,quality control issues,and reduced efficiency.

Parameter

Main Parameters Value/Description

Product Model 170ADO35000

Manufacturer Schneider Electric

Product Category Discrete Output Module

Output Type Solid State(Transistor)

Number of Points 16 points

Output Voltage 24 VDC(Source)

Current per Point 0.5 A(Maximum current a single output can handle)

Isolation 1500 VAC(Optical isolation between logic and field circuits)

Operating Temperature 0°C to 60°C

Communication Protocol Modbus,Modbus Plus,TCP/IP(Supported by the Momentum system)

Mounting DIN Rail or Panel Mount

Export to Sheets

Technical Principles and Innovative Values

Solid-State Switching:Unlike traditional relay outputs,the 170ADO35000 uses solid-state transistors for switching.This provides significantly faster switching speeds and a longer operational life by eliminating mechanical wear and tear,which is critical for high-frequency applications.

High-Density Design:With 16 output points in a compact form factor,the module offers a high I/O density.This allows for more outputs to be controlled from a smaller space,reducing the overall size and cost of the control cabinet.

Built-in Diagnostics:The module features diagnostic capabilities that can detect faults such as short circuits or overloads on the output lines.This helps in quick troubleshooting and reduces the mean time to repair(MTTR).

Electrical Isolation:The 170ADO35000 provides robust optical isolation between the internal controller circuitry and the external field wiring.This protects the sensitive control electronics from voltage spikes and noise originating from the field,enhancing system reliability and safety.

Application Cases and Industry Value

Case Study:Food and Beverage Bottling Line:A bottling plant required a control system to manage the various motors,valves,and conveyor belts.By integrating the Schneider Electric 170ADO35000 modules into their Modicon Momentum system,they were able to achieve a highly reliable and synchronized operation.The high-speed switching of the module enabled precise timing for filling valves,resulting in reduced spillage and increased production speed.User feedback highlighted the module’s ease of use and its contribution to reducing maintenance costs,as its solid-state outputs didn’t require frequent replacement like mechanical relays.

Case Study:Water Treatment Plant:A municipal water treatment facility used the 170ADO35000 modules to control various pumps,motor starters,and alarm beacons.The module’s robust design and electrical isolation were essential in protecting the control system from the electrical noise and harsh environmental conditions common in such facilities.The built-in diagnostics feature was particularly valuable,as it allowed technicians to quickly identify and address wiring faults,ensuring uninterrupted operation of the critical water supply infrastructure.

Related Product Combination Solutions

170CPU20003:The Modicon Momentum processor module that communicates with and controls the 170ADO35000.

170ADI34000:A discrete input module from the same series,used to receive digital signals from field devices like pushbuttons and limit switches.

170INT11000:An Analog Input Module for the Momentum system,used to read continuous signals from sensors.

170ADM69040:A multi-function I/O base that can house the 170ADO35000 and other modules,providing a unified platform.

170ENT11000:A Momentum Ethernet TCP/IP adapter,enabling the entire system to connect to plant-wide networks.

TSX Quantum Series:While the 170ADO35000 is for Momentum,this series represents Schneider’s more powerful,rack-based PLCs for larger applications.

Installation,Maintenance,and Full-Cycle Support

The Schneider Electric 170ADO35000 module is designed for quick and easy installation on a DIN rail or panel.Its simple terminal block wiring and LED status indicators for each channel make initial setup and commissioning straightforward.The module’s robust design and solid-state outputs minimize the need for routine maintenance,as there are no moving parts to wear out.In the event of a fault,the diagnostic LEDs and system-level fault reporting help technicians quickly pinpoint the problem,reducing troubleshooting time.We offer full-cycle support for the 170ADO35000,including technical assistance for installation and configuration,as well as a reliable supply of replacement parts to ensure your system’s longevity.We are committed to providing the expertise and resources you need to keep your automation systems running smoothly and efficiently.Contact us for a customized solution.
