Description

Product Overview

TheICS Triplex T8293Crepresents the gold standard in safety-critical communication technology,designed as a Triple Modular Redundant(TMR)network interface module for high-integrity control systems.As a crucial component within the ICS Triplex safety platform,theT8293Cprovides robust and fault-tolerant communication capabilities that ensure continuous data exchange between safety controllers and higher-level systems.This advanced communication module implements triple redundancy across its entire architecture,featuring three independent communication channels that operate in parallel with continuous synchronization and voting mechanisms.TheICS Triplex T8293Cmaintains seamless connectivity even during component failures,ensuring that critical safety data is never compromised in industrial environments where communication integrity is paramount.

Engineered for maximum reliability,theICS Triplex T8293Cincorporates advanced error detection and correction algorithms that validate data integrity across all communication paths.The module’s robust design withstands extreme industrial conditions,operating flawlessly across wide temperature ranges and in electrically noisy environments that would disrupt conventional communication systems.With its comprehensive diagnostic capabilities,theT8293Ccontinuously monitors network health,channel performance,and data consistency,providing early warning of potential issues before they impact system operation.The module’s flexible architecture supports multiple industrial protocols,making it an ideal solution for integrating safety systems with DCS platforms,enterprise networks,and third-party control equipment while maintaining the highest safety integrity levels.

Technical Specifications

Parameter Name

Parameter Value

Product Model

T8293C

Manufacturer

ICS Triplex

Product Type

Triple Modular Redundant Communication Module

Architecture

TMR(Triple Modular Redundant)

Safety Level

SIL3

Communication Channels

3 independent Ethernet channels

Data Rate

100/1000 Mbps

Protocol Support

Modbus TCP/IP,OPC UA,Ethernet/IP

Isolation Voltage

1500V AC

Operating Voltage

24VDC±10%

Power Consumption

12W

Operating Temperature

-40°C to+70°C

Storage Temperature

-40°C to+85°C

MTBF

>800,000 hours

Connection Type

RJ45 connectors

Diagnostic Coverage

>99%

Vibration Resistance

5g 50-2000Hz

Certification

SIL3,TÜV,UL,CE,cULus

Redundancy

Triple channel with automatic failover

Configuration

Web-based interface and dedicated software

Main Features and Advantages

TheICS Triplex T8293Cdelivers unparalleled communication reliability through its Triple Modular Redundant architecture,featuring three independent Ethernet channels that operate simultaneously with continuous data synchronization and voting.This design ensures that no single point of failure can disrupt critical communications,maintaining SIL3 safety integrity while providing 100/1000 Mbps data rates for high-performance applications.The module’s advanced diagnostic system monitors each communication channel continuously,detecting errors,latency issues,and data inconsistencies while automatically isolating faulty channels without impacting overall system operation.With an MTBF exceeding 800,000 hours and comprehensive fault detection coverage exceeding 99%,theT8293Csets the industry benchmark for communication reliability in safety-critical applications.

Protocol flexibility and integration:TheICS Triplex T8293Csupports multiple industrial protocols including Modbus TCP/IP,OPC UA,and Ethernet/IP,providing seamless integration with various control systems and enterprise networks.The module’s web-based configuration interface simplifies setup and maintenance,while its robust construction ensures reliable operation in extreme environmental conditions.The triple redundant design includes automatic failover capabilities that maintain continuous communication even during multiple component failures,ensuring uninterrupted data exchange for critical safety functions.TheT8293Calso features comprehensive cybersecurity protections including hardware-based encryption and secure boot capabilities,safeguarding critical infrastructure from cyber threats while maintaining real-time communication performance.

Application Field

TheICS Triplex T8293Cis deployed in industries where communication reliability directly impacts safety and operational integrity.In oil and gas applications,it provides critical network connectivity for offshore platform safety systems,pipeline emergency shutdown systems,and refinery process protection networks.The power generation industry relies on theT8293Cfor nuclear plant safety communications,turbine protection systems,and grid stability control networks where communication failure could have catastrophic consequences.Chemical and petrochemical plants utilize this module for reactor safety systems,flare gas recovery controls,and hazardous area monitoring networks that require guaranteed communication availability.

Critical infrastructure applications benefit from theICS Triplex T8293C’s proven reliability in LNG terminal safety systems,gas compression station controls,and distribution facility protection networks.The marine industry employs these communication modules for engine room safety networks and dynamic positioning systems on vessels and offshore installations.In transportation infrastructure,theT8293Censures reliable communication in tunnel safety systems,railway signaling networks,and airport safety operations.Its unmatched reliability makes it the preferred choice for any application where communication integrity is critical for human safety,environmental protection,and asset preservation.

Related Products

ICS Triplex T8111C-TMR Safety Controller

ICS Triplex T8461-Analog Input Module

ICS Triplex T8431-Digital Input Module

ICS Triplex T8471-Analog Output Module

ICS Triplex T8441-Digital Output Module

ICS Triplex Power Supply-Redundant power units

ICS Triplex Baseplate-Module mounting system

ICS Triplex Configuration Software-System setup tools

ICS Triplex HMI-Operator interface stations

ICS Triplex Historian-Data recording and analysis

Installation and Maintenance

Pre-installation preparation:Before installing theICS Triplex T8293C,verify compatibility with existing safety system architecture and ensure adequate space for proper ventilation and maintenance access.Confirm network infrastructure supports redundant Ethernet connections and prepare all necessary mounting hardware and communication cables according to manufacturer specifications.Ensure proper grounding and electrical isolation to prevent interference and ensure safe operation in industrial environments.

Maintenance recommendations:Implement rigorous preventive maintenance for theICS Triplex T8293C,including regular visual inspections for physical integrity,connection security,and environmental conditions.Monitor network performance metrics and conduct periodic diagnostic tests to verify redundant channel operation and data synchronization.Maintain comprehensive documentation of all maintenance activities and configuration changes.Utilize the advanced diagnostic capabilities to monitor communication health continuously and address potential issues before they impact system availability.

Product Guarantee

We guarantee that everyICS Triplex T8293Ccommunication module is genuine OEM product with full manufacturer warranty and safety certifications intact.Our technical support team provides comprehensive services from system design and risk assessment through commissioning and ongoing maintenance support.Choose our solutions for uncompromised communication reliability in your most critical applications,backed by our commitment to quality and customer safety excellence.
