Product Overview

The ICS Triplex T8110B is a robust,4-port serial communication module engineered for industrial environments requiring reliable,high-performance serial connectivity.Manufactured by International Communications Solutions(ICS)under the Triplex brand—renowned for durable industrial I/O solutions—the ICS Triplex T8110B delivers stable,low-latency serial data transmission via a PCI Express(PCIe)host interface.Designed for integration into industrial PCs,engineering workstations,and control servers,this module supports both RS-232 and RS-422 communication standards across its four independent ports,enabling seamless connection to legacy automation equipment such as PLCs,HMIs,RTUs,modems,and terminal servers.

As part of the ICS Triplex Turbo Serial family,the ICS Triplex T8110B features advanced 16C550C-compatible UART(Universal Asynchronous Receiver/Transmitter)controllers with 16-byte FIFO buffers per port,minimizing CPU overhead and preventing data loss during high-speed transmissions.It supports programmable baud rates up to 921.6 kbps,making it suitable for time-critical applications in power generation,water treatment,manufacturing,and oil&gas facilities.The T8110B is widely used in SCADA(Supervisory Control and Data Acquisition)and DCS(Distributed Control Systems)where consistent,error-free serial communication is essential for operational integrity.

The ICS Triplex T8110B connects to external devices via a DB25 male connector,with port configuration(RS-232 or RS-422)determined by wiring in an external breakout box or terminal block.This allows flexible deployment in DIN rail or rack-mounted enclosures.Fully supported on Windows and Linux platforms,the T8110B combines industrial durability with ease of integration,serving as a dependable bridge between modern computing systems and legacy serial instrumentation.

Technical Specifications

Product Model ICS Triplex T8110B

Manufacturer International Communications Solutions(ICS)Triplex

Product Type 4-Port Serial Communication Module

Host Interface PCI Express x1(PCIe Gen 1/2/3)

Number of Ports 4

Port Type DB25 Male Connector(RS-232/RS-422 configurable per port)

Communication Standard EIA/TIA-232-F,EIA/TIA-422-B

UART Chipset 16C550C-Compatible with 16-byte FIFO

Baud Rate Up to 921.6 kbps(programmable)

Data Bits 5,6,7,8

Stop Bits 1,1.5,2

Parity None,Even,Odd,Mark,Space

Flow Control XON/XOFF(Software),RTS/CTS,DTR/DSR(Hardware)

ESD Protection±15 kV Air Gap,±8 kV Contact

Operating Temperature 0°C to+60°C

Storage Temperature-20°C to+85°C

Humidity 5%to 95%RH,non-condensing

Power Consumption<2.5 W(from PCIe slot)

Driver Support Windows XP/Vista/7/8/10/11,Windows Server,Linux Kernel 2.6+

Installation Internal PCIe Slot,External Breakout Box for Field Wiring

Main Features and Advantages

The ICS Triplex T8110B is designed to deliver reliable,high-performance serial I/O in demanding industrial environments.Its 4-port configuration offers a balanced solution between port density and system resource usage,making it ideal for mid-scale automation systems where more than a single COM port is needed but full 8-or 16-port cards are excessive.

A key advantage is its flexible port configuration:each of the four DB25 pins can be individually wired for RS-232(point-to-point)or RS-422(differential,long-distance,noise-resistant)operation,allowing integration of diverse field devices.The use of 16C550C-compatible UARTs with 16-byte FIFO ensures efficient data handling,reducing interrupt frequency and CPU utilization—critical for maintaining real-time responsiveness in control applications.

Built for industrial durability,the T8110B includes robust ESD protection to guard against electrostatic discharge,a common issue in industrial settings.It operates reliably in temperatures from 0°C to+60°C and is designed for 24/7 continuous operation.With full driver support for Windows and Linux,the T8110B integrates seamlessly into existing control architectures and supports long-term deployments in infrastructure projects.

Additionally,the T8110B is compatible with standard breakout boxes(e.g.,DB25 to four DB9 or terminal blocks),enabling clean,serviceable installations in control cabinets.Its low power consumption and PCIe interface ensure compatibility with modern industrial motherboards while maintaining backward compatibility with legacy serial protocols like Modbus RTU,DNP3,and ASCII.

Application Field

The ICS Triplex T8110B is deployed across multiple industrial sectors where reliable serial communication is essential:

Power Generation&Substations:Connects protective relays,meters,and RTUs to SCADA systems using Modbus or DNP3.

Water/Wastewater Treatment:Interfaces with pump controllers,level sensors,and chemical dosing systems.

Manufacturing:Links PLCs,barcode readers,and CNC machines to HMI and MES systems.

Oil&Gas:Integrates flow computers,wellhead sensors,and safety shutdown systems in remote locations.

Telecommunications:Manages legacy modems,multiplexers,and access equipment in central offices.

Transportation:Supports signaling systems,train control units,and baggage handling equipment.

Its compact size and proven reliability make the T8110B a preferred choice for system integrators upgrading legacy systems or building new control stations with moderate serial I/O requirements.

Related Products

ICS Triplex T8191–8-port PCIe serial module for higher density applications.

ICS Triplex T8180–4-port variant,often used as a predecessor or alternative.

ICS Triplex T8310–16-port PCIe serial card for large-scale integration.

ICS Triplex T8110B-I–Isolated version with 500 V galvanic isolation(if available).

ICS Triplex DB25 Breakout Box–External enclosure for converting DB25 to DB9 or screw terminals.

MOXA C104H/PCIe–Competitive 4-port serial card for benchmarking.

ProSoft Technology MVI46-MCM–Rockwell ControlLogix communication module.

Siemens 6GK5915-1AD00-0AA0–Industrial Ethernet switch for hybrid networks.

Honeywell CC-IP0101–Ethernet-to-serial gateway for modernization projects.

Red Lion Controls N-Tron 510 Series–Rugged industrial switches often deployed alongside T8110B systems.

Installation and Maintenance

Pre-installation:Ensure the host system has an available PCIe x1(or larger)slot.Download the latest drivers from ICS.Determine port configuration(RS-232/RS-422)and prepare breakout cables.Power down the system before installing the card.Secure the T8110B in the slot and fasten the bracket.

Wiring:Use a DB25 breakout box or terminal block to connect field devices.Label all cables clearly.Ensure proper grounding and avoid running serial cables parallel to AC power lines.

Maintenance:Periodically inspect connectors for corrosion or looseness.Monitor system logs for port errors.Use ICS diagnostic tools to verify signal integrity.The T8110B requires minimal maintenance but benefits from clean,well-ventilated environments.
