Honeywell 620-0073C Ethernet Loop Processor Module, 24 VDC Rack-Mounted Design

Product Overview

The Honeywell 620-0073C is an Ethernet Loop Processor Module (ELPM) for the Honeywell IPC 620 programmable controller family, also known as the Series 620 platform. In Honeywell’s own parts documentation it sits under the Communications Interface Modules heading, alongside the 620-0043C Modbus-RTU interface and the 620-0052C data collection module, which tells you precisely where it belongs architecturally: this is the module that puts a 620-series controller onto an Ethernet loop network, not a general-purpose CPU.The “C” suffix is not decorative. In the IPC 620 numbering convention, a C suffix denotes CE Mark compliance, while an R suffix denotes a module approved for removal and insertion under power. The Honeywell 620-0073C carries the C but not the R, which has a direct maintenance consequence: it is not intended to be pulled from a live rack.Functionally, the Honeywell 620-0073C performs two jobs at once. It executes loop and logic processing for its assigned control tasks, and it manages Ethernet-side communication, exchanging real-time data with the rack backplane on one side and with supervisory hosts, SCADA systems and peer controllers on the other. That dual role is what makes it a high-consequence spare: lose the module and you lose both the processing and the network path behind it.A caution on sourcing. Because the Honeywell 620-0073C is long discontinued, the aftermarket listings for it are unusually unreliable, with several sellers publishing specifications that are demonstrably invented. Treat only the physical, electrical and approval data as dependable, and verify anything else against your existing module or Honeywell documentation before you buy.

Category: FUJI

Contact Us WhatsApp / Wechat：+8618150087953
Phone：+86 18150087953
Email：sales@cxplcmro.com

Description

Technical Specifications

Parameter Name	Parameter Value
Product Model	620-0073C
Manufacturer	Honeywell
Product Type	Ethernet Loop Processor Module (ELPM)
Product Category	Communications Interface Module
Compatible System	Honeywell IPC 620 / Series 620 programmable controller platform
Associated Platforms	Honeywell IPC 620 installations within TDC 2000 and TDC 3000 architectures
Core Function	Loop and logic processing combined with Ethernet loop network communication
Network Type	Ethernet loop topology
Communication Protocol	Ethernet / Ethernet TCP-IP (industrial Ethernet loop)
Supply Voltage	24 V DC nominal, supplied via the IPC 620 rack backplane
Power Consumption	Approx. 11 W
Slot Requirement	Single slot in a Honeywell 620-series processor or I/O rack
Mounting Method	Rack-mounted plug-in module with panel retention
Hot-Swap Capability	Not rated for removal or insertion under power (no R suffix)
Suffix Designation	C = CE Mark compliant version
Status Indication	Front-panel LED status indicators for module and communication state
Approximate Dimensions	51 mm W × 267 mm H × 178 mm D (single-slot 620-series module footprint)
Weight	Approx. 1.1 kg
Operating Temperature	−40 °C to +70 °C
Approvals	CE, UL, CSA, TUV, FM
Country of Origin	USA
Tariff Code	8537101190
Lifecycle Status	Discontinued; available through surplus and specialist spare-part channels

Main Features and Advantages

Processing and communication in one module: The defining characteristic of the Honeywell 620-0073C is that it does not force a choice between a processor and a network interface. It handles loop execution and logic for its assigned control duties while simultaneously managing Ethernet loop traffic, which removes an entire layer of gateway hardware, protocol conversion and the associated failure points from the panel.Ethernet loop topology for a resilient network: Loop architecture gives traffic two directions around the network rather than one. For a controller mounted in a rack that has to stay in conversation with operator stations, historians and peer controllers, that redundancy is the difference between a single cable fault being an event and being an outage.Backplane-powered, single-slot simplicity: The Honeywell 620-0073C draws its 24 V DC supply from the rack backplane and occupies one slot. There is no separate power supply to wire, no auxiliary PSU to accommodate, and no additional panel space to find — the practical benefit being that a replacement can be commissioned in the footprint the failed unit already occupied.Industrial approvals across major markets: With CE, UL, CSA, TUV and FM approvals recorded for this part number, the Honeywell 620-0073C is usable in regulated installations across North America and Europe without a separate compliance review, which matters considerably when a replacement has to be justified to a site’s engineering authority.Built for the 620 mechanical standard: At roughly 51 × 267 × 178 mm and about 1.1 kg, the module matches the standard 620-series single-slot envelope used by the power supplies, I/O control modules and processors in the same family. Mechanically it is a known quantity: the same guides, the same backplane connector, the same retention hardware.Diagnostics at the front panel: Status LEDs give a technician an immediate read on module and communication state without a programming terminal, which is what shortens the diagnostic phase of an outage when every minute of downtime is being counted.
