GE DS200TCRAG1ACC

Description

Product Overview

The​​  GE DS200TCRAG1ACC  ​​is a sophisticated relay output board manufactured by General Electric(GE)as part of their Mark V series for industrial automation and control systems.This advanced electronic device serves as a critical interface component,primarily designed to provide relay output functionality that converts digital signals into electromagnetic relay control signals

.

As a versatile industrial control solution,the​​GE DS200TCRAG1ACC​​features 30 plug-in relays and comprehensive connectivity options,including 4 x 34-pin connectors and 4 x 12-pin connectors.The 34-pin connectors are designated with IDs JOR,JOS,JOT,and JO,while the 12-pin connectors are identified as JS3,JS4,JS5,and JS6

.

Technical Specifications

Parameter

Specification

​​Product Model​​

GE DS200TCRAG1ACC

​​Manufacturer​​

General Electric(GE)

​​Product Type​​

Relay Output Board

​​Series​​

Mark V

​​Relay Configuration​​

30 plug-in relays

​​Connector Configuration​​

4 x 34-pin connectors,4 x 12-pin connectors

​​34-pin Connector IDs​​

JOR,JOS,JOT,JO

​​12-pin Connector IDs​​

JS3,JS4,JS5,JS6

​​Relay Contact Rating​​

0.5 Amps per relay

​​Compatible Systems​​

GE Mark V Speedtronic control systems

​​Country of Origin​​

USA

Key Features and Capabilities

Advanced Relay Output Functionality

The​​GE DS200TCRAG1ACC​​provides multi-channel relay output capability,enabling simultaneous control of multiple external electrical devices such as motors,valves,lights,and other industrial equipment.This multi-channel design allows for precise control and operation of various electrical devices within industrial automation systems

.

Digital Signal Conversion

This output board excels at converting digital signals from PLCs,controllers,or other digital devices into electromagnetic relay control signals.This conversion capability ensures precise control of external equipment,making it ideal for complex industrial automation applications where accurate signal processing is essential

.

Comprehensive Connectivity Options

With its extensive connector configuration,the​​GE DS200TCRAG1ACC​​offers flexible connectivity solutions.The board’s multiple connector types facilitate easy integration with various field devices and cables,ensuring rapid deployment and system integration in industrial environments

.

Compact and Robust Design

The​​GE DS200TCRAG1ACC​​features a compact design that optimizes space utilization while maintaining robust construction suitable for harsh industrial environments.This design approach makes it ideal for installation in control cabinets and equipment enclosures where space constraints are a consideration

.

High Reliability and Performance

As part of GE’s industrial automation portfolio,the​​GE DS200TCRAG1ACC​​benefits from the manufacturer’s reputation for quality and reliability.The board is designed to operate stably in various industrial environments,ensuring consistent performance and minimal downtime in critical applications

.

Application Areas

Industrial Automation Systems

The​​GE DS200TCRAG1ACC​​finds extensive application in industrial automation systems across multiple sectors.Its relay output capabilities make it suitable for controlling motors,valves,and other industrial equipment in manufacturing environments,process industries,and material handling systems

.

Power Generation and Energy Sector

In power generation facilities,the​​GE DS200TCRAG1ACC​​serves as a critical component in control systems for gas turbines,steam turbines,and other power generation equipment.Its reliability and precise control capabilities make it ideal for applications where system availability and performance are paramount

.

Process Industries

The board is widely used in process industries including oil and gas,petrochemical,and chemical processing plants.Its ability to handle multiple relay outputs simultaneously makes it suitable for complex process control applications where multiple devices need coordinated control

.

Infrastructure and Utilities

In infrastructure applications such as water treatment plants,wastewater management systems,and transportation infrastructure,the​​GE DS200TCRAG1ACC​​provides reliable control functionality for pumps,valves,and other critical equipment

.

Installation and Maintenance Considerations

Pre-Installation Requirements

Before installing the​​GE DS200TCRAG1ACC​​,ensure that the installation environment meets specified requirements.Verify that the drive current emergency shutdown device location is known and accessible.Confirm that the shutdown device is in good working condition and that personnel are familiar with its operation

.

Environmental Conditions

Ensure the installation area is clean,dry,and free from moisture or standing water.Remove any oil or grease from the floor using appropriate cleaning agents.Eliminate all ungrounded double-prong power cords to prevent electrical shock hazards

.

Safety Procedures

Notify operators and management personnel in the work area about scheduled maintenance activities.Select a clean,flat,and sturdy workspace near the drive equipment for board replacement operations.Follow established safety protocols and ensure proper personal protective equipment is used during installation and maintenance activities

.

System Integration and Compatibility

The​​GE DS200TCRAG1ACC​​is designed for seamless integration with GE’s Mark V Speedtronic control systems.Its compatibility with various industrial protocols and communication standards ensures easy integration into existing automation infrastructure.The board’s modular design supports system expansion and modification without requiring extensive reconfiguration

.

Performance and Reliability

The​​GE DS200TCRAG1ACC​​delivers exceptional performance characteristics,including:

​​High Reliability​​:Designed for continuous operation in demanding industrial environments

​​Precision Control​​:Accurate signal conversion and relay operation

​​Flexible Configuration​​:Multiple relay outputs for diverse application requirements

​​Easy Maintenance​​:Modular design facilitates quick replacement and troubleshooting

​​Long Service Life​​:Quality components ensure extended operational lifespan

Technical Support and Service

GE provides comprehensive technical support for the​​GE DS200TCRAG1ACC​​,including documentation,application guidance,and troubleshooting assistance.The board is backed by GE’s global service network,ensuring prompt support and replacement parts availability when needed

.

Conclusion

The​​GE DS200TCRAG1ACC​​relay output board represents a sophisticated solution for industrial automation and control applications.With its 30 plug-in relays,comprehensive connectivity options,and robust design,it provides reliable performance in demanding industrial environments.Whether deployed in power generation,process industries,or manufacturing facilities,the​​GE DS200TCRAG1ACC​​offers the reliability,flexibility,and performance required for modern industrial control applications
