Description

The GE DS200TCPSG1ARE is a mid-sized inverter manufactured by General Electric(GE).It is primarily used to control AC induction motors and also features a DC input power board,making it suitable for industrial automation and turbine control applications.The following is a summary of its key information:

I.Product Positioning and Functionality

Core Applications

Inverter Function:As a mid-sized inverter,it controls the speed and torque of AC induction motors.Its wide output frequency range(0.5Hz to 200Hz)meets the needs of various motor applications.

DC Input Power Board:Provides DC power to distributed control systems(DCSs)and supports turbine control,making it suitable for applications such as refineries and petrochemical/chemical plants.

Key Features

High Efficiency:Over 95%efficiency reduces energy consumption.

Overload Capacity:150%overload capacity for 1 minute accommodates short-term high-load conditions.

Programmability:Supports programming for industrial process and machine control,offering support for multiple programming languagessuch as ladder diagrams and function block diagrams.Security:Built-in protection mechanisms prevent industrial processes and equipment from external interference and attacks.

II.Technical Specifications and Parameters

Electrical Parameters

Input Voltage:Supports 24V DC(24VDC),and may be compatible with 120V AC in some scenarios.

Output Frequency:0.5Hz to 200Hz,meeting different motor speed requirements.

Power Consumption:≤10W(varies by model and application scenario).

Physical Parameters

Dimensions:Dimensions vary slightly depending on the source,but common dimensions are 4.5×17.6×24.3cm or 2×2×39cm(please confirm with the actual model).

Weight:Approximately 2kg to 2.5kg,ensuring easy installation and maintenance.

Operating Temperature:-40°C to 100°C(0°C to 50°C for some models),suitable for extreme temperature environments.Interface and Communication

Connectors:Includes one 16-pin connector and one 9-pin connector,supporting multi-channel signal transmission.

Communication Protocols:Supports RS485,Modbus RTU,CAN,Ethernet,and serial communications,enabling seamless integration with higher-level systems and other devices.

III.Application Scenarios and Advantages

Typical Industries

Power Generation:Used for controlling gas turbines and steam turbines to ensure stable power production.

Petrochemical:Controls pumps,compressors,and other equipment in refineries and chemical plants to ensure safe and efficient production processes.

Manufacturing:Suitable for production line automation control in the automotive,electronics,and food industries,enhancing production flexibility.

Core Advantages

High Performance:Utilizes advanced control technology and high-quality components to ensure stable operation.

High Reliability:High-temperature resistance and anti-interference design reduce the risk of downtime.

Ease of Use:Provides multiple operating modes and programming languagesto reduce user learning curves.

Compatibility:Seamlessly integrates with GE Mark VI systems and other industrial automation equipment,protecting user investment.IV.Procurement and After-Sales Support

Market Availability

Suppliers:Purchases can be made through official GE channels or authorized distributors(such as Zhangzhou Fengyun Electrical Equipment Co.,Ltd.and Xiamen Amicon Technology Co.,Ltd.).

Price Range:Market quotes start at approximately¥23,314.00(varies depending on purchase volume,model,and supplier).Some channels offer price inquiries.

Availability:Some suppliers display”long-term availability,”but please confirm availability of specific models(for example,the DS200TCPSG1ARE was previously marked”out of stock”).

After-Sales Service

Warranty:Typically,a one-year warranty is provided,with some suppliers offering extended warranties.

Technical Support:GE or authorized suppliers provide technical support for installation,commissioning,troubleshooting,and other areas.

Return and Exchange Policy:Please confirm the supplier’s return and exchange policies before purchasing to reduce procurement risk.
