Description
I.Product Positioning and Functionality
Core Applications
As a key component of the Mark V turbine control system,the DS200RTBAG3AGC is primarily used for signal relay,power distribution,and interface expansion,ensuring stable communication between various modules within the system(such as PLCs,sensors,and actuators).
It supports 24VDC/120VAC inputs to power other modules within the system and provides multiple connection ports compatible with various industrial protocols(such as RS485 and Modbus RTU).
Key Features
High-Temperature Design:Suitable for high-temperature environments such as turbine nacelles,the operating temperature range is typically-30°C to 100°C.
High Reliability:Utilizing industrial-grade components and passing anti-interference testing,it reduces the risk of downtime.Programmability:Supports PLC system programming,allowing control logic to be customized according to user needs.
II.Technical Specifications and Parameters
Electrical Parameters
Operating Voltage:24V DC/120V AC
Output Frequency:Some data sheets indicate 56/63Hz;the specific frequency should be determined based on the actual application scenario.
Power Consumption:≤10W(typical).
Physical Parameters
Dimensions:Common dimensions are 10×16×23cm;specific dimensions may vary by supplier.
Weight:Approximately 2-2.5kg,ensuring easy installation and maintenance.
Interfaces and Communication
Connectors:Provides one 16-pin connector and one 9-pin connector,supporting multi-channel signal transmission.
Communication Protocols:Compatible with industrial protocols such as RS485 and Modbus RTU,enabling seamless integration with higher-level systems.III.Application Scenarios and Advantages
Typical Industries
Power Generation:Controls gas and steam turbines to ensure stable power generation.
Petrochemical:Controls pumps,compressors,and other equipment in refineries and chemical plants to ensure safe and efficient production processes.
Heavy Industry:Suitable for high-temperature,high-dust environments in steel and cement plants,providing reliable control signal transmission.
Core Advantages
Compatibility:Seamlessly integrates with GE Mark V systems,protecting users’long-term investment in GE control technology.
Flexibility:Supports customized programming to adapt control strategies to different operating conditions.
Security:Built-in protection mechanisms prevent industrial processes and equipment from external interference and attacks.
