GE DS200CTBG1ADD

Description

📌产品介绍|Product Description

型号/Model

GE DS200CTBG1ADD

中文版

主要功能

母板/终端板作用：DS200CTBG1ADD属于GE Mark V系统中的I/O终端母板(Terminal Board)，主要负责为控制信号、传感器、执行器提供接线接口。

信号管理：把外部输入/输出信号统一接入，传输到对应的控制模块。

保护与隔离：设计有隔离和防护电路，减少外部干扰，保证信号传输稳定。

配套性强：与Mark V控制系统的核心模块完全兼容。

技术亮点

工业级PCB设计，抗高温、耐电磁干扰。

多通道信号接入，便于扩展和维护。

插拔式端子，现场布线方便。

应用领域

GE燃气轮机控制系统

GE蒸汽轮机控制系统

发电厂DCS控制系统

关键工业设备的过程控制

工控老姜点评

这块CTBG终端板就像“神经中枢的接线排”，把外部所有的信号都整齐送进控制核心。现场最常见的问题是：接线松动、氧化导致接触不良，轻则报警乱跳，重则保护误动作。老姜提醒一句——电厂里这类板子一定要保持清洁、定期检查接线，别等到停机才想起来。

English Version

Key Functions

Terminal Board Function:The DS200CTBG1ADD is part of the GE Mark V system,serving as an I/O terminal board for signal wiring and distribution.

Signal Management:Consolidates external input/output signals and transmits them to the control modules.

Protection&Isolation:Built-in circuits provide signal isolation and protection against external interference.

Compatibility:Fully compatible with GE Mark V control system modules.

Technical Highlights

Industrial-grade PCB design with strong resistance to temperature and EMI.

Supports multiple signal channels for flexible expansion.

Plug-in terminal design for easy field wiring and maintenance.

Application Areas

GE Gas Turbine Control Systems

GE Steam Turbine Control Systems

Power Plant DCS Systems

Industrial Process Control

Think of this CTBG terminal board as the“wiring hub”of the system’s nervous system.The most common on-site issues are loose or oxidized connections,which can cause anything from false alarms to false trips.My advice:always keep it clean and check connections regularly—don’t wait until the turbine shuts down to notice the problem.
