Product Overview

The FOXBORO E45P-FFNHTA-3B 63-95VDC UNMP is a high-performance power supply module designed for use within FOXBORO’s I/A Series Distributed Control Systems(DCS).Offering 63-95VDC voltage input,this module is engineered to provide a reliable power source for various control modules and field devices in industrial automation environments.As part of the E45P series,it ensures high efficiency and continuous performance in demanding applications,making it a vital component in many automation and control systems.

The FOXBORO E45P-FFNHTA-3B integrates seamlessly with FOXBORO DCS systems,enabling effective management of critical industrial processes.Its compact,durable design ensures that it can function reliably in industrial environments that require consistent power input for field devices such as actuators,sensors,and control systems.The module’s flexibility,ruggedness,and ease of integration into complex systems make it the preferred choice for applications in sectors like chemical processing,oil and gas,power generation,and manufacturing.

By ensuring optimal power supply and stability in fieldbus communication,the E45P-FFNHTA-3B ensures smooth control and monitoring of industrial operations.Its advanced features and robust design minimize downtime,enhance operational reliability,and optimize system performance.

Technical Specifications

Parameter Name Parameter Value

Product Model E45P-FFNHTA-3B

Manufacturer FOXBORO

Product Type Power Supply Module

Input Voltage Range 63V DC-95V DC

Output Voltage 24V DC

Output Power 30W

Operating Temperature-20°C to+60°C

Protection Class IP20

Dimensions 120mm x 120mm x 50mm

Weight 0.8 kg

Mounting DIN Rail

Certifications CE,UL

Diagnostic Features Integrated diagnostics

Main Features and Advantages

Wide Voltage Range:The FOXBORO E45P-FFNHTA-3B supports a wide input voltage range of 63V DC to 95V DC,making it highly versatile and adaptable to various industrial power systems.This flexibility ensures that the module can operate across a wide range of environments and power configurations,reducing the need for additional power regulation equipment.

Compact and Efficient Design:With a compact footprint of 120mm x 120mm x 50mm,the E45P-FFNHTA-3B is designed to fit into space-constrained environments while providing a stable output power of 30W.Despite its small size,it delivers reliable power for critical control systems,making it ideal for industrial control panels and cabinets.

Rugged Industrial Design:Built for durability,the FOXBORO E45P-FFNHTA-3B is housed in an IP20-rated enclosure,providing excellent protection against dust and other environmental factors.This rugged design ensures that the module can operate reliably in demanding industrial settings,maintaining uptime even in harsh conditions.

DIN Rail Mounting:The E45P-FFNHTA-3B is designed for easy installation with DIN rail mounting,simplifying the setup process in control panels and automation racks.This mounting option saves time and reduces the complexity of installation in both new and retrofit systems.

Enhanced Diagnostics:Equipped with integrated diagnostic features,the FOXBORO E45P-FFNHTA-3B provides real-time monitoring and feedback on system performance.This diagnostic capability helps in identifying potential issues before they lead to failure,ensuring that preventive maintenance can be performed and system reliability is maximized.

Wide Operating Temperature:The E45P-FFNHTA-3B is designed to operate in a broad temperature range,from-20°C to+60°C,making it suitable for use in a variety of environments,from freezing cold to high-heat industrial applications.

CE and UL Certification:With CE and UL certifications,the FOXBORO E45P-FFNHTA-3B meets international safety and quality standards,ensuring reliable operation and safety for global applications.

Reliable Performance:The E45P-FFNHTA-3B ensures a stable output of 24V DC,essential for the smooth operation of FOXBORO I/A systems and connected field devices.It guarantees continuous performance,minimizing downtime and reducing the need for frequent maintenance.

Application Field

The FOXBORO E45P-FFNHTA-3B is ideal for applications that require a reliable,continuous power supply to field devices and control systems.Some of the key industries and scenarios where this module excels include:

Oil and Gas:In the oil and gas sector,the E45P-FFNHTA-3B is used to provide stable power to critical sensors,actuators,and other control devices.Its rugged design ensures reliable operation in both offshore and onshore environments,where power stability is crucial for safety and efficiency.

Chemical Processing:The module plays a crucial role in chemical plants where maintaining constant power to control systems is vital for process stability.The FOXBORO E45P-FFNHTA-3B helps ensure that critical processes,such as temperature control,flow regulation,and pressure monitoring,operate smoothly and without interruption.

Power Generation:In power plants,the FOXBORO E45P-FFNHTA-3B ensures the continuous supply of power to systems monitoring key parameters like pressure,temperature,and flow.It supports the automation of power generation systems and guarantees reliable power to the control systems even in harsh industrial conditions.

Manufacturing Automation:The E45P-FFNHTA-3B is also used in automated manufacturing systems to power industrial equipment,robots,and machinery.The module ensures uninterrupted control of automated processes,improving production efficiency and minimizing downtime in manufacturing environments.

Water Treatment:The module can be used in water treatment plants to maintain a reliable power supply for monitoring and control systems.Its durability and diagnostic capabilities make it an ideal choice for such critical applications where system failure can lead to significant issues.

HVAC Systems:The FOXBORO E45P-FFNHTA-3B is also ideal for HVAC(Heating,Ventilation,and Air Conditioning)systems,where stable power to temperature and humidity sensors is required to ensure that air quality and environmental conditions are properly controlled.

Related Products

FOXBORO E45P-FFNHTA-3C:A higher-power variant of the E45P-FFNHTA-3B,designed for applications requiring more output power and additional field device support.

FOXBORO E45P-FFNHTA-2B:A slightly lower voltage input version with similar features and performance,ideal for systems with lower input voltage requirements.

FOXBORO E45P-FFNHTA-4B:A variant with additional communication capabilities,designed for integration into larger,more complex automation systems.

FOXBORO I/A Series Power Supply Module:A broader product range offering more robust solutions for process control systems requiring higher power output or specialized features.

FOXBORO DM400FB Power Supply:A smaller,more compact power supply solution,providing lower power output for lighter applications.

Installation and Maintenance

Pre-installation preparation:

Before installing the FOXBORO E45P-FFNHTA-3B,ensure that the control panel or rack has sufficient space for DIN rail mounting and that power supplies are correctly configured for 63V DC-95V DC input.Confirm the proper wiring for 24V DC output connections and ensure the environment meets the IP20 protection rating to avoid exposure to moisture or excessive dust.

Maintenance recommendations:

The FOXBORO E45P-FFNHTA-3B requires minimal maintenance,but periodic inspections of the power connections,diagnostic LEDs,and field device status are recommended.Ensure that the module’s temperature range is not exceeded,and check for any visible wear on power cables.Regular cleaning with a soft cloth and a review of the diagnostic data will help to keep the system in peak condition and prevent unexpected failures.

Product Guarantee

The FOXBORO E45P-FFNHTA-3B comes with a FOXBORO warranty,ensuring top-tier performance and reliability for the long term.The company’s commitment to quality ensures that the E45P-FFNHTA-3B performs optimally throughout its operational lifetime.FOXBORO also offers comprehensive after-sales support,including troubleshooting,technical guidance,and system upgrades.Rest assured,this power supply module is built to meet the highest standards of reliability,providing an excellent long-term investment for critical industrial systems.
