Description
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | Fluke 719-100G |
| Manufacturer | Fluke Corporation |
| Product Type | Electric Pressure Calibrator |
| Pressure Measurement Range | -12 to 120 psi (-850 mbar to 8 bar) |
| Pressure Measurement Accuracy | 0.025% of range (6 months), 0.035% of range (1 year) |
| Pressure Measurement Resolution | 0.01 psi, 1 mbar |
| mA Measurement Range | 0 to 24 mA |
| mA Measurement Accuracy | 0.015% reading + 2 counts |
| mA Source/Simulate Range | 0 to 24 mA |
| mA Source/Simulate Accuracy | 0.015% reading + 2 counts |
| Loop Power Supply | 24V (available for transmitter testing) |
| Overpressure Protection | 2x full range |
| Internal Pump Range | Up to 100 psi |
| Programmable Pump Limit | Yes – eliminates over-pressurization and sets target pressures |
| Pressure Module Compatibility | 29 x Fluke 700Pxx Pressure Modules (extend range up to 700 bar) |
| Pressure Switch Test | Built-in function |
| Operating Temperature | -10°C to 55°C |
| Storage Temperature | -30°C to 60°C |
| Relative Humidity | 95% (-10°C to 30°C), 75% (30°C to 40°C), 45% (40°C to 50°C), 35% (50°C to 55°C) |
| Shock/Drop | 1 meter drop test |
| Safety Approvals | CSA C22.2 No. 1010.1:1992 |
| EMC Compliance | EN50082-1:1992, EN55022:1994 Class B |
| Battery Type | Two 9V alkaline batteries |
| Battery Life | 12 hours (12mA into 500Ω), 200 pump cycles to 100 psi |
| Dimensions (H x W x L) | 60 x 87 x 210 mm (2.19 x 3.41 x 8.28 in) |
| Weight | 912 g (2 lb) |
| Warranty | 3 years for calibrator, 1 year for pump |
Main Features and Advantages
Electric Pump for One-Handed Pressure Calibration: The defining feature of the Fluke 719-100G is its built-in electric pump, which eliminates the physical effort and time required for manual hand pumping . Calibration and testing of pressure devices can be performed quickly and easily with one hand, making the Fluke 719-100G the ideal tool for busy process professionals . The programmable pump limit settings allow users to set target pressures and prevent over-pressurization, protecting both the calibrator and the device under test from damage .
Best-in-Class Pressure and mA Accuracy: The Fluke 719-100G delivers pressure measurement uncertainty of 0.025%, establishing it as one of the most accurate field pressure calibrators available . Simultaneously, the Fluke 719-100G measures and sources mA signals with 0.015% accuracy, enabling precise calibration of P/I and I/P transmitters, valve positioners, and 4-20 mA loops . This dual accuracy capability means the Fluke 719-100G can handle the complete calibration workflow for a pressure transmitter in a single instrument.
Precision Control for Accurate Calibration: The Fluke 719-100G incorporates a precision pressure adjust vernier and a variable release rate bleed valve, providing exceptional fine control over applied pressure . These features allow users to dial in exact pressure setpoints with minimal overshoot, ensuring accurate and repeatable calibration results . The ability to source mA with simultaneous pressure measurement enables efficient testing of valves and I/P devices without requiring multiple instruments .
Versatile Diagnostic and Troubleshooting Functions: The Fluke 719-100G includes a built-in switch test function for testing pressure switches, measuring set, reset, and deadband parameters . The 24V loop power supply enables transmitter testing without requiring an external power source . The Fluke 719-100G also simulates mA signals for troubleshooting 4-20 mA loops, making it a comprehensive diagnostic tool for process instrumentation .
Rugged Design and Low Maintenance: The Fluke 719-100G features unique cleanout ports that reduce pump failures and allow easy cleaning without repair . Its robust construction withstands a 1-meter drop, and the instrument operates across a wide temperature range, ensuring reliability in demanding field environments . The Fluke 719-100G is backed by a 3-year warranty, demonstrating Fluke’s confidence in its durability and long-term performance .
