Emerson 5X00226G3 Ovation I/O Interface Controller – Critical Bridge Between Field Devices and Ovation DCS

Product Overview

The Emerson 5X00226G3 is a high-performance I/O interface controller specifically engineered for Emerson’s renowned Ovation™ Distributed Control System (DCS). As a critical bridge between field devices and the central control system, the Emerson 5X00226G3 manages signal exchange between Ovation controllers and I/O modules, ensuring smooth, reliable, and deterministic plant operations across the most demanding process industries. Within the Ovation DCS architecture, the Emerson 5X00226G3 serves as a key interconnect element that enables seamless communication between control systems and field instruments such as sensors, actuators, transmitters, and valves.Designed with modular flexibility and field-proven reliability, the Emerson 5X00226G3 supports a wide spectrum of signal types—including analog inputs/outputs, digital inputs/outputs, RTD, thermocouple, and pulse inputs—allowing it to integrate effortlessly with diverse field devices. Depending on the chassis configuration, the Emerson 5X00226G3 can manage up to 128 I/O points across multiple I/O modules, consolidating signal conditioning, data acquisition, and control output into a single, compact interface controller. Communication with the higher-level Ovation controller is achieved via the Ovation system backplane bus, minimizing external wiring complexity while maximizing signal integrity.Physically, the Emerson 5X00226G3 is housed in a rugged industrial enclosure measuring 44 × 178 × 114 mm and weighing approximately 0.7 kg. It operates on a 24 V DC power supply delivered through the Ovation I/O chassis backplane and functions reliably across an operating temperature range of 0 °C to +60 °C, with storage tolerance from −40 °C to +85 °C and humidity tolerance of 5% to 95% RH (non-condensing). The module is built for high availability environments, featuring built-in channel monitoring, fault indication, communication verification, and full hot-swappable capability—allowing direct module replacement during live system operation without plant shutdown. With LED indicators for power, status, I/O activity, and fault conditions, the Emerson 5X00226G3 provides at-a-glance operational visibility. Certified to CE, RoHS, and FCC Class A standards, and engineered for DIN rail or panel mounting, the Emerson 5X00226G3 stands as a trusted cornerstone of Emerson Ovation DCS deployments in power generation, petrochemical processing, water treatment, and large-scale manufacturing facilities worldwide.

Category: FUJI

Contact Us WhatsApp / Wechat：+8618150087953
Phone：+86 18150087953
Email：sales@cxplcmro.com

Description

Technical Specifications

Parameter	Value
Product Model	5X00226G3 (also referenced as 5X00226G03)
Manufacturer	Emerson Automation Solutions (formerly Westinghouse)
Product Type	Ovation DCS I/O Interface Controller
System Platform	Emerson Ovation™ Distributed Control System
Primary Function	Signal exchange management between Ovation controller and I/O modules
Supported Signals	Analog I/O, Digital I/O, RTD, Thermocouple, Pulse Input
I/O Point Capacity	Manages up to 128 I/O points (depending on chassis configuration)
Communication Protocol	Ovation System Backplane Bus
Power Supply	24 V DC (via Ovation I/O chassis backplane)
Operating Temperature	0 °C to +60 °C
Storage Temperature	−40 °C to +85 °C
Humidity Range	5% to 95% RH (Non-Condensing)
Diagnostics	Built-in channel monitoring, fault indication, communication verification
Status Indicators	LED for Power, Status, I/O Activity, and Fault
Hot-Swappable	Yes
Electrical Isolation	Channel-to-ground and channel-to-channel isolation
Mounting Type	Ovation I/O Chassis Mount (DIN Rail / Panel Mount options)
Dimensions (L × W × H)	44 × 178 × 114 mm
Weight	0.7 kg
Certifications	CE, RoHS, FCC Class A
Degree of Protection	IP20 (Control Cabinet Installation)
