Description

Product Overview

The DR-100-24 is a versatile and robust DIN rail power supply that acts as the backbone of industrial control systems.It converts a standard AC input voltage(typically 85-264VAC)into a regulated 24V DC output,which is the industry standard for powering control circuits.With a maximum output of 100 Watts(equivalent to 4.2 Amps),the DR-100-24 is capable of powering a wide range of components simultaneously,from a main PLC module to dozens of I/O devices and field sensors.Its compact form factor saves valuable space within control cabinets,while its high efficiency minimizes energy consumption and heat generation.

Engineered with built-in protections,the DR-100-24 safeguards connected equipment against short circuits,overloads,overvoltage,and overheating.This high level of reliability and protection is crucial for ensuring the continuous operation of critical industrial processes.The power supply features a standard green LED indicator for a quick visual status check and an adjustable output voltage range,allowing for fine-tuning to meet specific application requirements.

Technical Specifications

Parameter Name Parameter Value

Product Model DR-100-24

Manufacturer MEAN WELL

Product Type DIN Rail Power Supply(DR Series)

Input Voltage Range 85-264 VAC(Universal AC Input)

Output Voltage 24V DC(Adjustable:24-28V)

Output Power 100 W

Output Current 4.2 A

Efficiency Typically 88%

Protection Features Short Circuit,Overload,Overvoltage,Over-temperature

Mounting DIN rail(TS-35/7.5 or TS-35/15)

Operating Temperature-20°C to+70°C(-4°F to+158°F)

Main Features and Advantages

High Efficiency and Energy Savings:With an efficiency rating of up to 88%,the DR-100-24 converts most of the input energy into usable power.This high efficiency translates into lower operating temperatures,which extends the product’s lifespan,and significant energy savings over its operational life.

Robust Industrial Design:Built to withstand harsh industrial environments,the DR-100-24 is enclosed in a rugged plastic housing.It is designed to be highly resistant to vibration and shock,ensuring reliable performance in demanding applications and machinery.

Comprehensive Protection:The power supply features a complete suite of protection features.In the event of a fault,such as a short circuit or an overload,the unit automatically shuts down to protect itself and the connected load.This self-protection and quick recovery capability enhance system reliability and minimize downtime.

Compact and Easy to Install:The DR-100-24’s sleek,compact design takes up minimal space on a DIN rail,making it easy to integrate into crowded control cabinets.Its simple screw terminal connections allow for quick and hassle-free wiring,speeding up installation and maintenance.

Worldwide Compatibility:With a universal AC input range from 85V to 264V,the DR-100-24 can be used in almost any country without requiring a separate transformer or configuration,making it a globally versatile power solution.

Application Field

The MEAN WELL DR-100-24 is a staple in a vast array of industrial and commercial applications that require a reliable 24V DC power source.

Industrial Automation:Powering PLCs,I/O modules,and control relays in factory automation and process control systems.

Machinery Control:Providing power to sensors,actuators,and solenoids in CNC machines,robotics,and packaging equipment.

Building Automation:Used in control panels for lighting systems,security systems,and HVAC units.

Telecommunications:Powering equipment in telecommunication racks and data centers.

Renewable Energy Systems:Providing auxiliary power in solar and wind power installations.

Related Products

The DR-100-24 is a standalone power supply,but it is often used in conjunction with other components to create a complete industrial control system.Related products include:

MEAN WELL DR-120-24:A higher-wattage version(120W)of the same series.

Industrial DIN Rail Power Supplies:Other models from MEAN WELL and other manufacturers with varying wattages and voltages.

Programmable Logic Controllers(PLCs):Such as those from Siemens,Allen-Bradley,or ABB.

Human-Machine Interfaces(HMIs):Operator panels that display system status.

I/O Modules and Fieldbus Couplers:Devices that connect field sensors and actuators to the PLC.

Control Relays and Contactors:Used for switching high-power loads based on control signals.

Installation and Maintenance

Installation

Before installing the DR-100-24,always ensure that the power supply to the cabinet is disconnected and locked out.The power supply should be mounted vertically on a standard DIN rail to ensure proper heat dissipation through convection.Connect the input wires(L,N)to the screw terminals and the output wires(+V,-V)to the DC output terminals.For safety,ensure the grounding wire is connected to the ground terminal.Verify all connections are secure to prevent loose wiring and potential arcing.

Maintenance

The DR-100-24 is designed to be a”fit and forget”component with a high MTBF(Mean Time Between Failures).Routine maintenance is minimal and primarily involves:

Visual Inspection:Periodically inspect the unit for any signs of physical damage,overheating,or discoloration.

Ventilation Check:Ensure that the ventilation holes on the top and bottom of the unit are not blocked by dust or other debris to allow for proper airflow.

Terminal Tightness:Periodically check the terminal screws to ensure they are still tight and that connections have not loosened due to vibration.

If the status LED(typically green)is not lit,it may indicate a lack of input power or a fault with the unit itself,in which case it should be replaced by a qualified technician.
