Description

Product Overview

The CACR-IR30SGB is a high-performance AC servopack designed as a single-axis servo drive with a power rating of 3.0KW,operating on 200VAC input.This servo drive is engineered to deliver precise motion control,making it a vital component in various industrial automation systems where accuracy and reliability are paramount.

The CACR-IR30SGB integrates advanced control algorithms to ensure smooth speed,torque,and position control,enabling seamless operation with compatible servo motors.Its single-axis design makes it suitable for applications requiring dedicated control of individual motion axes,such as in precision machining,material handling,and automated assembly lines.The CACR-IR30SGB is recognized for its robust performance,efficient power management,and ease of integration,making it a preferred choice for enhancing productivity in industrial settings.

Technical Specifications

Parameter Name

Parameter Value

Product Model

CACR-IR30SGB

Product Type

AC Servo Drive/Servopack

Rated Output Power

3.0KW

Input Voltage

Single-phase 200-240V AC,50/60Hz

Output Current

18A(rms)

Axis Configuration

Single axis

Control Methods

Position,speed,torque control

Communication Interface

RS-485(Modbus compatible)

Operating Temperature

0℃-55℃

Storage Temperature

-20℃-65℃

Dimensions(W×H×D)

120mm×210mm×180mm(approximate)

Weight

Approximately 3.5kg

Protection Features

Overcurrent,overvoltage,undervoltage,overload,overheating,encoder error,short circuit

Control Resolution

1,000,000 pulses/rev(for pulse train input)

Response Frequency

5kHz

Installation Method

DIN rail or panel mounting

Protection Class

IP20(when properly installed)

Certifications

CE,UL,cUL

Main Features and Advantages

High torque output:The CACR-IR30SGB delivers a high torque-to-power ratio,ensuring strong performance even under varying load conditions.This allows it to handle sudden load changes without compromising control precision,making it suitable for heavy-duty applications such as metal forming machinery.

Advanced motion control:Equipped with sophisticated PID control with feedforward compensation,the CACR-IR30SGB minimizes positioning errors and ensures smooth motion transitions.This results in reduced vibration and noise,extending the lifespan of mechanical components in the system.

Energy-efficient operation:The CACR-IR30SGB incorporates regenerative braking technology that recovers excess energy during deceleration,feeding it back into the power supply.This feature reduces overall energy consumption by up to 20%compared to conventional drives in cyclic operation scenarios.

User-friendly configuration:The servo drive offers intuitive parameter setup via compatible software or optional handheld programmers,simplifying commissioning and reducing setup time.It also features auto-tuning functionality that optimizes control parameters based on the connected load,eliminating the need for manual calibration.

Robust protection:The CACR-IR30SGB is equipped with comprehensive protection mechanisms to safeguard both the drive and connected equipment.These include protection against overcurrent,voltage fluctuations,and overheating,ensuring reliable operation even in harsh industrial environments.

Application Field

The CACR-IR30SGB is widely used in precision machining centers,where it controls the movement of cutting tools with high accuracy,ensuring tight tolerances in machined parts.This has led to a reduction in scrap rates by up to 25%in manufacturing facilities utilizing the drive.

In material handling systems,the CACR-IR30SGB regulates the motion of conveyors and robotic arms,enabling precise positioning of materials in warehouses and distribution centers.Its reliable performance has increased throughput by an average of 30%in such applications,as it minimizes downtime due to motion control errors.

The servo drive is also employed in automated assembly lines,where it controls the movement of assembly heads,ensuring precise insertion of components.In the automotive parts manufacturing sector,the CACR-IR30SGB has improved assembly accuracy,leading to a 15%reduction in product defects.Additionally,it finds application in packaging machinery for heavy-duty packaging tasks,maintaining consistent operation even at high production speeds.

Related Products

YASKAWA SGMGH-30ACA61:A 3.0KW servo motor perfectly matched with CACR-IR30SGB for a complete motion control solution.

CACR-IR15SGB:A 1.5KW servo drive in the same series,suitable for applications requiring lower power than CACR-IR30SGB.

CACR-IR50SGB:A 5.0KW servo drive offering higher power capacity than CACR-IR30SGB for more demanding applications.

YASKAWA JUSP-OP02A:Programming cable for connecting a PC to CACR-IR30SGB for parameter configuration and monitoring.

YASKAWA JVOP-182:Handheld programmer designed for on-site setup and diagnostics of CACR-IR30SGB.

YASKAWA SGMAV-04ADA21:400W servo motor compatible with smaller drives in the series,providing a scalable alternative to CACR-IR30SGB for lower power needs.

CACR-IR75SGB:A 7.5KW servo drive in the same product line,ideal for heavy-industry applications beyond the CACR-IR30SGB’s capacity.

Installation and Maintenance

Pre-installation preparation:Before installing the CACR-IR30SGB,ensure the mounting location is dry,clean,and free from excessive vibration.Verify that the power supply meets the drive’s voltage and frequency requirements,and that appropriate circuit protection(such as fuses or circuit breakers)is installed in the supply line.Check all connecting cables for damage and ensure they are rated for the drive’s current and signal requirements.It is also important to confirm that the mounting surface can support the weight of the CACR-IR30SGB and that there is sufficient space around the drive for ventilation.

Maintenance recommendations:The CACR-IR30SGB requires periodic maintenance to ensure optimal performance.Every three months,inspect the drive for dust accumulation on the heat sink and clean it using compressed air if necessary to maintain proper heat dissipation.Check all electrical connections for tightness to prevent loose connections that could cause operational issues.Monitor the drive’s status indicators regularly for error codes,and refer to the user manual for troubleshooting if faults occur.Avoid exposing the CACR-IR30SGB to extreme temperatures or moisture,as this can degrade its performance over time.For firmware updates,use the manufacturer’s recommended software and follow the specified update procedures to avoid drive malfunction.

Product Guarantee

The CACR-IR30SGB comes with a 12-month warranty from the date of installation,or 18 months from the date of manufacture,whichever occurs first.This warranty covers defects in materials and workmanship under normal operating conditions.The manufacturer provides comprehensive technical support through a global network of service centers,offering assistance with installation,configuration,and troubleshooting for the CACR-IR30SGB.Additionally,customers have access to detailed documentation,including user manuals and application guides,to facilitate proper use of the drive.For extended warranty options and specialized support services,customers can contact their local representative,ensuring long-term reliability and performance of the CACR-IR30SGB in their industrial applications.
