BENTLY 3500/50 286566-02 Product Introduction

product overview

BENTLY 3500/50 286566-02 is the core module of the Bently Nevada 3500 monitoring system,designed specifically for monitoring the speed,acceleration,and direction of industrial rotating machinery.This module supports dual channel input and can receive signals from eddy current sensors or magnetic sensors.Through programming,it can achieve functions such as speed monitoring,alarm threshold setting,and zero speed indication.It is widely used in mechanical protection systems in power generation,petrochemicals,metallurgy,and other fields.

technical specifications

Parameter specifications

Model 3500/50 286566-02

Input voltage 24VDC

Input current range 100-400A(input),maximum output 10A

Dimensions 170mm×105mm×32mm

Operating temperature-20°C to+50°C

Storage temperature-40°C to+70°C

Environmental humidity ranging from 5%to 95%(non condensing)

32-bit RISC processor

Support system DCS system

Input signal range+10.0V to-24.0V(standard module),+5V to-11V(insulation module)

Power consumption is usually 5.8W

Main features and advantages

Dual channel monitoring capability

Supports simultaneous reception of two sensor signals,which can be configured for speed,acceleration,or direction monitoring respectively,covering a wide range of industrial scene requirements.

Flexible configuration function

Through the 3500 framework configuration software,the following modes can be programmed:

Speed monitoring and set point alarm

Zero speed indication

Rotor acceleration alarm

Reverse rotation notification

High reliability and safety

Compliant with API 670 standard to ensure compatibility with industrial equipment.

Support triple module redundancy(TMR)configuration to enhance system fault tolerance.

Built in safety barrier option,suitable for installation in hazardous areas.

Data synchronization and scalability

Can output key phase signals to the framework backplane,simplifying system configuration.

Support live plug and unplug maintenance to reduce downtime.

Peak holding function

Record the highest speed value during equipment operation for easy fault tracing and analysis.

application area

Power generation industry:speed and vibration monitoring of steam turbines,generators,and exciters.

Petrochemical and Metallurgy:Mechanical Protection for Compressors,Pumps,and Gearboxes.

Aerospace:dynamic performance analysis of gas turbines and engines.

Paper making and water conservancy:real-time status monitoring of paper machines and water turbines.

Related products

3500/40M:Displacement monitoring module,which collaborates with 3500/50 to achieve comprehensive monitoring of vibration and displacement.

3500/33:16 channel relay module,used for logical control of alarm signals and linkage with external devices.

3500/25:Keyphase module,providing synchronization signals to enhance monitoring accuracy.

3500/53:Overspeed protection module,designed for emergency stop control in high-risk scenarios.
