The Baldor ASR SYN 2-3 is a permanent magnet synchronous AC servo motor engineered for high-precision industrial automation.Part of the Baldor ASR(Advanced Servo Range)series,this motor delivers high torque density,excellent dynamic response,and smooth operation across a wide speed range.It operates on 230 VAC line voltage and is typically paired with compatible servo drives such as Baldor MicroFlex e100,ABB DCx series,or other IEC-compliant servo amplifiers.

Designed for demanding applications like CNC machining,robotics,printing,packaging,and semiconductor handling,the ASR SYN 2-3 features a robust mechanical design,integrated high-resolution encoder,and IP65 protection(standard),making it suitable for harsh industrial environments.

⚙️Key Technical Parameters

Parameter Specification

Model Number ASR SYN 2-3

Manufacturer Baldor Electric Company(now ABB Motion)

Motor Type 3-Phase AC Permanent Magnet Synchronous Servo Motor

Continuous Torque(Tcont)3.0 Nm

Peak Torque(Tpeak)~9.0 Nm(3x overload for short duration)

Rated Power 2.3 kW(~3.0 hp)

Rated Speed 3000 RPM

Maximum Speed 3000 RPM(mechanical limit)

Voltage Class 230 VAC(line-to-line)

Back EMF Constant~50 V/kRPM(typical)

Torque Constant(Kt)~0.95 Nm/A(approx.)

Encoder Type 2500-line incremental quadrature encoder(TTL)with index(Z signal),10,000 counts/rev(quadrature)

Optional Feedback Resolver,Sin/Cos 1 Vpp,or BiSS-C encoder(on request)

Mounting B5(face mount)or B14(flange mount),standard IEC dimensions

Shaft Configuration Keyed shaft with threaded center hole(M12)

Protection Rating IP65(dust-tight and protected against water jets)

Insulation Class Class F(155°C),suitable for high ambient temperatures

Cooling Method Self-ventilated(IC 411)or forced air/water-cooled option

Inertia(Rotor)~0.00045 kg·m²

Weight~12.5 kg

Cable&Connector Typically uses MS/MD series circular connectors(e.g.,15-pin D-sub or M23)for power and feedback

🔧Application Scenarios

🏭CNC Machining Center

A precision CNC milling machine uses the Baldor ASR SYN 2-3 as the spindle motor.Paired with a MicroFlex e100 servo drive,it delivers consistent torque from 0 to 3000 RPM,enabling smooth cutting across various materials.The high-resolution encoder ensures accurate speed control and position feedback during threading and contouring operations.During a high-speed aluminum cut,the motor maintains stability even under sudden load changes,thanks to its high dynamic response.

🤖Robotic Arm Joint Drive

In a 6-axis industrial robot,the ASR SYN 2-3 powers the shoulder joint(Axis 2).Its high torque-to-inertia ratio allows rapid acceleration and deceleration,critical for fast pick-and-place cycles.The IP65 rating protects against coolant mist and dust in the factory environment.The integrated encoder provides real-time position feedback to the robot controller,ensuring repeatability within±0.01°.

💡Technical Principles&Innovative Values

Innovation Explanation

High Torque Density Compact design delivers 3.0 Nm in a relatively small frame,ideal for space-constrained machines.

Sine-Wave Commutation Support Enables smooth,low-vibration operation when paired with compatible drives.

Robust Mechanical Design Reinforced bearings and shaft for radial and axial loads(common in belt/pulley or gearbox drives).

Thermal Protection Built-in PTC thermistor or KTY84 sensor(optional)for overtemperature monitoring.

Interchangeable with Industry Standards Footprint and mounting compatible with other IEC servo motors(e.g.,Siemens,Yaskawa,Mitsubishi).

Drive Compatibility Works with Baldor MicroFlex,ABB DCx,Kollmorgen,Control Techniques,and other servo drives using standard tuning procedures.

🔄Related Product Combination Solutions

Product Purpose

Baldor MicroFlex e100/e150 Compact servo drives optimized for ASR series motors

ABB DCx Series Drives High-performance servo amplifiers for industrial automation

ASR Motor Mounting Kits B5/B14 flanges,coupling kits,mounting brackets

Encoder Feedback Cables Pre-wired cables with M23 or D-sub connectors

ASR SYN 2-2 Lower torque variant(2.0 Nm)for lighter-duty applications

ASR SYN 2-4 Higher torque variant(4.0 Nm)for demanding loads

ABB Motion Studio/Baldor Mint Workbench Software for motor tuning,diagnostics,and commissioning

🛠️Installation,Maintenance&Support

Installation:

Align motor shaft carefully with load(use laser alignment if possible).

Use proper torque on mounting bolts and shaft fasteners.

Connect power(U/V/W)and feedback(encoder)cables per drive manual.

Ground the motor frame securely.

Maintenance:

Check for unusual noise or vibration.

Inspect encoder cables for damage.

Monitor motor temperature(should not exceed 100°C under load).

No routine maintenance required on bearings(lubricated for life,typically 20,000+hours).

Troubleshooting:

Motor not turning?→Check encoder connection,drive enable signal,and phase wiring.

Overheating?→Verify load inertia match,cooling,and duty cycle.

Position error?→Re-tune PID loop or check for mechanical backlash.

📦Availability&Legacy Note

The ASR series has been largely succeeded by ABB’s Omnicore and Mint-based servo systems,but the ASR SYN 2-3 remains in use and available as new surplus,refurbished,or through industrial automation suppliers.

Replacement Tip:For modern upgrades,consider ABB’s M2000 series servos or Kollmorgen AKM2G as drop-in replacements with improved efficiency and connectivity.
