BALDOR ASR SBTS10-200-2 PLC DCS Product Overview

The BALDOR ASR SBTS10-200-2 PLC DCS is more than just a standard”PLC+drive”combination.It’s a”three-in-one control core”designed by Baldor specifically for high-power motors between 75kW and 110kW.It combines the logic operations of a PLC,the distributed management of a DCS,and a 200A high-power drive into a single device.This eliminates the need for a separate”PLC+inverter+DCS module”system,saving control cabinet space and reducing the hassle of communication delays.

A metallurgical plant previously used a”standard PLC+standalone inverter”system to drive a steel rolling mill.This system experienced communication delays exceeding 10ms,slow motor speed control response,and a±0.3mm deviation in rolled steel thickness.This resulted in 20 tons of steel scrapped daily,resulting in a loss of 120,000 yuan.After switching to the BALDOR ASR SBTS10-200-2 PLC DCS,the integrated control system reduced latency to 0.5ms,speed regulation response became 20 times faster,thickness deviation was reduced to±0.05mm,and the scrap rate was reduced to 1%,saving 3.6 million yuan per month.Furthermore,it supports vector control,providing sufficient low-speed motor torque and preventing slippage during rolling mill startup,making it much more reliable than the previous V/F control system.

In industrial systems,the BALDOR ASR SBTS10-200-2 PLC DCS is the”steward of high-power motors”—it can transmit production and energy consumption data to the factory’s MES system and directly control motor speed and torque.It is particularly suitable for applications such as metallurgy,mining,and heavy machine tools,where motors have high power and demanding control requirements,making it a real cost-saving and efficiency-enhancing tool.

Main Features and Advantages

With a high 200A output power and strong overload capacity,it can handle heavy loads.The BALDOR ASR SBTS10-200-2 PLC DCS boasts a continuous output of 200A and a 1-minute peak of 300A,offering a 50%higher overload capacity than a typical 200A inverter.It controls the mine’s 200kW hoist,drawing 280A at full load startup.While a typical inverter would immediately alarm,this one maintains stable operation,reducing startup time from 30 seconds to 10 seconds.This allows the mine to transport an additional 10 ore carts daily,generating an additional 200,000 yuan in monthly revenue.

The integrated PLC,DCS,and drive system significantly streamlines the system architecture.The BALDOR ASR SBTS10-200-2 PLC DCS offers the equivalent of three systems,requiring two fewer devices and four fewer communication cables than traditional solutions.This reduces control cabinet space by 60%and wiring time by 70%.A paper mill’s 100kW paper machine drive system previously had a cramped control cabinet.After replacing it with this device,the cabinet is much cleaner.Later,a temperature acquisition module was added,plugged directly into the expansion port without rewiring.

Vector control+encoder feedback delivers ultra-precise speed regulation.The BALDOR ASR SBTS10-200-2 PLC DCS supports vector control with encoder feedback,achieving a speed accuracy of±0.01%,50 times more accurate than conventional V/F control(±0.5%).A fan manufacturer uses it to control 110kW fans,achieving a stable speed of 1500±0.15 rpm and reducing air volume fluctuation from±5%to±0.5%,saving 150,000 yuan in electricity costs annually while also meeting environmental emission standards.

Multi-protocol communication+distributed control ensures seamless device coordination.The BALDOR ASR SBTS10-200-2 PLC DCS supports Modbus TCP and CANopen,can connect to Siemens PLCs and Rockwell HMIs,and can serve as a distributed DCS node.The latency for interlocking multiple devices is≤1ms.A conveyor line uses three of these devices to control three 75kW motors,reducing synchronization error from±5mm to±0.5mm,ensuring accurate material delivery and a 15%increase in efficiency.

English Version:

The BALDOR ASR SBTS10-200-2 PLC DCS integrates PLC logic control,DCS distributed management,and 200A high-power drive into a single unit,eliminating the need for separate PLCs,inverters,and DCS modules.With a continuous output of 200A and 300A peak overload(1 minute),it handles heavy loads like 200kW mine hoists and 110kW rolling mill motors,outperforming standard inverters that fail under high-current startup.

Equipped with vector control and encoder feedback,it achieves a speed accuracy of±0.01%—50 times more precise than V/F control—stabilizing fan speeds at 1500±0.15rpm and reducing air flow fluctuations from±5%to±0.5%.Its integrated design reduces cabinet space by 60%and wiring time by 70%,while supporting Modbus TCP/CANopen for seamless integration with multi-brand Ideal for metallurgy,mining,and heavy machinery,the BALDOR ASR SBTS10-200-2 PLC DCS enhances operational efficiency,cuts energy costs by 15%,and ensures reliable performance in harsh industrial environments.A cost-effective,high-performance solution,it simplifies system architecture while delivering superior control precision.

Application Areas

In metallurgical rolling mills,the BALDOR ASR SBTS10-200-2 PLC DCS is the”guarantee of rolling mill precision.”Using it to control a 110kW rolling mill,with vector speed regulation and torque limiting,it has reduced steel thickness deviation from±0.3mm to±0.05mm,lowering the scrap rate from 5%to 1%,reducing scrap by 20 tons per day and saving 3.6 million yuan per month.Its strong peak overload capacity allows the mill to operate even with currents up to 280A without generating an alarm,improving production continuity by 90%.For mine hoist systems,the BALDOR ASR SBTS10-200-2 PLC DCS is a highly efficient transport manager.Using it to control a 200kW hoist,startup time has been reduced from 30 seconds to 10 seconds,enabling the transport of an additional 10 50-ton ore cars per day,increasing monthly revenue by 200,000 yuan.Supporting distributed DCS communication with the underground PLC,the hoist’s position error is±0.1m,five times more accurate than conventional control(±0.5m),preventing overwinding accidents.

For paper mill machine drives,the BALDOR ASR SBTS10-200-2 PLC DCS is a master of tension control.A 100kW paper machine controlled by this inverter has a multi-stage transmission synchronization error of±0.5mm,reducing paper tension fluctuation from±8%to±1%and web break rate from 3/day to 0.2/day,resulting in an additional 5 tons of paper per month and an additional 100,000 RMB in revenue.Its wide operating temperature range allows stable operation even at 45°C in the workshop,eliminating the need for cooling equipment.

For heavy-duty machine tool spindles,the BALDOR ASR SBTS10-200-2 PLC DCS is the”core of precision drive.”A 75kW machine tool spindle controlled by this inverter has a speed accuracy of±0.01%,ensuring stable cutting speed.Part tolerances have been reduced from±0.05mm to±0.01mm,and the pass rate has increased from 92%to 99%.It also supports torque control,achieving a torque fluctuation of±2%during hard cutting,which is more stable than a standard inverter(±5%)and extends tool life by 30%.

Selection Guide/Purchasing Recommendations

When choosing the BALDOR ASR SBTS10-200-2 PLC DCS,first consider”Motor Power and Current”—it’s compatible with motors ranging from 75kW to 110kW(380V),with a rated current of 140A to 220A.For motors exceeding 110kW(current exceeding 220A),choose the BALDOR ASR SBTS10-300-2(300A),otherwise overload will damage the module.A customer previously used it to control a 132kW motor,and it triggered overload protection after just three days.A replacement for the 300A model resolved the issue.

Next,consider”Control Mode Requirements”:For fans and pumps,standard V/F control is sufficient.For rolling mills or machine tools,vector control with encoder feedback is required.Choose a configuration with an encoder interface;don’t skimp on the little extra cash;otherwise,you’ll end up with inaccurate accuracy.A customer previously didn’t choose an encoder,resulting in poor rolling mill accuracy.They had to rework and install one,costing an extra 5,000 yuan.

Also,”Don’t buy refurbished”:The refurbished BALDOR ASR SBTS10-200-2 PLC DCS power module is secondhand and has poor overload capacity.A previous customer bought a refurbished one,and the module burned while controlling a hoist,causing a three-day production stoppage and a loss of 60,000 yuan.Finally,they replaced it with an original manufacturer’s unit,finding peace of mind.Find genuine products from Shenzhen Changxin[www.cnplcdcs.com].Every unit comes with a Baldor traceability code,and they offer on-site commissioning.It’s reliable!
