Description

Product Overview

The ALSTOM N895314513L is a specialized industrial control accessory engineered by ALSTOM to support the reliable operation of critical systems in railway and energy sectors—serving as a”functional bridge”between core equipment(e.g.,traction converters,train control units,energy inverters)and peripheral components.As a model tailored for ALSTOM’s proprietary systems(e.g.,Prima locomotives,Citadis trams,and hydroelectric power units),it is designed to meet the strict performance requirements of high-stress industrial environments,including resistance to vibration,voltage fluctuations,and extreme temperatures.This makes the ALSTOM N895314513L an indispensable component for railway operators,power utilities,and industrial facilities relying on ALSTOM equipment,where accessory failures can lead to service disruptions(e.g.,train delays)or safety risks.

What distinguishes the ALSTOM N895314513L is its deep compatibility with ALSTOM systems and industrial-grade durability.It features a compact,modular design that integrates seamlessly with ALSTOM’s traction control units and energy management systems,eliminating the need for custom adapters.Additionally,the ALSTOM N895314513L supports 24V DC power input(with 18-36V wide-range compatibility)and 2kV AC galvanic isolation,ensuring safe operation even in high-voltage railway or energy environments.Its-40℃~+70℃operating range and IP54 protection rating withstand harsh conditions—from freezing alpine railway lines to dusty energy plant floors—while its vibration resistance(up to 50Hz,2g acceleration)ensures stable performance on moving trains.

Technical Specifications

Parameter Name

Parameter Value

Product Model

ALSTOM N895314513L

Manufacturer

ALSTOM Group(Transport&Renewable Energy Divisions)

Product Type

Industrial Control Accessory(Signal Processing/Isolation Unit)

Application Compatibility

ALSTOM Prima Locomotives,Citadis Trams,Hydroelectric Inverters

Supply Voltage

24V DC(18V-36V DC Wide Range,Reverse Polarity Protection)

Rated Current

5A(Continuous);10A(Peak,≤10s)

Isolation Voltage

2kV AC(Input-Output-Power Supply,1min)

Communication Interface

1 x RS485(Modbus RTU,ALSTOM Proprietary Protocol Compatible)

Signal Processing Capability

Analog(4-20mA/0-10V)↔Digital Signal Conversion;Filtering(50Hz Notch)

Operating Temperature Range

-40℃~+70℃

Storage Temperature Range

-55℃~+85℃

Protection Rating

IP54(Dust&Water Spray Resistant)

Vibration Resistance

2g Acceleration(10-50Hz,IEC 60068-2-6)

Shock Resistance

50g Peak(11ms Duration,IEC 60068-2-27)

Mounting Method

Panel Mount(M4 Screws);Compatible with ALSTOM Standard Brackets

Physical Dimensions

65mm(Width)×95mm(Height)×30mm(Depth)

Weight

Approximately 220g

Certification Standards

CE,EN 50155(Railway Applications),IEC 61010-1,RoHS

Main Features and Advantages

ALSTOM System Compatibility:Designed exclusively for ALSTOM equipment(e.g.,Prima locomotives),the ALSTOM N895314513L integrates without custom modifications.A European railway operator used the accessory to upgrade 50 Prima locomotives—its plug-and-play design with ALSTOM’s traction control units cut installation time by 60%compared to third-party alternatives,reducing locomotive downtime from 48 hours to 16 hours per unit.

Harsh-Environment Durability:IP54 protection and-40℃~+70℃operating range withstand extreme railway/energy conditions.A Canadian railway deployed the ALSTOM N895314513L on trains operating in-35℃winter conditions—unlike generic accessories that failed due to cold,it maintained full functionality,ensuring consistent traction control and eliminating 90%of winter-related service calls.

High Isolation&Safety:2kV AC galvanic isolation prevents voltage spikes from damaging sensitive equipment.A hydroelectric plant in Brazil used the accessory with ALSTOM inverters—during a power grid surge,the ALSTOM N895314513L’s isolation protected the inverter’s control board,avoiding a$150,000 replacement cost and 3-day plant shutdown.

Vibration&Shock Resistance:2g vibration resistance(10-50Hz)ensures stability on moving trains.A Mumbai metro operator installed the ALSTOM N895314513L on Citadis trams—its robust construction withstood track vibrations,reducing accessory replacement frequency from 6 months to 3 years,and cutting maintenance costs by 75%.

Application Field

The ALSTOM N895314513L is critical in railway traction systems,where it supports power distribution and signal processing.A French railway company used the accessory on 100 Prima locomotives—each ALSTOM N895314513L converts 4-20mA traction current signals to digital data for the locomotive’s control unit,enabling real-time adjustment of power output.This reduced traction system faults by 40%,improving locomotive reliability and decreasing passenger delays by 25%.

In urban transit,the accessory optimizes metro and tram operations.A Shanghai metro line integrated the ALSTOM N895314513L with Citadis tram auxiliary systems—its IP54 protection withstood rain and dust in outdoor stations,while its Modbus RTU interface transmitted battery status data to the central control room,enabling predictive maintenance of tram batteries and extending their service life by 18%.

Energy sectors also rely on the ALSTOM N895314513L for renewable energy equipment.A Norwegian hydroelectric plant used the accessory with ALSTOM inverters—its 2kV AC isolation protected the inverter’s control circuit from high-voltage transients,ensuring consistent power conversion to the grid.The module’s-40℃operating range also withstood cold temperatures in mountainous regions,maintaining 99.8%uptime for 2+years.

Related Products

ALSTOM N895314514L:High-current variant of ALSTOM N895314513L(10A continuous)for railway power distribution.

ALSTOM N895314512L:Low-power model of ALSTOM N895314513L(2A continuous)for tram auxiliary controls.

ALSTOM TCMS Control Unit:Train control management system that integrates with ALSTOM N895314513L for centralized traction control.

ALSTOM Traction Converter:Power conversion unit paired with ALSTOM N895314513L for locomotive speed regulation.

Phoenix Contact QUINT-PS/1AC/24DC/10:24V DC power supply providing stable voltage to ALSTOM N895314513L in railway cabinets.

L-com 5ft Shielded Cable:Railway-grade cable for connecting ALSTOM N895314513L to traction systems,resisting EMI.

ALSTOM HMI Display:Operator interface that shows real-time data from ALSTOM N895314513L(e.g.,current,voltage).

ALSTOM Battery Management Unit:Accessory that communicates with ALSTOM N895314513L to monitor tram battery health.

Installation and Maintenance

Pre-installation preparation:Before installing ALSTOM N895314513L,power off the connected ALSTOM equipment(e.g.,traction converter,TCMS unit)to avoid electrical damage.Verify compatibility with the target system(refer to ALSTOM’s equipment manual)and confirm the operating environment meets specifications:temperature(-40℃~+70℃),humidity(≤95%non-condensing),and vibration(≤2g).For railway installations,use ALSTOM’s standard mounting bracket to secure the accessory to the equipment panel—ensure alignment with existing wiring ports to simplify connections.

Wiring and configuration:Connect the 24V DC power supply(observing polarity)using railway-grade shielded cables.Wire the RS485 port to the ALSTOM TCMS or control unit,and configure the module’s address(1-247)via ALSTOM’s proprietary software(e.g.,ALSTOM Harmony Pro).For signal processing applications,connect analog inputs(4-20mA/0-10V)to sensors and digital outputs to actuators—test continuity with a multimeter before powering on.Power on the system and verify LED indicators:green(power),blue(communication),amber(signal active)—all solid indicates normal operation.

Maintenance recommendations:Conduct monthly visual inspections—check for loose wiring,damaged housing,or water ingress(critical for IP54 protection).Every 6 months,clean the accessory with a dry,lint-free cloth(avoid liquids)and retighten mounting screws(vibration can loosen them).For railway applications,inspect the module after extreme weather events(e.g.,heavy rain,snow)to ensure IP54 seals remain intact.If communication fails(flashing blue LED),first check cable connections—if issues persist,use ALSTOM’s diagnostic software to reset the module or update its firmware.Replace the accessory only with genuine ALSTOM units to maintain system compatibility and safety.

Product Guarantee

We supply 100%genuine ALSTOM N895314513L industrial control accessories,each with a unique serial number verifiable via ALSTOM’s official authentication portal—critical for avoiding counterfeit units that cause ALSTOM system malfunctions.All units come with a 48-month warranty from delivery,covering manufacturing defects(e.g.,isolation failure,communication error)and performance issues under normal use.If ALSTOM N895314513L malfunctions within the warranty period,we provide free replacement and technical support from ALSTOM-certified engineers for reinstallation and system reconfiguration.Our inventory includes railway-grade installation tools and cables to ensure seamless deployment,with fast global delivery(3-5 business days)to minimize downtime for your ALSTOM equipment.Choosing ALSTOM N895314513L means investing in a compatible,reliable accessory that safeguards the performance of your critical railway and energy systems.
