Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | SDCS-CON-1 |
| Manufacturer | ABB |
| Part Number | 3BSE006196R1 |
| Product Type | Central Control Board / CPU Module |
| System Compatibility | ABB DCS500, DCS600 DC Drive Systems |
| Supply Voltage | 24 V DC |
| Typical Current Consumption | Approx. 2 A |
| Control Signal Output | 0 to 10 V DC |
| Communication Interfaces | RS-485, Fieldbus (via option modules) |
| Supported Protocols | Modbus RTU, Profibus, CANopen |
| Data Processing Cycle | ≤ 15 ms |
| Operating Temperature | –20 °C to +60 °C |
| Storage Temperature | –40 °C to +85 °C |
| Relative Humidity | 5–95% non-condensing |
| Protection Class | IP20 |
| Dimensions (W × H × D) | Approx. 250 × 180 × 30 mm |
| Weight | Approx. 0.3 kg |
Main Features and Advantages
High-performance DC drive control: The ABB SDCS-CON-1 3BSE006196R1 is engineered to deliver precise and stable control of DC motors in demanding industrial applications. It executes advanced control algorithms for speed and torque regulation with a fast processing cycle of ≤15 ms, ensuring rapid response to load changes and process disturbances. This capability is critical for applications like rolling mills and large fans where control stability is paramount.Robust communication and integration: The board serves as the communication hub for the DC drive system. It features built-in RS-485 serial communication and supports popular industrial fieldbus protocols such as Modbus RTU, Profibus, and CANopen through plug-in option modules. This flexibility allows the ABB SDCS-CON-1 3BSE006196R1 to integrate seamlessly into diverse automation architectures, enabling real-time data exchange with PLCs, DCS, and SCADA systems for centralized monitoring and control.Industrial ruggedness and reliability: Designed for continuous operation in harsh conditions, the module operates reliably within a wide temperature range of –20°C to +60°C and high humidity environments. Its robust construction and comprehensive self-diagnostic functions, including monitoring of power supply, I/O status, and communication links, contribute to high system availability and reduced maintenance downtime.
Application Field
The ABB SDCS-CON-1 3BSE006196R1 control board is primarily deployed in heavy industries that rely on high-power DC drive systems for critical process control. In the metals industry, it is extensively used in rolling mill drives, where precise speed and torque control of DC motors are essential for metal forming processes. The board ensures smooth acceleration and deceleration, maintaining consistent tension and speed synchronization across multiple stands.In mining and material handling, the ABB SDCS-CON-1 3BSE006196R1 controls DC motors for large hoists, conveyors, and crushers, providing the high starting torque and robust performance required for heavy-load applications. It is also widely used in cement production for kiln drives and in power plants for boiler feed pump controls. The module’s reliability and communication capabilities make it suitable for modernizing legacy DC drive systems in these sectors, extending their service life while maintaining compatibility with existing motor and power infrastructure.
