ABB RTAC-01 SP Kit: Complete Hardware for Drive Encoder Feedback Integration

The ABB RTAC-01 (Option SP Kit) is a pulse encoder interface module designed for integration with ABB’s ACS/ACH series variable frequency drives. It provides a dedicated, high-performance interface for incremental pulse encoders, enabling the drive to perform precise closed-loop speed control, position control, or simple speed verification, which is essential for synchronous motor applications, high-performance speed regulation, and basic positioning tasks.

Category: FUJI

Contact Us WhatsApp / Wechat：+8618150087953
Phone：+86 18150087953
Email：sales@cxplcmro.com

Description

Application Scenarios:In a textile factory, a spinning machine driven by an ACS800 with a synchronous reluctance motor required extremely precise and stable speed control to maintain consistent yarn quality. Using only open-loop sensorless control resulted in slight speed variations under changing load, leading to yarn thickness inconsistencies. By installing the ABB RTAC-01 pulse encoder interface and mounting an encoder to the motor shaft, the drive transitioned to true closed-loop flux vector control. The drive could now regulate speed with an accuracy of 0.01% of rated speed, completely eliminating the speed drift. This resulted in a measurable 15% reduction in yarn defects and allowed the machine to operate at its optimal design speed, increasing throughput.

Parameter:

Main Parameters	Value/Description
Product Model	ABB RTAC-01 (Option SP Kit)
Manufacturer	ABB Drives
Product Category	Encoder Interface Module / Feedback Option Kit
Compatible Drive Series	ACS 600, ACS 800, ACH 400, ACH 500, ACH 600 (Verify specific model compatibility)
Encoder Type	Incremental Encoder (TTL/HTL compatible)
Input Signals	Differential channels: A, /A, B, /B, Z, /Z (Zero marker)
Supply Voltage for Encoder	Typically +5 VDC or +10-30 VDC (selectable), sourced from the module.
Maximum Input Frequency	High (e.g., 300 kHz), suitable for high-resolution encoders on fast motors.
Output to Drive	Pulse trains processed and passed to the drive’s main controller (e.g., RMIO board) for speed calculation.
Primary Function	Provides high-resolution motor speed and direction feedback for closed-loop control.
Module Form	Plug-in card for installation in the drive’s I/O or communication slot.
Kit Contents	Typically includes the RTAC-01 interface board, mounting hardware, and connector(s).
Key Benefit	Enables flux vector control without an external feedback card, improving speed accuracy and low-speed torque.
