ABB REF615C-D HCFCACABANB2BAN1XD IEC 61850-Compliant Feeder Management Relay with HMI and Ethernet

Description

Application Scenarios

At a large automotive manufacturing plant in Germany, repeated arc flash incidents in 10 kV switchgear caused production halts and safety concerns. The legacy electromechanical relays offered no arc detection or fast tripping capability. After upgrading to the REF615C-D HCFCACABANB2BAN1XD, engineers enabled its integrated arc protection function using fiber-optic sensors installed inside critical compartments. During a subsequent insulation failure, the REF615C-D HCFCACABANB2BAN1XD detected the arc within 1 ms and issued a trip command in under 4 ms—containing the fault before catastrophic damage occurred. This intervention prevented an estimated €2M in equipment loss and avoided a multi-day line shutdown. In this real-world deployment, the REF615C-D HCFCACABANB2BAN1XD proved to be not just a protector, but a guardian of personnel safety and operational continuity.

Technical Principles and Innovative Values

Innovation Point 1: Sub-Cycle Arc Flash Mitigation – When equipped with arc sensors, the REF615C-D HCFCACABANB2BAN1XD uses light intensity + overcurrent coincidence logic to trigger tripping in <4 ms, far faster than conventional breakers—limiting incident energy to survivable levels per IEEE 1584.

Innovation Point 2: True IEC 61850 Native Architecture – Unlike retrofitted relays, this unit implements IEC 61850 from the ground up, enabling seamless GOOSE messaging for breaker failure schemes and sampled value (SV) integration without gateways.

Innovation Point 3: Adaptive Protection Logic – Features load-encroachment blocking, cold-load pickup immunity, and auto-adaptive earth-fault settings that adjust based on system grounding mode—reducing nuisance trips in dynamic grids.

Innovation Point 4: Embedded Diagnostics & Asset Health – Continuously monitors CT saturation, VT fuse failure, and internal hardware status, logging events with time-stamped waveforms for post-fault analysis—turning protection into predictive insight.

Application Cases and Industry Value

In a solar farm in Australia integrating 30 MW of PV into a rural 33 kV network, grid instability during cloud transients caused frequent earth-fault misoperations. The utility replaced basic overcurrent relays with ABB REF615C-D HCFCACABANB2BAN1XD units featuring sensitive earth-fault (SEF) and directional overcurrent (67N) functions. The relays’ adaptive settings distinguished between capacitive charging currents and true faults, eliminating false trips while maintaining <100 ms clearance for genuine events. Over 12 months, availability increased by 99.98%, and remote configuration via IEC 61850 reduced site visits by 70%. Field engineers noted, “It’s the first relay that understands the difference between sunshine and a short circuit.”

Related Product Combination Solutions

REF615C-D HCFCACABANB2BAN1XD: Base model; pair with ARC615 arc sensor modules for full arc flash protection.

REF620: Higher-end successor with more advanced synchrophasor (IEEE C37.118) and cybersecurity features.

PCM600: ABB’s engineering tool for configuring, testing, and commissioning REF615C-D relays offline.

RED615: Dedicated line differential protection relay for feeder ends requiring unit protection.

TPU600: Portable test unit that validates REF615C-D settings and timing accuracy in the field.

ABB Ability™ Electrical Distribution Control System: Cloud platform that aggregates data from REF615C-D relays for fleet-wide visibility.

REF542plus: Legacy compact relay; useful reference during modernization projects replacing older ABB protection.

LTM615: Motor protection variant in the same 615 family—ideal for mixed feeder/motor cabinets.

Installation, Maintenance, and Full-Cycle Support

Installation of the REF615C-D HCFCACABANB2BAN1XD follows standard panel cutout dimensions (177 × 266 mm), with rear terminals supporting screw or plug-in wiring. Commissioning is accelerated via ABB’s PCM600 software, which auto-generates IEC 61850 CID files and performs virtual injection tests. For arc protection, ensure fiber-optic loops are routed away from sharp bends and terminated cleanly to avoid signal loss.

Routine maintenance includes annual verification of CT/VT circuits and arc sensor integrity using the built-in self-test function. The relay’s front-panel HMI allows local viewing of phasors, event logs, and oscillography—no laptop required for basic diagnostics. Should replacement be needed, the modular design enables hot-swap in redundant systems, and configuration backup via USB ensures zero re-engineering. We supply only factory-tested REF615C-D HCFCACABANB2BAN1XD units, validated for all protection functions, communication protocols, and arc response timing. Each unit includes a full test report and is backed by a 24-month warranty with global technical support.

Contact us for a customized solution—whether you’re hardening your switchgear against arc flash, modernizing to IEC 61850. or integrating renewables into a resilient grid, the REF615C-D HCFCACABANB2BAN1XD delivers intelligent, secure, and life-saving protection where it matters most.
