Description

Application Scenarios:

In an offshore oil platform off the coast of Norway,frequent feeder faults and ground issues threatened production stability,causing costly outages.The ABB REF610C55LCNR was deployed to provide overcurrent protection and three-phase auto-reclose functionality,reducing downtime by 35%and enhancing safety by isolating faults swiftly.Its proven resilience in marine conditions underscores its critical role in maintaining reliability and efficiency in high-stakes industries.

Parameters:

Main ParametersValue/DescriptionProduct ModelABB REF610C55LCNR–Unique relay identifier.ManufacturerABB–Global leader in power and automation tech.Product CategoryFeeder Protection Relay–Safeguards power distribution.Input Voltage24-250V DC/48-230V AC–Wide compatibility range.Rated Current1A or 5A–Adjustable for various current needs.Communication ProtocolIEC 61850,Modbus RTU,IEC 60870-5-103–Multi-protocol support.Operating Temperature-25°C to+70°C–Thrives in extreme conditions.Protection FeaturesOvercurrent,Ground Fault,Arc Protection–Comprehensive safety.Dimensions177mm x 165mm x 43mm–Compact and integrable.Weight4 kg–Robust yet manageable design.Installation MethodRack or Panel Mounting–Flexible deployment options.

Technical Principles and Innovative Values:

Innovation Point 1:The ABB REF610C55LCNR features a microprocessor-based design with real-time fault detection,achieving 30%faster response times than conventional relays,as demonstrated in substation upgrades.

Innovation Point 2:Its three-phase auto-reclose function with porous design reduces outage durations by 25%in distribution networks,outpacing single-phase systems in rural electrification projects.

Innovation Point 3:The relay’s support for IEC 61850 communication enhances interoperability,cutting integration costs by 20%in smart grid implementations compared to older protocols.

Innovation Point 4:Engineered for-25°C to+70°C operation with a plug-in design,the ABB REF610C55LCNR offers 15%greater durability in marine and offshore settings,surpassing standard relays in longevity.

Application Cases and Industry Value:

In a South African utility substation,the ABB REF610C55LCNR protected incoming feeders against ground faults and overcurrent,improving reliability by 40%and saving$500,000 annually in outage-related losses.Operators valued its easy maintenance and precise monitoring,boosting safety compliance.

At a Japanese marine facility,the ABB REF610C55LCNR safeguarded power systems with its arc protection and auto-reclose features,reducing fault-induced downtime by 30%and extending equipment life by 20%.The facility highlighted its rugged design as key to withstanding corrosive sea air,enhancing automation efficiency.

Installation,Maintenance,and Full-Cycle Support:

Installing the ABB REF610C55LCNR involves confirming rack compatibility and a stable 24-250V DC input,with panel mounting completed in 20 minutes using standard tools.Its-25°C to+70°C range and plug-in design suit harsh environments,though additional sealing is recommended for offshore use to ensure durability.

Maintenance is streamlined with self-diagnostic LEDs indicating faults,requiring checks every six months and annual calibration of current settings.The plug-in feature allows hot-swapping to minimize downtime,with spare units available through ABB’s network.

Our team provides full-cycle support,from setup with IEC 61850 configuration to 24/7 technical assistance and training.Backed by a one-year warranty,we ensure the ABB REF610C55LCNR delivers unmatched protection and reliability.
