ABB Power Supply Module for ACS800 and DCS800 Drive Systems

Product Overview

The NGPS-02C is a high-performance auxiliary power supply module manufactured by ABB, designed specifically to provide stable 24V DC control power for ABB drive systems including the ACS600, ACS800, and DCS800 series . This module functions as the critical power backbone for drive control circuits, converting incoming AC mains voltage (typically 85-264V AC) into a regulated 24V DC output that powers the RMIO control board, operator panels, auxiliary relays, and excitation circuits . As a key component of ABB’s drive architecture, the NGPS-02C ensures that control electronics receive clean, isolated power independent of the main drive power stage, enhancing system reliability and operational stability.

The NGPS-02C represents an upgrade from its predecessor, the NGPS-02, featuring improved wide-range input voltage tolerance that makes it particularly suitable for installations in regions with significant grid voltage fluctuations . This power supply module is designed for cabinet installation using DIN rail or dedicated mounting brackets, and is not hot-swappable, requiring proper power-down procedures for installation or replacement . The NGPS-02C incorporates comprehensive protection features including input overvoltage/undervoltage protection, output overcurrent limiting, short-circuit protection, and thermal shutdown, ensuring reliable operation in demanding industrial environments. With a typical power capacity of approximately 240W and output current capability of around 10A, the NGPS-02C provides ample power for most drive control systems .

Category: FUJI

Contact Us WhatsApp / Wechat：+8618150087953
Phone：+86 18150087953
Email：sales@cxplcmro.com

Description

Technical Specifications

Parameter Name	Parameter Value
Product Model	NGPS-02C
Manufacturer	ABB
Product Type	Auxiliary Power Supply Board / Control Power Module
Compatible Series	ACS600, ACS800, DCS800, DCS400
Input Voltage	85-264V AC, 47-63Hz
Output Voltage	24V DC (typical)
Output Current	~10A (typical, dependent on drive cabinet configuration)
Power Capacity	~240W (typical operating condition)
Efficiency Rating	Up to 94%
Protection Functions	Overvoltage, Undervoltage, Overcurrent, Short-Circuit, Overtemperature
Mounting Type	DIN Rail or Dedicated Bracket
Protection Class	IP20
Operating Temperature	-10°C to +60°C (typical industrial cabinet)
Storage Temperature	-20°C to +70°C
Dimensions	Approx. 120 x 100 x 35 mm
Weight	Approx. 0.4 – 0.5 kg
Isolation	Electrical isolation between input and output
Indicator	Board LED (Power/Status)

Main Features and Advantages

Wide-range AC input for global compatibility: The NGPS-02C accepts a broad input voltage range from 85V to 264V AC at 47-63Hz, making it suitable for use across different regions with varying electrical standards . This universal input capability is particularly valuable for OEMs and multinational facilities that standardize on a single power supply module for drive systems worldwide. The module’s tolerance for grid fluctuations ensures continued operation even in facilities with unstable power conditions, reducing the risk of unplanned downtime.

Comprehensive protection and safety features: The NGPS-02C incorporates multiple layers of protection including input overvoltage/undervoltage detection, output overcurrent limiting, short-circuit protection, and thermal shutdown . These protective mechanisms safeguard both the power supply and the downstream control electronics from damage due to electrical faults or abnormal operating conditions. The electrical isolation between input and output circuits prevents ground loops and protects sensitive control electronics from high-voltage transients .

High-efficiency power conversion: With efficiency ratings reaching up to 94%, the NGPS-02C minimizes power loss and heat generation, contributing to reduced cabinet cooling requirements and lower operational costs . The efficient design also extends the service life of internal components by reducing thermal stress, enhancing long-term reliability in continuous operation applications.

Board-level status indication: The NGPS-02C features an on-board LED indicator that provides immediate visual feedback on power and operational status . This diagnostic capability simplifies troubleshooting and reduces mean time to repair by allowing maintenance personnel to quickly verify power availability without requiring external test equipment.

Proven reliability in drive applications: The NGPS-02C is field-proven across thousands of ABB drive installations worldwide, with a design that prioritizes long-term reliability and stable output under varying load conditions . The module’s robust construction and conservative component ratings ensure dependable operation in demanding industrial environments including steel mills, paper machines, and material handling systems.
