Description
Application Scenarios
A municipal water pumping station faced frequent control system failures due to electrical noise and humidity. Engineers replaced the existing unreliable controller with the ABB PM630 (3BSE000434R1) CPU. The module’s robust industrial design and support for remote I/O (via the S500 series) allowed it to handle the pump sequencing and level control logic reliably. The built-in RS-232/RS-485 port enabled seamless integration with the existing telemetry system for remote monitoring. This upgrade resulted in zero unplanned downtime over two years and improved the station’s operational visibility.
Parameter
| Main Parameter | Value / Description |
|---|---|
| Product Model | ABB PM630 (3BSE000434R1) |
| Manufacturer | ABB |
| Product Category | PLC CPU Processor Module (Advant Controller 31 / OCS) |
| CPU & Processing | 16-bit industrial microcontroller |
| Program Memory | Up to 32 KB (EPROM) / 64 KB (EEPROM with MB510 support) |
| Data Memory (RAM) | 8 KB (typical) |
| Communication Ports | 1x RS-232 / RS-485 serial port (for programming and HMI) |
| I/O Expansion | Supports local and remote I/O modules (S500 series) via expansion bus |
| Programming Standard | IEC 61131-3 (LD, FBD, ST, IL, SFC) |
| Real-Time Clock (RTC) | Yes, built-in |
| Supply Voltage | 24 V DC |
| Power Consumption | Approx. 3 W |
| Operating Temperature | 0 °C to +60 °C |
| Mounting | Rack-mounted (AC 31 rack) |
| Dimensions (LxHxW) | ~310.5 mm x 38.7 mm x 238.5 mm |
| Weight | ~1.2 kg |
