ABB PM554-T A1 High Efficiency IP20 Power Supply

Description

The ABB PM554-T A1 is a compact, high-efficiency DIN Rail Mount Power Supply Module designed to provide reliable 24V DC power for industrial control systems, particularly for ABB’s AC500 PLC family (e.g., AC500-eCo series). With a wide input voltage range (85-264V AC) and a rated output of 5A (120W), it ensures stable operation in environments with fluctuating mains power. Its slim design and high efficiency (≥95%) make it ideal for space-constrained control cabinets in manufacturing and process automation.

Category: FUJI

Contact Us WhatsApp / Wechat：+8618150087953
Phone：+86 18150087953
Email：sales@cxplcmro.com

Description

Application Scenarios

In an automotive assembly line’s control cabinet, the ABB PM554-T A1 is mounted on a DIN rail alongside an ABB AC500 PM554-T PLC CPU and I/O modules. It takes the unstable 220V AC plant mains, converts it to a clean 24V DC, and powers the PLC’s CPU, digital output modules, and sensor arrays. Its wide input range allows it to handle voltage sags and surges without dropping out, ensuring continuous operation of the conveyor and robotic control logic.

Parameter

Main Parameters	Value/Description
Product Model	PM554-T A1
Manufacturer	ABB
Product Category	DIN Rail Power Supply (Switched Mode)
Input Voltage	85 – 264 V AC (Universal Input)
Input Frequency	50/60 Hz
Output Voltage	24 V DC (Regulated)
Rated Output Current	5 A
Rated Power	120 W (approx.)
Efficiency	≥ 95% (Typical)
Cooling Method	Natural Convection (Fanless)
Protection Class	IP20 (Chassis)
Operating Temperature	-25°C to +60°C (with derating)
Storage Temperature	-40°C to +85°C
Mounting	DIN Rail (TH35) or Panel Mount
Dimensions (W×H×D)	~100 × 35 × 120 mm (approx.)
Weight	~0.5 kg
Certifications	CE, UL, cULus, RoHS (Industrial)

Technical Principles and Innovative Values

The ABB PM554-T A1 utilizes advanced switched-mode power supply (SMPS) technology to deliver a stable DC bus for sensitive control electronics.
