ABB PFTL101B 2.0KN Weighing Sensor

Description

​Product Overview​​

The​​ABB PFTL101B 2.0KN​​is a high-precision weighing sensor and load cell designed for accurate force and weight measurement in industrial applications.This robust sensor utilizes strain gauge technology to deliver reliable performance in demanding environments,providing precise measurement capabilities for various industrial weighing and force monitoring applications.The​​PFTL101B 2.0KN​​represents ABB’s commitment to quality measurement solutions that ensure operational efficiency and process reliability across multiple industries.

As part of ABB’s comprehensive measurement instrumentation portfolio,the​​ABB PFTL101B 2.0KN​​offers a 2.0 kilonewton capacity with exceptional accuracy and stability.The sensor features a durable construction typically employing stainless steel or other corrosion-resistant materials,ensuring long-term performance even in challenging industrial conditions.Its advanced design incorporates temperature compensation and overload protection features,making it suitable for critical applications where measurement accuracy directly impacts product quality and process efficiency.The​​PFTL101B 2.0KN​​supports standard industrial signal outputs and interfaces,enabling seamless integration with control systems and measurement instrumentation.

​​Technical Specifications​​

Parameter Name

Parameter Value

Product Model

​​PFTL101B 2.0KN​​

Manufacturer

ABB

Product Type

Weighing Sensor/Load Cell

Rated Capacity

2.0 kN(kilonewtons)

Accuracy Class

C3 or better

Sensitivity

2.0 mV/V±0.1%

Non-linearity

≤±0.03%of rated output

Hysteresis

≤±0.03%of rated output

Creep(30 minutes)

≤±0.03%of rated output

Temperature Effect on Zero

≤±0.03%of rated output/10°C

Temperature Effect on Output

≤±0.03%of rated output/10°C

Input Resistance

380±5 ohms

Output Resistance

350±3 ohms

Insulation Resistance

≥5000 MΩ(50V DC)

Recommended Excitation

10-15V DC

Safe Overload

150%of rated capacity

Ultimate Overload

300%of rated capacity

Operating Temperature

-20°C to+70°C

Protection Rating

IP67

Cable Length

Standard 5 meters

​​Main Features and Advantages​​

Precision Measurement Performance:The​​ABB PFTL101B 2.0KN​​delivers exceptional measurement accuracy through advanced strain gauge technology and precision manufacturing.The sensor maintains excellent linearity and repeatability across its entire measurement range,with non-linearity and hysteresis both controlled within±0.03%of rated output.This high level of accuracy ensures reliable data for process control and quality assurance applications where precise weight measurement is critical.

Robust Construction and Environmental Resistance:Designed for industrial environments,the​​PFTL101B 2.0KN​​features a hermetically sealed stainless steel construction with IP67 protection,making it resistant to moisture,dust,and most industrial chemicals.The sensor incorporates comprehensive temperature compensation that minimizes the effects of temperature variations on measurement accuracy,ensuring consistent performance across the operating temperature range from-20°C to+70°C.

Installation Flexibility and Safety Features:The​​ABB PFTL101B 2.0KN​​offers multiple mounting options including threaded connections and flange mounting,providing flexibility for various application requirements.Built-in safety features include 150%safe overload capacity and 300%ultimate overload protection,preventing damage from accidental overloading.The sensor’s standardized electrical connections and cable interface simplify installation and maintenance procedures.

​​Application Field​​

The​​ABB PFTL101B 2.0KN​​finds extensive application in industrial weighing systems across multiple sectors.In manufacturing and process industries,the sensor is used in platform scales,hopper weighing systems,and force monitoring applications where precise weight measurement is essential for inventory control,batching processes,and quality assurance.The​​PFTL101B 2.0KN​​provides reliable performance in these critical applications,ensuring accurate material handling and process control.

In material handling and logistics,the​​ABB PFTL101B 2.0KN​​is employed in conveyor belt scales,crane overload protection systems,and warehouse weighing equipment.The sensor’s robust construction and high accuracy make it ideal for these demanding applications where reliability and precision are paramount.Additionally,the sensor serves in test and measurement equipment for quality control and research applications,providing accurate force measurement data for product testing and development processes.

​​Related Products​​

​​ABB PFTL101A series​​-Lower capacity variants in the same product family

​​ABB PFTL201B series​​-Higher capacity weighing sensors for heavier applications

​​ABB weight transmitters​​-Signal conditioning and display units

​​ABB weighing indicators​​-Digital displays and controllers

​​ABB junction boxes​​-Multi-sensor connection systems

​​ABB cable assemblies​​-Specialized connection cables and accessories

​​Installation and Maintenance​​

Pre-installation preparation:Before installing the​​ABB PFTL101B 2.0KN​​,ensure the mounting surface is clean,flat,and properly aligned to avoid side loads or bending moments.Verify that the installation environment meets the specified temperature and humidity requirements.Check the cable connections for integrity and ensure proper grounding is established.Prepare the necessary mounting hardware and tools according to the application requirements.

Maintenance recommendations:Regular inspection of the​​PFTL101B 2.0KN​​should include checking for physical damage,cable integrity,and connection tightness.Perform periodic calibration verification to maintain measurement accuracy.Keep the sensor clean and free from debris accumulation that could affect performance.Monitor for environmental changes that might impact measurement accuracy,and address any issues promptly to ensure continuous reliable operation.

​​Product Guarantee​​

The​​ABB PFTL101B 2.0KN​​is manufactured to ABB’s stringent quality standards,ensuring reliable performance and long-term stability in industrial weighing applications.Our commitment includes comprehensive technical support for proper selection,installation,and operation of the weighing sensor.We guarantee genuine ABB components with full traceability and documentation.For specific application requirements or technical assistance,our engineering team provides expert guidance to ensure optimal performance of the​​PFTL101B 2.0KN​​in your measurement system.
